Clean Face Direct Vent
Fireplace Insert
Models: VC41LDVINTSC,
VC41LDVIPTSC, VC41CDVINTSC
WARNING
IF The INFORMATION IN TheSe INSTRuCTIONS IS
NOT FOLLOWeD exACTLy, A FIRe OR exPLOSION
MAy ReSuLT CAuSING PROPeRTy DAMAGe,
PeRSONAL INjuRy OR LOSS OF LIFe.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WhAT TO DO IF yOu SMeLL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale,
from the manufacturer.
Installation and
4685
Operating Instructions
VC41LDVI insert cover
WARNING
AVERTISSEMENT
INSTALLeR: Leave this manual with the appliance.
CONSuMeR: Retain this manual for future refer-
ence.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitré avant d'y toucher.
Ne laisser jamais les enfants
20304685 11/13 Rev. 4
toucher le panneau vitré.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC41LDVINTSC and is the answer not in the manual?

Questions and answers

Summary of Contents for Vermont Castings VC41LDVINTSC

  • Page 1 Clean Face Direct Vent Fireplace Insert Models: VC41LDVINTSC, VC41LDVIPTSC, VC41CDVINTSC WARNING IF The INFORMATION IN TheSe INSTRuCTIONS IS NOT FOLLOWeD exACTLy, A FIRe OR exPLOSION MAy ReSuLT CAuSING PROPeRTy DAMAGe, PeRSONAL INjuRy OR LOSS OF LIFe. Installation and 4685 –...
  • Page 2: Table Of Contents

    CONTeNTS VC41LDVI/VC41CDVI Gas Fireplace Insert Thank you and congratulations on your purchase of a Vermont Castings Gas Fireplace Insert PLeASe ReAD The INSTALLATION AND OPeRATION INSTRuCTIONS BeFORe uSING The APPLIANCe! IMPORTANT: Read all instructions and warnings carefully before starting installation.
  • Page 3: Important Safety Information

    IMPORTANT SAFeTy INFORMATION VC41LDVI/VC41CDVI Gas Fireplace Insert OWNeR INSTALLeR Please retain these instructions for future reference. Please leave these instructions with the appliance. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •...
  • Page 4: Code Approval

    IMPORTANT SAFeTy INFORMATION & CODe APPROVAL VC41LDVI/VC41CDVI Gas Fireplace Insert 11. Keep the area around your fireplace clear of combus- IMPORTANT: tible materials, gasoline, and other flammable vapor PLeASe ReAD The FOLLOWING and liquids. Do not run fireplace where these are used CAReFuLLy or stored.
  • Page 5: Product Features Product Specifications

    4,500 feet (1,370 m). Input Input Orifice Size Model Fuel BTu/h BTu/h Front Rear GAS PReSSuReS VC41LDVINTSC Nat. 39,000 27,000 VC41LDVIPTSC 36,000 28,000 1.20 mm 1.30 mm Natural Propane (LP) VC41CDVINTSC Nat. 40,000 30,800 3.1 mm Inlet Minimum 4.5” w.c.
  • Page 6: Insert Dimensions

    INSeRT DIMeNSIONS VC41LDVI/VC41CDVI Gas Fireplace Insert ” (621 mm) 13 ” (337 mm) ” 12 ” (56 mm) (318 mm) ” (144 mm) " 18 " (586 mm) (460 mm) ” (668 mm) 2 ” 29 ” (740 mm) (57 mm) Figure 2 - VC41LDVI Fireplace Insert Dimensions 4734...
  • Page 7: Installation Information

    GeNeRAL INSTALLATION INFORMATION VC41LDVI/VC41CDVI Gas Fireplace Insert BeFORe yOu START INSeRT APPLICATIONS Before installing the gas fireplace insert, consider the Read this homeowner manual thoroughly and follow all functioning needs of the fireplace. Confirm the size of the instructions carefully. Inspect all contents for shipping fireplace cavity, the design of the chimney, and the avail- damage and immediately inform your dealer if any damage ability of the gas supply and electricity for the insert fan.
  • Page 8: Insert Clearances

    CLeARANCeS VC41LDVI/VC41CDVI Gas Fireplace Insert INSeRT CLeARANCeS No combustibles (ie: drapes, doors) may be within, or swing within 36" of the front of the insert. Finish Wall 12" (305 mm) 12” (305 mm) Maximum Depth 14" Noncombustible Side Wall Material Required (356 mm) up to 14"...
  • Page 9: Installation

    INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert INSeRT PLACeMeNT ReMOVe COMMAND CeNTeR BRACKeT • The insert must be placed within a code-conforming In order to fit insert into a smaller opening, the command masonry fireplace or a tested and listed zero-clear- center bracket may be removed. Refer to Pages 6 and 9 ance (UL-127, solid fuel) fireplace.
  • Page 10: Zero-Clearance Fireplace Requirements

    INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert ZeRO-CLeARANCe (MeTAL) FIRePLACe Insulation ReQuIReMeNTS • The damper and grate must be removed. • The smoke shelf, internal baffles, screen, refractory and Shelf metal or glass doors may be removed (if applicable). • Do not remove or alter the insulation or any structured rigid frame members (metal sides, floor, door frames, Masonry Lining or Refractory face of the fireplace, etc.).
  • Page 11: Venting Installation

    Installation of any damaged venting component. • Unauthorized modification of the venting system. • Installation of any component part not manufactured or approved by Vermont Castings Group. • Installation other than permitted by these instruc- tions. Maximum Height 40' (12.9 m) This insert must be vented to the outside.
  • Page 12: Altitude Considerations

    VeNTING INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert ALTITuDe CONSIDeRATIONS This heater has been tested at altitudes ranging from sea Failure to adjust air shutter properly may level to 4,500 feet (1,370 m). In this testing, heater with lead to improper combustion which can standard orifice burns correctly with just an air shutter create a safety hazard.
  • Page 13: Venting Configurations

    VeNTING INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert VeNTING CONFIGuRATIONS Termination Kits (Refer to Page 11) Exhaust Inlet 3" (75 mm) Exhaust UL 1777 Gas Liner 3" (75 mm) Inlet Recommended block-off plate (noncombustible metal). Prevents odors from chimney entering room. UL 127 Solid Fuel Z.C Fire- FP2949 Figure 11 -...
  • Page 14: Insert Installation

    GLASS FRAMe ReMOVAL VC41LDVI/VC41CDVI Gas Fireplace Insert GLASS FRAMe ReMOVAL BRICK PANeL INSTALLATION 1. Before installation, the glass frame removal tool must Figure 13 be removed from the side of the unit. As you face the Kit contents: front of the unit, the glass frame removal tool is located 1, Rear Panel 2, Upper Brick Retainer Brackets on the right side.
  • Page 15: Porcelain Panel Installation

    PORCeLAIN PANeL INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert Figure 14 NOTe: The contemporary porcelain liner kit can only be 1. Remove porcelain panels and hardware from packag- used with a contemporary unit. The log porcelain liner kit ing. can only be used with a log unit. 2.
  • Page 16: Intake/Exhaust Manifold Removal & Vent Install

    INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert INTAKe/exhAuST MANIFOLD ReMOVAL The unit is shipped from the factory without a baffle AND VeNT INSTALLATION installed. On the natural gas units, the baffle should be sufficient for venting up to 20 feet (6 m) off the top of the The intake/exhaust manifold is shipped attached to insert.
  • Page 17: Check Gas Type

    INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert CheCK GAS TyPe Use proper gas type for the insert you are installing. If you have conflicting gas type, do not install insert. See dealer 100 gal. (min. where you purchased the insert for proper insert according External Propane/LP to your gas type.
  • Page 18 INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert A manual shut-off valve is factory installed Only persons licensed to work with gas upstream of the appliance. union tee and piping may make the necessary gas con- plugged 1/8" NPT pressure tapping point nections to this appliance. should be installed upstream of the appli- ance.
  • Page 19: Check Gas Pressure

    CheCK GAS PReSSuRe VC41LDVI/VC41CDVI Gas Fireplace Insert 1. Check gas type. The gas supply must be the same as Pressure Inlet stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance.
  • Page 20: Electrical Installation

    eLeCTRICAL INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert eLeCTRICAL WIRING This insert will work without any electrical supply. Electricity is only needed to operate blower. 300 Watts To Outlet A/C Module Verify proper operation after servicing. Pilot Optional Aux. 300 Watts 300 Watts RF Receiver A/C Module ON/OFF Button...
  • Page 21: Log Placement

    LOG PLACeMeNT VC41LDVI/VC41CDVI Gas Fireplace Insert Before you begin - This unit is supplied with seven (7) The positioning of the logs is critical to ceramic fiber logs. Do not handle these logs with your bare the safe and clean operation of this heater. hands.
  • Page 22 LOG PLACeMeNT VC41LDVI/VC41CDVI Gas Fireplace Insert Log #1 3. Install log #1 by placing hole in bottom of log on pins on the rear of the support bracket. Figure 24 Figure 24 LG1151 4. Install log #2 by placing locator block between front and rear burner.
  • Page 23 LOG PLACeMeNT VC41LDVI/VC41CDVI Gas Fireplace Insert Log #5 6. Install log #4 onto log #1 and log #3 by placing rectangular notches Log #4 on bottom of log #4 onto the rectangular protrusions on logs #1 and #3. Make sure the ember and bark area of the log is facing in.
  • Page 24: Decorative Glass Installation

    LOG, DeCORATIVe GLASS & BeAD PLACeMeNT VC41LDVI/VC41CDVI Gas Fireplace Insert 9. Install log #7 onto log #6 by placing the rectangular notch on the bottom of log #7 onto the rectangular protrusion on log #6. Make sure the ember and bark of the log is facing in.
  • Page 25: Stone Placement

    GLASS & STONe INSTALLATION VC41LDVI/VC41CDVI Gas Fireplace Insert DeCORATIVe GLASS & STONe INSTALLA- TION Use caution when handling glass. 3. Place stones on glass randomly as desired. Figure 29 1. Remove glass frame using the cam tool supplied with unit. 4.
  • Page 26: Operating Instructions

    OPeRATING INSTRuCTIONS VC41LDVI/VC41CDVI Gas Fireplace Insert FOR yOuR SAFeTy ReAD BeFORe LIGhTING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of lie. A. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions.
  • Page 27: Operating Instructions

    OPeRATING INSTRuCTIONS VC41LDVI/VC41CDVI Gas Fireplace Insert OPeRATING INSTRuCTIONS 1. STOP! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. With five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow "B"...
  • Page 28: Adjust The Air Shutter (Front Burner)

    AIR ShuTTeR ADjuSTMeNT (NATuRAL GAS ONLy) VC41LDVI/VC41CDVI Gas Fireplace Insert ADjuST The AIR ShuTTeR (FRONT BuRNeR) VC41LDVI ONLy The venturi of the front burner is equipped with an air 3. Remove four (4) screws holding burner in place and shutter. The opening of the venturi has been set at 1/4" for slide burner to the left and up and out of unit, allowing Natural Gas and fully open for Propane installation at sea access to venturi air shutter.
  • Page 29: (Vc41Ldvi Only) Adjust The Air Shutter (Rear Burner)

    AIR ShuTTeR ADjuSTMeNT (NATuRAL GAS ONLy) VC41LDVI/VC41CDVI Gas Fireplace Insert ADjuST The AIR ShuTTeR (ReAR BuRNeR) VC41LDVI ONLy This unit is equipped with a rear burner manual slide adjustable air shutter for natural gas. Locate the slide adjustment lever on the front lower left portion of the log support bracket, just below the horizontal grate bar.
  • Page 30: Signature Command System Operation

    SIGNATuRe COMMAND SySTeM OPeRATION INSTRuCTIONS VC41LDVI/VC41CDVI Gas Fireplace Insert To Thermopile RF Receiver FeATuReS ON/OFF To Sensor Command Center To Sparker • Easy Access Function Operation and System Configura- tion NG/LP Conversion • Operation Confirmation/Fault Diagnostic Indications (LED/Buzzer) • ON/OFF/HI/Med/Low Operation To Command Center Control •...
  • Page 31 SIGNATuRe COMMAND SySTeM OPeRATION INSTRuCTIONS VC41LDVI/VC41CDVI Gas Fireplace Insert NOTe: By disabling this feature, your fireplace may con- SySTeM CONFIGuRATION/SeTuP tinue to operate unattended. All System configuration/setup is done on the Command 2. When the master switch is in the ON position (“-”), press- Center.
  • Page 32 SIGNATuRe COMMAND SySTeM OPeRATION INSTRuCTIONS VC41LDVI/VC41CDVI Gas Fireplace Insert FuNCTIONS/OPeRATION (with Command 3. The third press on OFF will turn off the main burner. In Center) standing pilot configuration, the pilot will stay; in inter- mittent pilot configuration, the pilot will be shut off. Turning on the fireplace Turning the Fireplace Off 1.
  • Page 33: Touch Screen Remote Control Operation

    TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert Due to the sensitive temperature monitoring components in the transmitter, it is necessary to allow the transmitter to stabilize to room tem- perature before accurate room temperatures are displayed. If the transmitter is activated from a severe cold condition, allow 15 minutes for accurate temperature readings to appear on the LCD display.
  • Page 34 TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert Setting Privacy Code on Transmitter: Master Switch Figure 38 The remote transmitter privacy code is preset in factory. In the event of activation or interference from other nearby transmissions, change the code using the following procedures (learn function must be performed after changing the code):...
  • Page 35 TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert b. Use the OFF/down buttons to decrease the Set THERMO, LIGHT, FAN, AUX) are pressed and flashing. Time to zero Or 1. Press the ON/up button to turn c. Slide down on the arrow buttons to exit TIMER on the fireplace.
  • Page 36 TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert the flame height according to the difference between the effect right away; if the fireplace is off, the receiver will Set temperature and the Room temperature. There is no remember this setting and the blower is still off (see manual flame height adjustment.
  • Page 37 TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert 3. Press the light button again to confirm the setting. The n Safety Features new setting will be transmitted to the receiver. 1. Low Battery Detection 4. After the signal is sent, the On/up and Off/down but- When low battery condition occurs, the transmitter will tons become flame height controller again.
  • Page 38 TOuCh SCReeN ReMOTe CONTROL OPeRATION VC41LDVI/VC41CDVI Gas Fireplace Insert n using the Mounting Base The transmitter comes with a mounting base which allows you to hang the transmitter on the wall. 1. Secure the mounting base on the wall with supplied screws.
  • Page 39: Cleaning And Maintenance

    CLeANING and MAINTeNANCe VC41LDVI/VC41CDVI Gas Fireplace Insert Make sure the master switch on the command center is FIReBOx CLeANING in the “OFF” position. Wait at least five (5) minutes before 1. Carefully remove log set, and embers or decorative starting maintenance. Refer to Operating Instructions on glass from combustion chamber.
  • Page 40: Yearly Service Procedure

    MAINTeNANCe VC41LDVI/VC41CDVI Gas Fireplace Insert yeARLy SeRVICe PROCeDuRe Sensor Failure to inspect and maintain heater may lead to improper combustion and a potentially dangerous situation. A quali- fied technician should do the following once a year. Thermopile Signature 1. Check pilot flame. Flame should touch approximately Command 3/8"...
  • Page 41: Troubleshooting

    TROuBLeShOOTING VC41LDVI/VC41CDVI Gas Fireplace Insert SIGNATuRe COMMAND SySTeM OPERATION FAULT ACTION DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about the control 8 seconds board are...
  • Page 42: Replacement Parts

    RePLACeMeNT PARTS VC41LDVI/VC41CDVI Gas Fireplace Insert 47, 48 4685 VC41LDVI parts 20304685...
  • Page 43 RePLACeMeNT PARTS VC41LDVI/VC41CDVI Gas Fireplace Insert Ref. Description Qty. VC41LDVINTSC VC41LDVIPTSC VC41CDVINTSC 1. Log #1 20304799 20304799 2. Log #2 20304800 20304800 3. Log #3 20304801 20304801 4. Log #4 20304802 20304802 5. Log #5 20304803 20304803 6. Log #6...
  • Page 44 RePLACeMeNT PARTS VC41LDVI/VC41CDVI Gas Fireplace Insert Fuel Conversion Kits Natural Gas to LP VC41LDVINTSC Kit # 40ICFPGK VC41CDVINTSC Kit # ICF40LPK Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
  • Page 45: Optional Accessories

    RePLACeMeNT PARTS VC41LDVI/VC41CDVI Gas Fireplace Insert 5 a,b 1 a,b 7 a,b,c 8 a,b,c 6 a,b,c Optional Accessories Ref. Description VC41LDVI Square Face - Textured Black ICF40SFTB Square Face - Iron Age ICF40SFIA Small, 3-sided Surround 5/8" Deep - Black ICF40S3FB Small, 3-sided Surround 2"...
  • Page 46: For Massachusetts Residents Only

    VC41LDVI/VC41CDVI Gas Fireplace Insert Massachusetts Residents Only — Please read and follow these special requirements NOTe ReGARDING VeNTeD PRODuCTS 2. Approved Carbon Monoxide Detectors. Each carbon This product must be installed by a licensed plumber or gas fitter monoxide detector as required in accordance with the above when installed within the Commonwealth of Massachusetts.
  • Page 47: Warranty

    (2) years from date of installation. After installation, if any of the components manufactured by Vermont Castings Group in the appliance are found to be defec- tive in materials or workmanship, Vermont Castings Group will, at its option, replace or repair the defective components at no charge to the original owner.
  • Page 48: Efficiencies

    68.66 VC41CDVINTSC 77.8 69.49 w/ Propane Conversion Recherchez dans la brochure les caractéristique de rendement énergétique de foyer au gaz Énerguide Based on CSA P.4.1-09 Selon CSA P.4.1-09 Vermont Castings Group 149 Cleveland Drive • Paris, Kentucky 40361 www.vermontcastingsgroup.com 20304685...
