Item
Description
L2TP Server IP
Allow user to make a tunnel with remote site directly to secure the data
Address
transmission among the connection. User can use embedded L2TP client
supported by this router to make a VPN connection.
If you select the L2TP support on WAN interface, fill in the IP address for it.
User Name
Fill in the user name and password to login the L2TP server.
Password
Fill in the user name and password to login the L2TP server.
Address Mode
Static: To configure the IP address information by manually, please fill in the
related setting at below.
Dynamic: The option allows the machine to get IP address information
automatically from DHCP server on WAN side.
IP Address
Fill in the IP address for WAN interface.
Subnet Mask
Fill in the subnet mask for WAN interface.
Default Gateway
Fill in the default gateway for WAN interface out going data packets.
Keep Alive: Keep the L2TP connection all the time. Please also configure the
Operation Mode
Redial Period field.
Manual: Let user connect the L2TP connection manually.
When you finish these settings, then click Next button to jump at Step2.
e. PPTP
If you select PPTP, please fill in these fields on next page.
- 20 -
