Frigidaire FRS367AQG Parts Catalog

30-inch slide-in electric range
Hide thumbs

Advertisement

Quick Links

FES367A.eps LA00BG78330-2G.eps LAP23V0072D-4.eps LA00CT76336-2.eps
LA00D07396-3F.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
Series
Color
Market
Wiring Diagram
Owner's Guide
Installation Instructions 318201600
Timer Guide
318045067.eps
(EN/SERVICE/ECL)
FES367ABG FES367AQG FES367ASG
30" slide-in
30" slide-in
black
bisque
North America North America North America
318045067
318045067
318200823
318200823
318201600
318200191
318200191
Publication No.
5995401121
04/01/09
377
Copyright
30" slide-in
white
318045067
318200823
318201600
318200191
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES367A
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FRS367AQG

  Summary of Contents for Frigidaire FRS367AQG

  • Page 1 Product No. FES367ABG FES367AQG FES367ASG Series 30" slide-in 30" slide-in 30" slide-in Color black bisque white Market North America North America North America Wiring Diagram 318045067 318045067 318045067 Owner's Guide 318200823 318200823 318200823 Installation Instructions 318201600 318201600 318201600 Timer Guide 318200191 318200191 318200191...
  • Page 2 Publication No: 5995401121 FES367A BACKGUARD 01/04...
  • Page 3 FES367A Publication No: 5995401121 BACKGUARD Model Index: A FES367A (FES367ASG) B FES367A (FES367ABG) C FES367A (FES367AQG) POS. NO PART NO. DESCRIPTION 14 # 318076700 A B C Light, indicator, 125v 318039310 A - - End Cap, white, RH 318039312 - B - End Cap, black, RH 318039316 - - C...
  • Page 4 Publication No: 5995401121 FES367A BODY 01/04...
  • Page 5 FES367A Publication No: 5995401121 BODY Model Index: A FES367A (FES367ASG) B FES367A (FES367ABG) C FES367A (FES367AQG) POS. NO PART NO. DESCRIPTION 318066402 A B C Panel, main back 318070910 A B C Panel, main back, upper 318227600 A B C Shield, oven top 318159800 A B C...
  • Page 6 Publication No: 5995401121 FES367A BODY 01/04...
  • Page 7 FES367A Publication No: 5995401121 BODY Model Index: A FES367A (FES367ASG) B FES367A (FES367ABG) C FES367A (FES367AQG) POS. NO PART NO. DESCRIPTION 5303311164 A B C Spring 141# 318005201 A B C Switch, thermal cutout 318123901 A B C Deflector 5304405244 A B C Anti-tip &...
  • Page 8 Publication No: 5995401121 FES367A TOP/DRAWER 01/04...
  • Page 9 FES367A Publication No: 5995401121 TOP/DRAWER Model Index: A FES367A (FES367ASG) B FES367A (FES367ABG) C FES367A (FES367AQG) POS. NO PART NO. DESCRIPTION 318107104 A B C Drawer 318134011 A - - Panel, drawer, white, front 318134012 - B - Panel, drawer, black, front 318134013 - - C Panel, drawer, bisque, front...
  • Page 10 Publication No: 5995401121 FES367A DOOR 01/04...
  • Page 11 FES367A Publication No: 5995401121 DOOR Model Index: A FES367A (FES367ASG) B FES367A (FES367ABG) C FES367A (FES367AQG) POS. NO PART NO. DESCRIPTION 318180310 A B C Bracket, trim mtg 318180312 A B C Bracket, upper trim mtg 318187810 A - - Trim, door, white, RH side 318187814 - B -...
  • Page 12: Wiring Diagram

    Publication No: 5995401121 FES367A WIRING DIAGRAM 01/04...
