Summary of Contents for LG 49WFB
- Page 1 Easy Setup Guide Transparent Display Please read this manual carefully before operating your set and retain it for future reference. 47WFB 49WFB 55WFB P/NO : MFL69346102 (1510-REV00)
-
Page 2: Installation Preparation
INSTALLATION PREPARATION Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. Card and book To view the Owner's Manual You can view more information about the signage monitors in the owner's manual. -
Page 3: Mounting Holes
Mounting Holes CAUTION This product has the front and back sides. Make sure the product is installed with the front side facing forward. Image is displayed reversely on the back side. 47WFB Use M3 screws to mount the monitor. There are 16 screw holes on the rear side of the prod- uct. - Page 4 49WFB Use M3 screws to mount the monitor. There are 8 screw holes on the rear side of the product. < Rear side of the product >...
- Page 5 55WFB Use M3 screws to mount the monitor. There are 8 screw holes on the rear side of the product. < Rear side of the product >...
-
Page 6: Storage Method For Panel Protection
Storage Method for Panel Protection Correct Method Incorrect Method Panel Cushion Panel When laying down the product, place a cushion or a soft cloth on a flat floor. Put the product down with the panel of the product facing down. If the product is tilted onto the bezel, the bottom of the panel may be damaged. -
Page 7: Product Installation
PRODUCT INSTALLATION Lighting installation This product must be installed with lighting. Lighting must be installed behind the product so that the display can be seen clearly. 600 lux or more Lighting (When the Full Screen is White.) Installing a certain object behind the screen may require additional lighting. Additional lighting 600 lux or more Lighting... -
Page 8: Installation In Enclosure
Installation in Enclosure Install the product in the enclosure. Wear working gloves when installing the product. Do not use bare hands. Otherwise, it may cause personal injury. Place the product in the enclosure. Attach the product using the prepared screw holes and an additional enclosure guide frame. -
Page 9: Specifications
55WFB Dimension (W x H x D) 1331.1 mm x 786.7 mm x 11.2 mm Weight (head) 6.6 kg 49WFB Dimension (W x H x D) 1222.34 mm x 690.8 mm x 11.2 mm Weight (head) 5.4 kg Choose reliable TV and video offered on our website.
