DANFOSS BT27IK
Use the information below to properly turn the transmitter ON (OPERATION mode).
1. Place a charged battery in the transmitter. The charge must be done following the instructions of the
Battery Chargers' Manual.
Use the information below to properly turn the transmitter ON (OPERATION mode).
1. Place a charged battery in the transmitter. The charge must be done following the instructions of the
Battery Chargers' Manual.
2. Turn the contact key.
2. Turn the contact key.
3. Push and pull out the STOP button.
LED will flash orange-green pulse. If the transmitter has LCD, it displays the identification of the
machine and battery level (only if it has been pre-programmed).
3. Push and pull out the STOP button.
LED will flash orange-green pulse. If the transmitter has LCD, it displays the identification of the
machine and battery level (only if it has been pre-programmed).
4. Press the start button. The green LED will now light to indicate the transmitter is transmitting. Once
the Tx is connected, press any maneuver button and its corresponding relay will be activated. Check
to make sure all other maneuvers work in a coherent way with the expected movements.
4. Press the start button. The green LED will now light to indicate the transmitter is transmitting. Once
the Tx is connected, press any maneuver button and its corresponding relay will be activated. Check
to make sure all other maneuvers work in a coherent way with the expected movements.
