Summary of Contents for IDS NXT rome
- Page 1 IDS NXT Technical manual IDS NXT rome IDS Imaging Development Systems GmbH Dimbacher Str. 10 D-74182 Obersulm, Germany T: +49 7134 96196-0 E: info@ids-imaging.com W: http://www.ids-nxt.com...
-
Page 2: Table Of Contents
4 Standards and directives ........................9 5 IDS NXT rome ..........................11 5.1 Ambient conditions ........................11 5.2 Connecting a IDS NXT rome ....................... 13 6 Mechanical specifications ........................ 15 7 Electrial specifications ........................16 7.1 Pin assignment GigE connector (M12) ..................16 7.2 Pin assignment I/O connector ..................... -
Page 3: Preface
Please contact your local IDS distributors for first level support in your language. For a list of IDS distributors worldwide please go to our website http://www.ids-nxt.com. - Page 4 IDS NXT: Technical manual IDS NXT rome Address IDS Imaging Development Systems GmbH Dimbacher Str. 10 D-74182 Obersulm, Germany +49 7134 96196-0 info@ids-imaging.com http://www.ids-nxt.com Address in UK IDS Imaging Development Systems Ltd. Landmark House, Station Road RG27 9HA Hook | United Kingdom +44 1256 962910 info@ids-imaging.com...
-
Page 5: Symbols And Hints
IDS NXT: Technical manual IDS NXT rome 2 Symbols and hints This symbol indicates hints with useful information for better understanding and using features and functions. This symbol indicates important warnings for product safety to prevent damage. This symbol indicates important warnings for personal safety to prevent injury. -
Page 6: Safety Instructions
All warranty will be spoiled in this case. Intended use IDS industrial cameras are to be used to capture images for visualization and image processing tasks. They are designed for use in industrial environments. Observe the requirements for the proper use of this product. - Page 7 IDS NXT: Technical manual IDS NXT rome · Only operate the product under ambient conditions for which the respective product is approved. The use under other ambient conditions may result in damage. · To avoid any damage to the connectors, only mount or remove the product with the cables disconnected.
- Page 8 IDS NXT: Technical manual IDS NXT rome Correct disposal Dispose the camera and accessories properly and separately from other types of waste to encourage recycling of reusable materials and to protect the environment. According to the EC Directive 2012/19/EU (WEEE) we are obliged to take back this product, distributed by us after August 13, 2005, free of charge at the end of its useful life and to ensure it correct disposal.
-
Page 9: Standards And Directives
IDS NXT: Technical manual IDS NXT rome 4 Standards and directives (only valid for devices with housing) IDS Imaging Development Systems GmbH hereby confirms that this product has been developed, designed and manufactured in compliance with the following European directives ·... - Page 10 IDS NXT: Technical manual IDS NXT rome For customers in the USA For a class A digital device: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 11: Ids Nxt Rome
32 °F … 131 °F Device temperature during storage -20 °C … 60 °C -4 °F … 140 °F Humidity 20 % … 100 %, relative, non-condensing * Only if IDS NXT rome lens tube and IP65/67 cables are used 2021-11-08... - Page 12 55 °C (131 °F). Notes on ambient conditions · Avoid high air humidity levels and rapid temperature changes when using IDS cameras. · Temperatures below +4 °C (39 °F) combined with excessive relative air humidity levels can cause icing.
-
Page 13: Connecting A Ids Nxt Rome
IDS NXT: Technical manual IDS NXT rome 5.2 Connecting a IDS NXT rome Fig. 1: IDS NXT rome · 1: Pin assignment GigE connector (M12, 8-pin) · 2: Pin assignment I/O connector (M12, 12-pin) NOTICE! The camera can be supplied with voltage both from an external source and via Power-over-Ethernet (PoE). - Page 14 IDS NXT: Technical manual IDS NXT rome To ensure optimum performance of the network connection, you need to install the latest drivers for your network card. The transfer rate of GigE network adapters for PCI slots is limited to approximately 110-120 MByte/s. USB Ethernet adapter can have different restrictions, depending on the model.
-
Page 15: Mechanical Specifications
IDS NXT: Technical manual IDS NXT rome 6 Mechanical specifications The mechanical data for each camera model can be found on our website directly at the respective camera model beneath in the "Downloads" tab. Fig. 2: IDS NXT rome NOTICE! The camera connectors may be damaged if you install or remove the camera with plugged in cables. -
Page 16: Electrial Specifications
Designation 100BASE- MDX0+ BI_DA+ MDX0- BI_DA- MDX1+ BI_DB+ MDX1- BI_DB- MDX3+ BI_DD+ Fig. 3: M12 socket, camera rear view MDX3- BI_DD- MDX2- BI-DC- MDX2+ BI_DC+ The M12 connector of the IDS NXT rome complies with the IEC/PAS 61076-2-109 standard. 2021-11-08... -
Page 17: Pin Assignment I/O Connector
Residual ripple 120 mVpp IDS Imaging Development Systems GmbH recommends to adjust the power supply to the power requirement of the camera to limit overheating in case of short circuit. To ensure the electrical safety, the camera power supply must meet the requirements for SELV (safety extra low voltage) / LPS (limited power source) or ES1 / PS2. -
Page 18: Digital Input Wiring
Choose the size of the cable in such a way that the supply voltage available at the input of the camera is at least 12 V. To supply the IDS NXT rome camera with power using PoE or PoE+, you can use PoE injectors or switches that are compatible with IEEE standard 802.3af or IEEE standard 802.at. -
Page 19: Digital Output Wiring
IDS NXT: Technical manual IDS NXT rome Digital input wiring Fig. 5: Digital input wiring Pin 5 is the reference level (GND) for all inputs. All three inputs can also be used with different voltages. 7.4 Digital output wiring Symbol... - Page 20 IDS NXT: Technical manual IDS NXT rome Open collector wiring Fig. 6: Wiring as open collector Pin 6 is the reference level (GND) for all outputs. All three outputs can be connected simultaneously as open collector. 2021-11-08...
-
Page 21: Rs-232 Wiring
Only one output can be connected as an open emitter, since the load is on pin 6. The other outputs cannot be used anymore. 7.5 RS-232 wiring The IDS NXT rome has a serial interface of the type RS-232: · Baud rate: 300 … 230 400 Baud ·... - Page 22 IDS NXT: Technical manual IDS NXT rome The data rate of the serial interface depends on the capacity and length of the cable. 2021-11-08...
-
Page 23: Status Led
IDS NXT: Technical manual IDS NXT rome 8 Status LED Fig. 8: Status LEDs The camera has two LEDs that indicate information of the current status. · LED 1: camera status (two-color) · LED 2: Network status (two-color) LED 1... -
Page 24: Optical Specifications
IDS NXT: Technical manual IDS NXT rome 9 Optical specifications Immersion depth for lenses Position accuracy of the sensor 9.1 Immersion depth for lenses Some C-mount lenses reach deep into the camera flange. This may cause the lens to push against the back of the filter glass inside the camera or even make it impossible to screw in the lens. - Page 25 IDS NXT: Technical manual IDS NXT rome Fig. 10: Position accuracy of the sensor (1) Fig. 11: Position accuracy of the sensor (2) It cannot be guaranteed that the sensor cover glass or filter glass are absolutely parallel to each other.
-
Page 26: Filter Glasses
(type GL). Every camera model is available with different filter variants such as daylight cut filters (type DL). The filter type is given at the end of the model name. The following table shows an overview of the different optical filters used in IDS cameras: Refractive... - Page 27 IDS NXT: Technical manual IDS NXT rome Infrared cut filter (type HQ) Fig. 12: HQ filter Plain glass filter (typ GL) Fig. 13: Glass filter 2021-11-08...
-
Page 28: Cleaning The Filter Glasses
The filter glasses may only be cleaned from the outside. If you remove the glasses, the sensor might get soiled.IDS Imaging Development Systems GmbH is not liable for any damage to the sensor resulting from removal of the filter glasses. - Page 29 IDS NXT: Technical manual IDS NXT rome NOTICE! Never use cleaning agents containing acetone for cleaning the filter glasses! Acetone may damage the filter glass coating and may deteriorate the optical quality of the glasses. Cameras with fixed filter glass Use a wipe to wipe off dirt particles in a single sweep beyond the edge of the filter glass.
-
Page 30: System Specification
IDS NXT: Technical manual IDS NXT rome 11 System specification 1.3 GHz Dual Core ARM Cortex-A53 FPGA Xilinx Zynq UltraScale+ (ZU3CG) 2 GB DDR4 Flash 8 GB (with the system) 11.1 CNN Operating system Linux · Image preprocessing Demosaicing ·... -
Page 31: Benchmark
IDS NXT: Technical manual IDS NXT rome · Squeeze-and-Excitation layer · ReLU activation · ReLU6 activation · Swish activation · Sigmoid activation · Batch normalization · Filter kernel/pooling parameters Kernel/pooling window: any rectangle up to 15 x 15 pixels ·... -
Page 32: Index
IDS NXT: Technical manual IDS NXT rome card - A - - O - Accelerator Ambient conditions Operating system Architecture Output digital - B - - P - Benchmark Pin assigment - C - Plain glass filter Contact - R -...
