Frigidaire FES367E Factory Parts Catalog

30-inch slide-in electric range
Hide thumbs

Advertisement

Quick Links

FES367EC.eps LA20BG0048.eps BFES366ECA.eps LA20CT0061.eps
DFES367ECA.eps
318271907.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FES367ECA
37954386K50S1 37954386K50S2
Series
30" slide-in
Color
stainless
Market
North America
Wiring Diagram
318271907
Owner's Guide
318203810
Installation Instructions 318201611
Timer Guide
318200185
Publication No.
5995450862
05/10/07
(EN/SERVICE/ECL)
377
FES367ECB
30" slide-in
stainless
North America
318271907
318203810
318201611
318200185
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES367E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FES367E

  Summary of Contents for Frigidaire FES367E

  • Page 1 37954386K50S1 37954386K50S2 30" slide-in 30" slide-in stainless stainless North America North America 318271907 318271907 318203810 318203810 318201611 318200185 318200185 30-INCH SLIDE-IN ELECTRIC RANGE Model No. FES367E Publication No. 5995450862 05/10/07 (EN/SERVICE/ECL) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.
  • Page 2 Publication No: 5995450862 FES367E BACKGUARD 10/05...
  • Page 3 318163602 08016432 5303300265 5303311333 # Functional Parts * Non-Illustrated Parts FES367E BACKGUARD A FES367E (FES367ECA) B FES367E (FES367ECB) DESCRIPTION Light, indicator, 125v, (2) Console, assy., black Control Panel Assembly, w/membrane, stainless Control Panel Assembly, w/membrane, stainless Panel, control mtg. Clock/Timer, electronic, ES350 Screw, control mtg., 8-18 x 1/2"...
  • Page 4 Publication No: 5995450862 FES367E BODY 10/05...
  • Page 5 318251300 316136400 316136600 112# 318112703 # Functional Parts * Non-Illustrated Parts FES367E BODY A FES367E (FES367ECA) B FES367E (FES367ECB) DESCRIPTION Back, main Panel, main back, upper Shield, insulation, upper Panel, bodyside, upper RH Panel, bodyside, upper LH Screw, leveling Rack, oven...
  • Page 6 Publication No: 5995450862 FES367E BODY 10/05...
  • Page 7 5303211311 5303307980 5303323129 5304415832 5304436875 # Functional Parts * Non-Illustrated Parts FES367E BODY A FES367E (FES367ECA) B FES367E (FES367ECB) DESCRIPTION Switch, thermal cutout Backet, glide, (2) Insulation, 3.81 x 3.13 Motor, fan Adapter Assembly, vent tube, w/converter Box, vent Plate, shield...
  • Page 8 Publication No: 5995450862 FES367E TOP/DRAWER 10/05...
  • Page 9 5303325173 5303211311 5303300265 5303311333 # Functional Parts * Non-Illustrated Parts FES367E TOP/DRAWER A FES367E (FES367ECA) B FES367E (FES367ECB) DESCRIPTION Drawer Panel, drawer, stainless, front Panel, drawer, stainless, front Screw, handle mtg, 10-32 x 3/4 Bracket, drawer support, (2) Glide, warmer, inner RH...
  • Page 10 Publication No: 5995450862 FES367E DOOR 10/05...
  • Page 11 318165800 316221001 318163602 5304415832 # Functional Parts * Non-Illustrated Parts FES367E DOOR A FES367E (FES367ECA) B FES367E (FES367ECB) DESCRIPTION Trim, oven door, side, (2) Cover, rear door, black, (2) Baffle, door Insulation, oven door Insulation, oven door Glass, oven door, heat barrier...
  • Page 12: Wiring Diagram

    Publication No: 5995450862 FES367E WIRING DIAGRAM 10/05...
