ACTIVATING CONNECTED APPLIANCES (SWITCH BOX ONLY)
To activate each appliance, simply press the corresponding
on / off button on the front of the Switch Box, labelled:
For more detailed programming instructions (for the Switch Box Timer)
see page 1 1.
TYPICAL EXAMPLE OF A COMPLETE INSTALLATION
PUMP UV LIGHTS FEEDER SKIMMER
Page 10
POWER
IN
PROGRAMMING (SWITCH BOX TIMER, AND TIMER + PG)
After starting the power supply there is a short delay while the system starts up. Once the screen has
turned on, press Menu to display the programming menu. To return to the main menu press
Menu . The icons below represent the buttons.
MENU ENTER
TO PROGRAM THE DATE AND TIME
Press Menu to enter the programming mode, then use Down
down), then press Enter . Select date in the format DD/MM/YYYY and 24hr clock as displayed.
To change the date and time, use Up and Down
selection with Enter and move on. Press Menu
confirmed the minutes with Enter , the program will change automatically to the main screen

PROGRAMMING MODE.

TO PROGRAM A LINE
Press Menu to get to the programming menu. The five lines are automatically labelled 1-5. Use
Up and Down to select a line and press Enter .
Choose a device description (see list on next page) with Up
line will be renamed with selected device name. Press Enter
Each line can have up to five different program time slots which are labelled "a" through to "e".
Use Up to turn a program slot on, a check mark will appear to show that a program slot is being
set. Press Enter to proceed to set 'on' and 'off' times with Up
Use Menu at any point to move back through the options. When you have finished
programming, press Enter repeatedly to scroll through the remaining program slots.
The screen will display a large TICK to confirm that program slot changes
have been recorded.
When a line switches on, the light on the Switch Box will illuminate to show the
line is on.
UP DOWN
to select the clock icon (6 clicks
to change number displayed. Confirm
at any point to move back. When you have
and Down through device options. The
to select one.
and Down .
