Yaesu FTM-7250DR Technical Supplement page 3

REF. YAESU P/N
①
U20306007 BINDING HEAD SCREW M3X6B
②
U24308001 BIND HEAD TAPTITE-B M3X8
③ U03310002 SEMS SCREW ASM3X10NI
④
RA6075900 STUD
⑤
U20318007 BINDING HEAD SCREW M3X18B
⑥ U24208001 BIND HEAD TAPTITE-B M2.6X8
⑦
U9900310 RAMIMATE M2.6X6(3KA)
Non-designated parts are available only as part of a designated assembly.
Accessories
YAESU P/N
T90217152 DC Power Cable
T9026115 DC Power Cable (European Version)
Q0000151 Fuse (15 A)
Q0000172 Fuse (15 A, European Version)
RA607080A Mobile Mounting Bracket
T9101606 USB Cable
G6090246
LCD
RA6070500
LCD SPACER
RA6185400
RUBBER KNOB
CQ0897001
PANEL ASSY
RA606950A
VOLUME KNOB(ASSY)
RA6088100
RA6185100
REFLECTOR SHEET(LED)
LIGHT GUIDE(LED)
RA606930A
ENCODER KNOB(ASSY)
Description Qty.
3
14
3
1
4
5
5
Description
RA0208800
COIL SPRING(SP)
RA6070600
INTER CONNECTOR
RA6070100
REFLECTOR
RA6185300
RUBBER KNOB
RA6185700
FRONT PANEL ASSY
①
②
②
RA6089100 ②
SPONGE RUBBER(10X15)
②
CS2660701
DSP ASSY
②
MAIN Unit
④
②
②
T9207248
FW-ASSY
⑥
⑥
⑥
⑥
⑥
⑥
PANEL Unit
⑦
RA6070700
SPACER(SP)
⑦
M4090262
SPEAKER
EXPLODED VIEW-1
Exploded View & Miscellaneous Parts
①
RA606920A
COVER
① CS2558703 (TYP A2)
CS2558704 (TYP B2)
CS2558705 (TYP B3)
② MAIN-1 ASSY
T9207482 (CE OFF)
T9207483 (CE ON)
WIRE ASSY
③
②
②
RA6203300
②
SHIELD CASE COVER
②
RA6062400
ThermalConductivePad
②
②
③
M2090060A
③
FAN
P1091172A
CONNECTOR
RA6061700
RUBBER(FAN)
RA606890A (Lot. 1-12)
RA606890C (Lot. 13-)
CHASSIS
RA609420A
BLIND SHEET(5X110)
RA6105500
BLIND SHEET(5X70)
RA6069100
RUBBER PACKING
⑦
RA6069000
COVER(CHASSIS)
⑦
⑦
⑤
⑤
⑤
⑤
S5000288
FAN GUARD
FTM-7250DR/DE Technical Supplement
