Gti high volume low pressure gravity feed spray gun

Advertisement

Quick Links

GTI HIGH VOLUME LOW PRESSURE GRAVITY FEED SPRAY GUN
#2000 Millennium Air Cap
PSI / CFM Information
INLET
CAP
PRESSURE
PRESSURE
at handle
fan fully
of gun
open
(PSI)
(PSI)
8
2
14.5
4
20
6
24.5
8
30
10
IMPORTANT: Before using this equipment,
read all safety precautions and instructions.
Keep for future use.

DESCRIPTION

The high volume low pressure gravity feed
GTI gun is designed to apply a wide
variety of finishing materials. This gun was
manufactured
to provide a maximum
transfer efficiency by limiting air cap
pressure to 10 psi (complies with rules
issued by SCAQMD and other air quality
authorities).
This gun will produce approximately 10 psi
air cap pressure at 30 psi gun inlet pressure.
An air cap test kit is available (see Accesso-
ries) which can be utilized to set the exact air
cap presssure. Air consumption for this
gun (with #2000 cap) is 15.5 scfm at 10 psi air
cap pressure.
NOTE
This gun includes 400 series stain-
less steel fluid tip and needle.
Guns may be used with chlori-
nated solvent materials only if the
attached gravity cup is Delrin or
Nylon. Do not use aluminum
cups with chlorinated solvent
materials.
Important: This gun may be used with most
common coating and finishing materials. It
is designed for use with mildly corrosive
and non-abrasive materials. If used with
other high corrosive or abrasive materials,
it must be expected that frequent and thor-
ough cleaning will be required and the ne-
cessity for replacement of parts will be
increased.

INSTALLATION

For maximum transfer efficiency, do not
use more pressure than is necessary to
atomize the material being applied.
CFM
1 .
Connect the gun to a clean, moisture
FLOW
and oil free air supply using a hose size
(CFM)
of at least 5/16" I.D. hose. Do not use
7.5
1/4" I.D. hose (25' x 1/4" hose at 18 CFM
10.5
has a pressure loss of 25 psi. 25' x 5/16"
12.5
hose at 18 CFM has a pressure loss of
14.5
8 psi).
15.5
Depending on hose length, larger
I.D. hose may be required. Install an
HAV-511 air gauge at the gun handle
and air cap test kit over tip. When
gun is triggered on, adjust regulated
pressure to desired setting to pro-
vide a maximum of 10 psi at the air
cap. Do not use more pressure than
is necessary to atomize the material
being applied. Excess pressure will
create additional overspray and re-
duce transfer efficiency.
If quick connects are required, use
only high flow quick connects ap-
proved for HVLP use such as DeVil-
biss HC-4419 and HC-4719. Other
types will not flow enough air for
proper gun operation.
If an air adjusting valve is used at the
gun inlet, use DeVilbiss Model HAV-
500 or HAV-511. Some competitive
adjusting valves have significant
pressure drop that can adversely
affect spray performance. Models
HAV-500 and HAV-511 have minimal
pressure drop, which is important
for HVLP spraying.
2.
Attach the gravity feed cup to the
material inlet.
Protective coating and rust inhibi-
tors have been used to keep the
gun in good condition prior to
shipment. Before using the gun,
flush it with solvents so that these
materials will be removed from
fluid passages.
NOTE
NOTE
NOTE
NOTE
SERVICE BULLETIN
SB-2-168-K
Replaces SB-2-168-J
Repair Kit KK-5058-2

OPERATION

Mix, prepare and strain the material to be
sprayed according to the paint maufacturer's
instructions.
Strain material through a 60 or 90 mesh
screen.
1.
Fill the gravity feed cup with the mate-
rial. Do not overfill. Make sure that the
cup lid vent hole is clear.
2.
Open the spreader adjustment valve
(10) (Fan) by turning the valve stem
counterclockwise.
3.
Close the fluid needle adjusting screw
(17) by turning clockwise.
4.
Turn on air supply and set gun inlet
pressure to lowest recommended pres-
sure for material being sprayed. Best
atomization will occur with 10 psig air
cap pressure. However, some materi-
als can be sprayed at lower pressures,
improving transfer efficiency.
5.
Spray a test area by turning fluid needle
adjusting screw (17) counterclockwise
until a full coat is obtained.
If the finish is too sandy and dry, the
material flow may be too low for the
atomization air pressure being used.
If the finish sags, there is too much material
flowing for the atomization air pressure
being used.
Both of the above can be corrected by
increasing or decreasing the atomization air
pressure or the material flow. Pattern width
can be altered by turning spreader adjust-
ment valve (10), either clockwise to de-
crease the width or counterclockwise to
increase the width.
See Spray Gun Guide, SB-2-001 latest revi-
sion, for details concerning setup of spray
guns.

PREVENTIVE MAINTENANCE

To clean air cap and fluid tip, brush exterior
with a stiff bristle brush. If necessary to clean
cap holes, use a broom straw or toothpick if
possible. If a wire or hard instrument is used,
extreme care must be used to prevent scratch-
ing or burring of the holes which will cause
a distorted spray pattern.
(Continued on page 3)
