Installation
Section 3-3
Installing a Pentium
The EP-6VBA2 uses the Single Edge Contact (SEC) slot for a Pentium
processor packaged in an SEC cartridge. The SEC slot is not compatible with other
®
non-Pentium II/III processors.
Please have ready the following list of components so that we may install the
processor onto the motherboard.
1. Pentium
2. Intel Pentium
OK, now that you have all of your components ready, we can start.
First, please refer to figure 6 below, and follow the direction to lift up the
fixed foldable pentium
device is designed for you to install Pentium
avoide any damage on the board due to overtightening the four screws.
One thing must be kept in your mind that please make sure to lift upright the
foldable parts of the Retention module to fit and install CPU properly.
Now we are going to put the heatsink or cooler onto Pentium
Due to the processor is more and more faster in the feature. The power consump-
tion is larger than before processor. We strong recommend a good attach fan
heatsink or cooler onto the processor's OLGA package become very important.
®
The Pentium II/III processor may also be offered as Intel
boxed processor's fan heatsink requires a +12V power supply. A fan power cable
Page 3-8
II/III Processor (EP-6VBA2 only)
®
®
II/III processor heat sink
®
II/III Processor
®
II/III Retention Mechanism. This pre-installed
Figure 6
EP-3VBA2/6VBA2
®
®
II/III CPU more easier and to
®
II/III processor.
®
boxed processors. The
II/III
