Frigidaire FES367B Factory Parts Catalog

Electric
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FES367BCA
FES367B
WIRING DIAGRAM - # 318045066
OWNER'S GUIDE - # 318200823
TIMER INSTRUCTION SHEET - # 318200191
INSTALLATION INSTRUCTIONS - # 318201600
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
37954336H20S1
stainless
Publication No.
5995375564
020710
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
RANGE
Model No.
FES367B
©2002 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

  Related Manuals for Frigidaire FES367B

  Summary of Contents for Frigidaire FES367B

  • Page 1 PRODUCT NO. BASE MODEL NO. FES367BCA FES367B WIRING DIAGRAM - # 318045066 OWNER’S GUIDE - # 318200823 TIMER INSTRUCTION SHEET - # 318200191 INSTALLATION INSTRUCTIONS - # 318201600 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.
  • Page 2 Publication No. FES367BCA 5995375564 BACKGUARD 07/02...
  • Page 3 POS. NO 14 # 20 # 24 # 54 # 54A# # = Functional Parts * = Non-Illustrated Parts FES367BCA BACKGUARD PART NO DESCRIPTION 318076700 Light,indicator ,125v 5303300160 End Cap,black ,RH 5303300161 End Cap,black ,LH 318182991 Panel,control mtg. ,black 318185414 Clock/Timer,electronic ,black 318027810 Trim,backguard ,black ,top...
  • Page 4 Publication No. FES367BCA 5995375564 BODY 07/02...
  • Page 5 POS. NO 12 # 14 # 37 # 62 # 66 # 67 # 89 # 108# 141# # = Functional Parts * = Non-Illustrated Parts FES367BCA BODY PART NO DESCRIPTION 318066402 Panel,main back 318070910 Panel,main back ,upper 318108600 Shield,oven top 318159800 Panel,body side ,upper 318160004...
  • Page 6 Publication No. FES367BCA 5995375564 07/02...
  • Page 7 POS. NO 15 # 15A# 15B# 51 # # = Functional Parts * = Non-Illustrated Parts FES367BCA PART NO DESCRIPTION 5303310500 Drawer 318107903 Panel,drawer ,stainless 318194800 Support,element ,(2) 5303311125 Bracket,drawer 5303311129 Channel,drawer ,RH 5303311130 Channel,drawer ,LH 316224200 Element,surface ,9" ,2500W ,radiant 318198812 Element,surface ,8"...
  • Page 8 Publication No. FES367BCA 5995375564 DOOR 07/02...
  • Page 9 POS. NO # = Functional Parts * = Non-Illustrated Parts FES367BCA DOOR PART NO DESCRIPTION 318056802 Shield,insulation 318133754 Insulation,oven door 318157011 Liner,door 5303311174 Screw,10-24 x 3/8 5304417411 Screw,handle mtg. ,10-12 x 1 318053103 Gasket,oven door seal 318187916 Stainless Panel,oven door ,w/ glass 318041603 Panel,glass ,inner oven door 318042102...
  • Page 10: Wiring Diagram

    Publication No. FES367BCA 5995375564 WIRING DIAGRAM 07/02...
