Device Descriptions; Power Saving Mode - Matsuko Switch Box Installation And Operating Manual

TM
PUMPGUARD
What is PumpGuard™ (Switchbox Timer+PG only)
TM is patent pending, smart technology that helps to avoid possible disasters occurring
Pumpguard
when your pump blocks or overloads.
Line 1 on every Matsuko Switch Box Timer + PG is set to automatically learn how the new pump
behaves when it is first connected and turned on through the timer.
The PumpGuard TM will run the pump at different power levels for a twenty minute period until
it understands its normal operation. Once the learning process is over PumpGuard
monitoring mode. PumpGuard TM will monitor the pump all day everyday looking out for signs of
overloading or cutting out.
A pump that constantly keeps restarting can easily burn itself out. PumpGuard
situation and will run the pump on a lower intensity programme to see if this will correct the
problem. If a solution cannot be found, PumpGuard
pump from damaging itself further. In this situation PumpGuard
for a pump failure alarm is a fast beeping sound plus a red LED on line one) and the display
shows "pump fail".
Power Consumption Monitor (Switchbox Timer+PG only)
The digital display on the screen gives two electrical
consumption readings. The Switch Box Timer + PG gives
a constant reading on line 1. The second reading on the
screen shows a total consumption of all the lines been used
by all the devices on the switch box through lines 1 – 5.
To get a reading for an individual simply switch off
every line you do not want to monitor. The consumption
monitor gives an indicative reading with an
accuracy of +/-5%.
Clearing a fault from the Pumpguard
If you wish to clear the PumpGuard TM once the unit has sent the warning that there has been a
failure press Menu , using the Arrow Keys
, this will open the PumpGuard TM menu, press Enter
"Clear", this will clear the fault.
Adding a new pump
If you want to add a new pump to the PumpGuard
TM menu as above and use the arrow keys to move the cursor over to illuminate the
PumpGuard
arrow next to new pump, now press Enter , when pressed the text will show (current deleted)
and will start to run the new pump to learn its behaviour, this will take roughly twenty minutes.
Now press Menu to return to the main menu.
Page 12
TM goes into
TM detects this
TM will disconnect the power and save your
TM
sounds a stop alarm (the signal
L1: Shows power consumption on line 1.
L1–5: Shows total power consumptions of all lines.
TM
scroll down to the PumpGuard TM and press Enter
while the arrow is illuminated next to
TM so it can learn its normal function, open the
PROGRAMMING (SWITCH BOX TIMER AND TIMER + PG)
TO EDIT OR DELETE A PROGRAM SLOT
Press Menu to enter the programming menu. Select the line you want to change using Up
and Down . Press Enter .
If required, use Up and Down to change the name of the device and press Enter . Then
Press Enter to scroll through the program settings and press Up
If you need to delete a program slot, move the cursor back to highlight the program slot check
mark and press the Up button. The check mark and settings for the program slot will disappear
to show that the program slot has been de-activated.
When you have finished programming, press Enter
program slots. The screen will display a large TICK
been recorded.

DEVICE DESCRIPTIONS

The user has several choices for 'Device Descriptions' including:
Air Pump 1 Aux 1
Air Pump 2 Aux 2
Air Pump 3 Aux 3
Heater 1 Feeder 1
Heater 2 Feeder 2
Heater 3 Feeder 3
Filter 1 <None>
Filter 2
Filter 3

POWER SAVING MODE

After 5 minutes the display will go into power saving mode, to re-activate press the
Menu key.
MANUAL ON/OFF, AND OVER-RIDE PROGRAMME
If a line is off, you can manually turn if on and off by pressing that line button. When a line comes ON that
you have programmed, you can manually turn it off by pressing that line button. It will then come back on
when it reaches its next 'ON' that you have programmed.
and Down to edit times.
repeatedly to scroll through the remaining
to confirm that program slot changes have
Pump 1
Pump 2
Pump 3
UV 1
UV 2
UV 3
Light 1
Light 2
Light 3
Page 13
