- Page 1 Hooptie & snackbar MANUAL 2021...
- Page 2 Possible Hooptie rail and SnackBars configurations Two Hooptie rails One Hooptie rail, front and rear SnackBars Best for young passengers who might need additional help in Best for children who are able to get on and off the bike on staying contained on the rear deck.
-
Page 3: Parts Diagrams
Front bracket Rear bracket Rail insertion Rail insertion Rail boss point point Rail boss Installation Installation bracket bracket Hooptie rail SnackBar (Both Hooptie rails are identical) (All SnackBars are indentical) Outer rail Padded handrail Inner padded rail Insertion end Insertion end... -
Page 4: Installing The Brackets
installing the brackets Tools needed Hardware included 5 mm Allen wrench (4) M6 X 35 mm bolts (4) flat washers (shown here already installed on the bolts) 03 A 03 B To install the brackets, you need access to the crossbars Paying careful attention to whether you are installing the front located on the underside of the RearRack of your bike. - Page 5 Repeat steps 03 B - 03 D for the other bracket if applicable. You If you are installing Hooptie rails: are now ready to install the Hooptie rails or SnackBars. Do not fully tighten down the bolts after step 03 D. You want them to be a little loose to allow for some tolerance when installing the rails.
- Page 6 (4) spring washers (shown here already installed on the bolts) Please note: 04 A On each insertion end on the Hooptie rails there are two With the brackets still loose, take one Hooptie rail and slide etched markings encircling the rail tubing. These indicate the insertion end into the front and rear bracket at the same the two insertion settings: narrow and wide.
- Page 7 04 C Place a spring washer on one of the M5 x 28 mm bolts. Once your Hooptie rail or rails are installed, use a 5 mm Allen Thread the bolt by hand through the boss on the Hooptie wrench to tighten down the bolts under the brackets. Tighten bracket.
- Page 8 installing snackbars Tools needed Hardware included 4mm Allen wrench (2) M5 x 28mm ultra low socket pointed bolts (2) spring washers 05 A 05 B Take your SnackBar and slide the insertion rail into the Place a spring washer on one of the M5 x 28 mm bolts. bracket.
-
Page 9: Care And Maintenance
All bolts are pre-treated with a threadlocker but over time, this can wear away. For this reason, check the tightness of the bolts on the Hooptie rails and SnackBars often. If you are noticing bolts rattling loose, you can use a few drops of a removable threadlocker like Loctite on the thread of the bolts to prevent this.
