EPOX EP-3VBA2 Manual page 41

EP-3VBA2/6VBA2
Soft-Off by PWRBTN: Use this to select your soft-off function.
The default is Delay 4 sec.
Instant Off: Turns off the system instantly.
Delay 4 Second : Turns off the system after a 4 second delay. If momentary
HDD Power Down: HDD Standby timer can be set from 1 to 15 minute(s).
Doze Mode: The "Doze" mode timer starts to count when no "PM events" have
occurred.
Suspend Mode: This function works only when the Pentium II Processor is
installed. The timer starts to count when "System Standby" mode timer is timed
out and no "PM Events" are occurring. Valid range is from 1 minute up to 1 hour.
VGA: When set to On (default), any event occurring at a VGA port will awaken a
system which has been powered down.
LPT & COM: When set to On (default), any event occurring at a COM(serial)/
LPT (printer) port will awaken a system which has been powered down.
HDD & FDD: When set to On (default), any event occurring at a hard or floppy
drive port will awaken a system which has been powered down.
PCI Master: When set to On (default), any event occurring to the DMA control-
ler will awaken a system which has been powered down.
Modem Ring Resume: When set to Enabled, any event occurring to the Modem
Ring will awaken a system which has been powered down.
RTC Alarm Resume: When set to Enable rtc alarm resume, you could set the
date (of month) and timer (hh:mm:ss), any event occurring at will awaken a
system which has been powered down.
Primary INTR: When set to On (default), any event occurring at will awaken a
system which has been powered down.
press of button, the system will go into Suspend Mode. Press
the power botton again to take system out of Suspend Mode.
BIOS
Page 4-13
