- Page 1 OWNER’S MANUAL Transparent Display Please read this manual carefully before operating your set and retain it for future reference. 47WFB 49WFB 55WFB www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Mounting Holes Portrait Layout Storage Method for Panel Protection - Correct Method - Incorrect Method PRODUCT INSTALLATION Installing an LVDS Cable 47/55WFB LVDS connection 49WFB LVDS connection TSP500-M/TSP510-M LVDS connection Lighting Installation Installation in Enclosure Precaution - Correct Method - Incorrect Method... -
Page 3: Important Precautions 22 Troubleshooting
IMPORTANT PRECAUTIONS Please read these safety precautions carefully before using the product. WARNING Failure to follow those warnings may result in death, serious injury or damage to the product or other property. WARNING • Indoor Use Only. Electrical Power Related Precautions WARNING •... -
Page 4: Precautions In Installing The Product
• If you dropped the product or the case is broken, turn off the product and unplug the power cord. ►If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer Service. •... -
Page 5: Precautions In Using/Cleaning The
Do not attempt to disassemble, repair or modify the product yourself. ►Fire or electric shock can occur. ►Contact LG Customer Service for repair. • When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. -
Page 6: Installation Preparation
INSTALLATION PREPARATION Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. Card and book NOTE The accessories provided with your product may vary depending on the model or region. -
Page 7: Mounting Holes
Mounting Holes CAUTION This product has the front and back sides. Make sure the product is installed with the front side facing forward. Image is displayed reversely on the back side. 47WFB Use M3 screws to mount the monitor. There are 16 positions for screws on the rear side of the product. <... - Page 8 49WFB Use M3 screws to mount the monitor. There are 8 positions for screws on the rear side of the product. < Front of the product > < Rear of the product >...
- Page 9 55WFB Use M3 screws to mount the monitor. There are 8 positions for screws on the rear side of the product. < Front of the product > < Rear of the product >...
-
Page 10: Portrait Layout
Portrait Layout To install in portrait mode, rotate the set clockwise 90 degrees when looking at from the front. The portrait mode is only available on the scaler board. (The scaler board should support portrait mode.) 47/55WFB 49WFB CAUTION The scaler board is optional and it is not part of the product. -
Page 11: Storage Method For Panel Protection
Storage Method for Panel Protection Correct Method Incorrect Method Panel Cushion Panel When laying the product on a flat floor, pit it face down on a cushion or blanket to prevent scratch- ing and damage. If the product is tilted onto the bezel, the bottom of the panel may be damaged. -
Page 12: Product Installation
PRODUCT INSTALLATION Installing an LVDS Cable The LVDS cable port is located as shown in the figure below. When installing the product, make sure there is enough space to install the LVDS cable. 47/55WFB LVDS Cable (not included) 38 mm 49WFB... -
Page 13: 47/55Wfb Lvds Connection
47/55WFB LVDS connection Place a soft cloth on the table and put the set on it as illustrated. Put a LVDS cable in a holder. Cable head has to be properly oriented. CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. - Page 14 Attach LVDS cable and holder to the set with two screws. (These screws are included with TSP500-M/ TSP510-M.) Cable head has to be toward set back. (Label is located on set back.) CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. Check the direction of the LVDS cable to prevent damage to the LVDS cable.
-
Page 15: 49Wfb Lvds Connection
49WFB LVDS connection Place a soft cloth on the table and put the set on it as illustrated. Put a LVDS cable in a holder. Cable head has to be properly oriented. CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. Check the direction of the LVDS cable to prevent damage to the LVDS cable. - Page 16 Attach LVDS cable and holder to the set with two screws. (These screws are included with TSP500-M/ TSP510-M.) Cable head has to be toward set back. (Label is located on set back.) CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. Check the direction of the LVDS cable to prevent damage to the LVDS cable.
-
Page 17: Tsp500-M/Tsp510-M Lvds Connection
TSP500-M/TSP510-M LVDS connection Unscrew two screws to assemble LVDS cable and holder. Don’t throw away the screws. TSP500-M TSP510-M Put a LVDS cable in a holder. Cable head has to be properly oriented. CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. Check the direction of the LVDS cable to prevent damage to the LVDS cable. - Page 18 Attach LVDS cable and holder to TSP500-M/TSP510-M with two screws saved in step 1. TSP500-M TSP510-M CAUTION To prevent the LVDS cable from being separated, you must use a LVDS holder. Check the direction of the LVDS cable to prevent damage to the LVDS cable.
-
Page 19: Lighting Installation
Lighting Installation This product must be installed with backlighting. Lighting must be installed behind the product so that the display can be seen clearly. 600 lux or more (When the Full Screen Lighting is White.) If something obstructs the backlighting, additional lighting may be required. Additional lighting 600 lux or more (When the Full Screen... -
Page 20: Installation In Enclosure
Installation in Enclosure Install the product in the enclosure. Wear working gloves when installing the product. Do not use bare hands. Otherwise, it may cause personal injury. Place the product in the enclosure. Attach the product using the prepared screw holes and an additional enclosure guide frame. -
Page 21: Precaution
Precaution Correct Method Incorrect Method Do not hold the screen area when holding the Do not lift up the product by holding a corner. product. CAUTION Make sure the power is disconnected before moving or installing the product. Otherwise electric shock may occur. Wear working gloves when installing the product. - Page 22 TROUBLESHOOTING After-image appears on the product. Problem Resolution After-image appears when the y If you use a fixed image for a long time, the pixels may be damaged product is turned off. quickly. Use the screen-saver function. y When a dark image is displayed on the screen after an image with high contrast (black and white or gray), this may cause image sticking.
- Page 23 Surface Treatment (Top) Hard coating (2H), Anti-glare treatment (Reflectance < 2 %) Possible Display Type Landscape and Portrait Enabled 55WFB Screen type Liquid Crystal Display (LCD) Screen Dimension (W x H x D) 1331.1 mm x 786.7 mm x 11.2 mm (52.4 inches x 30.9 inches x 0.4 inches) Pixel Pitch 0.210 mm x 0.630 mm...
- Page 24 (Unit : mm) 47WFB 1176.58 11.2 222.1 16-M3 Tap Hole 109.6 354.24 446.34...
- Page 25 49WFB 1222.34 11.2 8-M3 Tap Hole 55WFB 1331.1 11.2 8-M3 Tap Hole...
- Page 26 LVDS PIN MAP GUIDE 47/49/55WFB LVDS connector: DD4RA40JA1 or equivalent LVDS cable connector: DD4PA40MA1 or equivalent Cable specification: Coaxial cable or twisted pair cable 1 meter long or shorter Pin No. Symbol Description NOTE Power Supply+12.0V Power Supply+12.0V Power Supply+12.0V Power Supply+12.0V...
- Page 27 Pin No. Symbol Description NOTE R1AP First LVDS receiver signal (A+) Ground R1AN First LVDS receiver signal (A-) Ground No Connection LVDS Select H' = JEIDA, 'L' = VESA Note: 1. All (power input) pins should be connected together. 2. All Input levels of LVDS signals are based on the EIA 644 Standard.
- Page 28 Make sure to read the Safety Precautions before using the product. The model and serial numbers of the SET are located on the back and one side of the SET. Record it below should you ever need service. Temporary noise is normal when powering ON or MODEL OFF this device.
