OWnEr'S ManUaL
ManUaL dEL USUariO
Vector Elite
TM
Please write model number here for future reference: /
Por favor, incluya el número del modelo aquí para futura referencia:
UL-ES-VectorElite-WH09
net Weight: 13.00 LBS
Peso neto:
5.9 KGS
MR

Advertisement

Table of Contents
loading

Related Manuals for Westinghouse Vector Elite UL-ES-VectorElite-WH09

Summary of Contents for Westinghouse Vector Elite UL-ES-VectorElite-WH09

  • Page 1 UL-ES-VectorElite-WH09 OWnEr'S ManUaL ManUaL dEL USUariO Vector Elite Please write model number here for future reference: / Por favor, incluya el número del modelo aquí para futura referencia: net Weight: 13.00 LBS Peso neto: 5.9 KGS...

  • Page 2: Safety Tips

    UL-ES-VectorElite-WH09 SafEty tiPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED "ACCEPTABLE FOR FAN SUPPORT", AND USE THE OUTLET SCREWS PROVIDED WITH THE OUTLET BOX. MOST OUTLET BOXES COMMONLY USED FOR THE SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND MAY NEED TO BE REPLACED.

  • Page 3: Consejos De Seguridad

    UL-ES-VectorElite-WH09 COnSEjOS dE SEGUridad HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O LESIONES PERSONALES, MONTE EL VENTILADOR EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES”, Y UTILICE LOS TORNILLOS DE MONTAJE INCLUIDOS CON LA CAJA DE EMBUTIR. LA MAYORÍA DE LAS CAJAS DE EMBUTIR UTILIZADAS NORMALMENTE PARA ARTEFACTOS DE ILUMINACIÓN NO SON ADECUADAS PARA VENTILADORES Y DEBERÍAN SER REEMPLAZADAS.

  • Page 4: Features Características

    UL-ES-VectorElite-WH09 fEatUrES CaraCtEríStiCaS DOWNROD VAULTED CEILING INSTALLATION INSTALLATION FLUSH MOUNT INSTALLATION INSTALACIÓN CON INSTALACIÓN PARA INSTALACIÓN AL RAS VARILLA VERTICAL CIELORRASOS ABOVEDADOS COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements your decor, or change the style with just a flip of the blade. For low ceilings For normal ceilings May require a longer downrod...
  • Page 5 UL-ES-VectorElite-WH09 PrEParinG fOr inStaLLatiOn antES dE La inStaLaCión Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
  • Page 6 UL-ES-VectorElite-WH09 MOUntinG BraCKEt inStaLLatiOn inStaLaCión COn SOPOrtE dE MOntajE Remove the screws and star washers from the two mating holes (1) on the canopy. Loosen (do not remove) the screws in the mating slots (2) on the canopy. Rotate the mounting bracket counter-clockwise and remove from the canopy. Quite los tornillos y las dos arandelas en estrella de los dos orificios coincidentes (1) del dosel.
  • Page 7 UL-ES-VectorElite-WH09 BLadE inStaLLatiOn MOUntinG BraCKEt inStaLLatiOn inStaLaCión COn SOPOrtE inStaLaCión dE LaS PaLEtaS dE MOntajE Install mounting bracket to outlet box in ceiling using the screws and washers provided with the outlet box. Install blade to blade bracket using three blade screws as shown. Instale el soporte de montaje a la caja de embutir del cielorraso con la Instale el aspa a la abrazadera para aspa usando tres tornillos para aspa tornillería suministrada con la caja de embutir.
  • Page 8 UL-ES-VectorElite-WH09 BLadE inStaLLatiOn MOUntinG OPtiOnS OPCiOnES dE MOntajE inStaLaCión dE LaS PaLEtaS Choose a MOUntinG OPtiOn Elija una OPCión dE MOntajE fLUSH MOUnt OPtiOn If flush mount option is selected, proceed to page 9, step 8. OPCión dE inStaLaCión aL raS Si elige la opción de montaje al ras, proceda a la página 9, paso 8.

  • Page 9: Flush Mount Option

    UL-ES-VectorElite-WH09 fLUSH MOUnt OPtiOn OPCión dE inStaLaCión aL raS For flush mount option, raise fan assembly and place onto hook from mounting bracket into a closed hole on the canopy. This will allow for hands free wiring. Guide motor wires through the base of the canopy as shown and attach canopy PrOCEEd dirECtLy tO PaGE 14 fOr WirinG OPtiOnS.
  • Page 10 UL-ES-VectorElite-WH09 nOrMaL dOWnrOd OPtiOn EXtEndEd dOWnrOd OPtiOn OPCión COn VariLLa OPCión COn VariLLa VErtiCaL Para CiELOrraSO nOrMaL VErtiCaL MÁS LarGa Feed motor lead wires through downrod/canopy assembly and insert downrod into downrod yoke. Make sure to align hole in downrod with the hole in downrod yoke. Install yoke cross pin (1) through yoke and downrod.
  • Page 11 UL-ES-VectorElite-WH09 EXtEndEd dOWnrOd OPtiOn OPCión COn VariLLa VErtiCaL MÁS LarGa Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod.
  • Page 12 UL-ES-VectorElite-WH09 EXtEndEd dOWnrOd OPtiOn OPCión COn VariLLa VErtiCaL MÁS LarGa Feed motor lead wires through downrod/canopy assembly and insert downrod into downrod yoke. Make sure to align hole in downrod with the hole in downrod yoke. Install yoke cross pin (1) through yoke and downrod. Insert clamp pin (2) into cross pin until it snaps into place. Tighten set screws (3) in yoke. Pase los hilos conductores del motor a través de la varilla vertical/conjunto del dosel e inserte la varilla vertical en la horquilla de la misma.
  • Page 13 UL-ES-VectorElite-WH09 MOUntinG MOntajE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the Levante con cuidado el conjunto del ventilador hasta el soporte de montaje.

  • Page 14: Wiring Options

    UL-ES-VectorElite-WH09 WirinG OPtiOnS OPCión dE CaBLEadO PULL CHain WirinG OPtiOn WaLL COntrOL WirinG OPtiOn From Fan: From House: From Fan: From House: White (common) Wall Control White (common) White (common) White (common) (connect) (connect) Black (hot) Black (hot) Black (hot) (connect) Fan Switch (hot) (connect)
  • Page 15 UL-ES-VectorElite-WH09 SECUrE tO CEiLinG aSEGUrE EL VEntiLadOr aL CiELOrraSO For flush mount fans, carefully lift fan from the mounting bracket, making sure not to break any wire connections. For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores de instalación al ras, levante con cuidado el ventilador del soporte de montaje asegurándose de que no interrumpa ninguna conexión de los cables. Para ventiladores con varilla vertical, deslice el dosel hacia arriba hasta el soporte de montaje.
  • Page 16 UL-ES-VectorElite-WH09 LiGHt fiXtUrE inStaLLatiOn inStaLaCión dEL artEfaCtO LUMinOSO Remove the spot head cover ring by twisting counterclockwise. Save it for later use. Install light bulbs. Quite el anillo de la cubierta de la lámpara direccional girando en sentido Instale las bombillas de luz. contrahorario.
  • Page 17 UL-ES-VectorElite-WH09 Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by Line up the "L" slot (1) with the dent on spot head (2), push the cover into the spot head and twist the cover clockwise.

  • Page 18: Operation And Maintenance

    UL-ES-VectorElite-WH09 OPEratiOn and MaintEnanCE Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse. Warm weather - (Forward) Fan turns counterclockwise direction.

  • Page 19: Operación Y Mantenimiento

    UL-ES-VectorElite-WH09 OPEraCión y MantEniMiEntO Operación Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 jalón – rápida; 2 jalones - mediana; 3 jalones - lenta; 4 jalones - apagado. Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc.

  • Page 20: Troubleshooting Guide

    UL-ES-VectorElite-WH09 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these trOUBLESHOOtinG GUidE installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, please consult with your authorized electrician and do not attempt any electrical repairs yourself.
  • Page 21 UL-ES-VectorElite-WH09 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos GUía Para SOLUCiOnar PrOBLEMaS casos, estos errores de instalación podrían ser confundidos con defectos. Si experimenta alguna falla, consulte esta guía para solucionar problemas.
  • Page 22 UL-ES-VectorElite-WH09...

  • Page 23: Parts List

    UL-ES-VectorElite-WH09 PartS LiSt LiSta dE rEPUEStOS description 1 ....Mounting Bracket 2 ....Blade Bracket 3 .
  • Page 24 Philadelphia, PA 19154 U.S.A. Philadelphia, PA 19154 U.S.A. Westinghouse Lighting Corporation, Westinghouse Lighting Corporation, a Westinghouse Electric Corporation licensee titular de la licencia de Westinghouse Electric Corporation is a registered trademark of es una marca registrada de Westinghouse Electric Corporation Westinghouse Electric Corporation...
