5. Operation

※ Caution : When you are holding the handset while the hook switch is off and someone may push
the button of camera, you may lose your hearing because of high volume of calling sound.
1. Calling of visitor
The visitor
presses the
call button on
A chime
the camera
sounds
The display will be shown up
for 60 seconds and turned off
automatically
A view of the front door can be seen anytime the
monitoring button is pressed and a dialog can be
made with anyone at the front door.
2. Communication with the optional Interphone
* Call from the entrance
Dialog between the interphone and camera is possible only when the visitor's image is visible on the monitor screen.
A visitor
calls from
the entrance
* Conversation with monitor
Pick-up the
handset
The visitor' s
image appears
on the monitor
Dialog duration
60 seconds at
To
a time
check
A chime rings
simultaneously
from both the
monitor and
Dialog begins
interphone
Press
the call
"Tu-Tu-Tu"
button
Sound
Dialog begins
Ends the call
A three-way
conversation can take
place if the monitor or
End the dialog
interphone is
picked up
simultaneously
the handset
Dialog begins
Open the door
The door release function
operates only when the visitor' s
image is displayed on the screen
Hang-up the
handset
Open the door
Hang-up the
handset
Hang-up End the
dialog
5
