- Page 1 UL-ES-Elite-WH11 Owner's Manual Manual del usuariO Elite Please write model number here for future reference: / Por favor, incluya el número del modelo aquí para futura referencia: net weight: 15.4 Peso neto: 6.99...
-
Page 2: Safety Tips
UL-ES-Elite-WH11 safety tiPs OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED "ACCEPTABLE FOR FAN SUPPORT", AND USE THE OUTLET SCREWS PROVIDED WITH THE OUTLET BOX. MOST OUTLET BOXES COMMONLY USED FOR THE SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND MAY NEED TO BE REPLACED. -
Page 3: Consejos De Seguridad
UL-ES-Elite-WH11 COnsejOs de seGuridad HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O LESIONES PERSONALES, MONTE EL VENTILADOR EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES”, Y UTILICE LOS TORNILLOS DE MONTAJE INCLUIDOS CON LA CAJA DE EMBUTIR. LA MAYORÍA DE LAS CAJAS DE EMBUTIR UTILIZADAS NORMALMENTE PARA ARTEFACTOS DE ILUMINACIÓN NO SON ADECUADAS PARA VENTILADORES Y DEBERÍAN SER REEMPLAZADAS. -
Page 4: Features Características
UL-ES-Elite-WH11 features CaraCterístiCas DOWNROD VAULTED CEILING INSTALLATION INSTALLATION FLUSH MOUNT INSTALLATION INSTALACIÓN CON INSTALACIÓN PARA INSTALACIÓN AL RAS CIELORRASOS ABOVEDADOS VARILLA VERTICAL May require a longer downrod For low ceilings For normal ceilings (sold separately) Para cielorrasos bajos Para cielorrasos normales Podría requerir una varilla vertical más larga... -
Page 5: Preparing For Installation
UL-ES-Elite-WH11 PreParinG fOr installatiOn antes de la instalaCión Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble). -
Page 6: Mounting Bracket Installation
UL-ES-Elite-WH11 MOuntinG BraCKet installatiOn instalaCión COn sOPOrte de MOntaje Remove the screws and star washers from the two mating holes (1) on the canopy. Loosen (do not remove) the screws in the mating slots (2) on the canopy. Rotate the mounting bracket counter-clockwise and remove from the canopy. -
Page 7: Mounting Options
UL-ES-Elite-WH11 MOuntinG BraCKet installatiOn MOuntinG OPtiOns instalaCión COn sOPOrte OPCiOnes de MOntaje de MOntaje Choose a MOuntinG OPtiOn elija una OPCión de MOntaje flusH MOunt OPtiOn If flush mount option is selected, proceed to page 8, step 6. OPCión de instalaCión al ras Si elige la opción de montaje al ras,... - Page 8 UL-ES-Elite-WH11 flusH MOunt OPtiOn OPCión de instalaCión al ras For flush mount option, raise fan assembly and place onto hook from mounting bracket into a closed hole on the canopy. This will allow for hands free wiring. Guide motor wires through the base of the canopy as shown and attach canopy PrOCeed direCtly tO PaGe 13, steP 15 fOr wirinG OPtiOns.
- Page 9 UL-ES-Elite-WH11 nOrMal dOwnrOd OPtiOn eXtended dOwnrOd OPtiOn OPCión COn Varilla VertiCal OPCión COn Varilla Para CielOrrasO nOrMal VertiCal MÁs larGa Feed motor lead wires through downrod/canopy assembly and insert downrod into downrod yoke. Make sure to align hole in downrod with the hole in downrod yoke. Install yoke cross pin (1) through yoke and downrod.
- Page 10 UL-ES-Elite-WH11 eXtended dOwnrOd OPtiOn OPCión COn Varilla VertiCal MÁs larGa Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole.
- Page 11 UL-ES-Elite-WH11 eXtended dOwnrOd OPtiOn OPCión COn Varilla VertiCal MÁs larGa Feed motor lead wires through downrod/canopy assembly and insert downrod into downrod yoke. Make sure to align hole in downrod with the hole in downrod yoke. Install yoke cross pin (1) through yoke and downrod. Insert clamp pin (2) into cross pin until it snaps into place. Tighten set screws (3) in yoke.
- Page 12 UL-ES-Elite-WH11 MOuntinG MOntaje Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the Levante con cuidado el conjunto del ventilador hasta el soporte de montaje.
-
Page 13: Wiring Options
UL-ES-Elite-WH11 wirinG OPtiOns OPCión de CaBleadO Pull CHain wirinG OPtiOn wall COntrOl wirinG OPtiOn Follow diagram above to make wiring connections for fan pull chain control. Follow diagram above to make wiring connections for wall control operation. OPCión de CaBleadO Para COntrOl de Pared OPCión de CaBleadO Para Cadenilla de tirO... -
Page 14: Secure To Ceiling
UL-ES-Elite-WH11 seCure tO CeilinG aseGure el VentiladOr al CielOrrasO For flush mount fans, carefully lift fan from the mounting bracket, making sure not to break any wire connections. For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores de instalación al ras, levante con cuidado el ventilador del soporte de montaje asegurándose de que no interrumpa ninguna conexión de los cables. -
Page 15: Blade Installation
UL-ES-Elite-WH11 Blade installatiOn instalaCión de las Paletas Check the motor for plastic shipping stabilizer tabs and remove them if they are present. Attach blade assembly to motor using the noise-dampening motor gaskets (1) and motor screws (2) provided. Tighten screws securely. -
Page 16: Light Fixture Installation
UL-ES-Elite-WH11 liGHt fiXture installatiOn instalaCión del artefaCtO luMinOsO Attach light kit to the switch housing using three small screws and star washers provided. Remove the screws (1) from the light kit (2). Find the two wires from the switch Removed in step 20. - Page 17 UL-ES-Elite-WH11 Remove the spot head cover ring by twisting counterclockwise. Install GU10 light bulbs Re-install the spot head cover ring by twisting clockwise. (1), 50 watts maximum. (included) WARNING: 1. Do not allow spot light heads to face each other.
- Page 18 UL-ES-Elite-WH11 Assemble decorative fob and extension chains from hardware bag to fan pull chains by inserting end of chain into chain coupling. Confirm chains are held by lightly pulling both chains in coupling. Sujetar las cadenas largas de tiro con las piezas finales correspondientes, a las cadenas del ventilador, introduciendo el extremo de la cadena larga en la pieza de unión.
-
Page 19: Operation And Maintenance
UL-ES-Elite-WH11 OPeratiOn and MaintenanCe Operation Turn on the power and check operation of fan. The pull chain controls the fan speeds as follows: 1 pull - high; 2 pulls - medium; 3 pulls - low; 4 pulls - off. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. -
Page 20: Operación Y Mantenimiento
UL-ES-Elite-WH11 OPeraCión y ManteniMientO FUNCIONAMIENTO Encienda el ventilador y verifique su funcionamiento. La cadenilla de tiro controla las velocidades del ventilador de la siguiente manera: 1 tirón – rápida; 2 tirones – mediana; 3 tirones – lenta; 4 tirones – apagado. -
Page 21: Troubleshooting Guide
UL-ES-Elite-WH11 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some trOuBlesHOOtinG Guide cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting chart. -
Page 22: Guía Para Solucionar Problemas
UL-ES-Elite-WH11 Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación Guía Para sOluCiOnar PrOBleMas o cableado incorrectos. en algunos casos, estos errores de instalación podrían ser confundidos con defectos. Si experimenta alguna falla, consulte esta guía para solucionar problemas. Si no puede solucionar el problema, consulte a un electricista autorizado y no intente reparar conexiones eléctricas. - Page 23 UL-ES-Elite-WH11...
- Page 24 Philadelphia, PA 19154 U.S.A. Philadelphia, PA 19154 U.S.A. Westinghouse Lighting Corporation, Westinghouse Lighting Corporation, titular de la licencia de Westinghouse Electric Corporation a Westinghouse Electric Corporation licensee es una marca registrada de is a registered trademark of Westinghouse Electric Corporation...
