Longtail CargoBay
Installation Manual
Use this manual for installation
of a X3 series CargoBay on
your Edgerunner, Stoker or Leap
Installing the X3 CargoBay
1
Clip the four upper buckles around the top of the V-Rack.
3
Position the four Ladder Locks facedown as shown. For
EdgeRunners use the #2 position for the two outside
Locks and #3 potition for the two inside. On Stoker and
Leap models you may have to adjust these at Step 5.
2
Clip each of the two side buckles around the corners of
the V-Rack. The forward buckle should loop below the
Wedding Rings (shown in Step 5). Do not tighten yet.
4
Install the hook-and-loop straps through the two outer
ladder loops. On EdgeRunner models, use the #1 opening.
On Leap & Stoker models use the loop at the center of
the V-Rack depending on the height of the V-Rack
Advertisement
Related Manuals for Xtracycle Longtail CargoBay X3 Series
Summary of Contents for Xtracycle Longtail CargoBay X3 Series
- Page 1 Longtail CargoBay Installation Manual Use this manual for installation of a X3 series CargoBay on your Edgerunner, Stoker or Leap Installing the X3 CargoBay Clip the four upper buckles around the top of the V-Rack. Clip each of the two side buckles around the corners of the V-Rack.
- Page 2 Longtail CargoBay Installation Manual, Continued Center the CargoBay on the V-Rack and pull the hook- Wrap the nylon webbing attached to the forward and and-loop straps taut around the two uprights of the rear Ladder Locks around the back side of the lower bike V-Rack.
