- Page 1 Freezer User manual Congelateur Guide d’utilisation Congelatore Istruzioni per l'uso ZACV283NX...
-
Page 3: Table Of Contents
Index BEFORE USING YOUR FREEZER .............2 SAFETY INSTRUCTIONS ..............2 General Safety Warnings ................2 During Usage ....................6 Installation warnings ..................7 Before using your freezer ................8 Information on No-Frost technology ............8 USAGE INFORMATION ...............9 Warnings about temperature adjustments ..........11 Accessories .................... -
Page 4: Before Using Your Freezer
SAFETY INSTRUCTIONS General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • This appliance is intended to be used in household and domestic applications such as: - staff kitchen areas in shops, offices and other working environments.
- Page 6 use appliances safely after they have been given appropriate supervision or instruction concerning use of the appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision is given. • If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service agent or similar qualified persons, in order to avoid a hazard.
- Page 7 Old and Out-of-order Fridges • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.
-
Page 8: During Usage
During Usage • Do not connect your freezer to the mains electricity supply using an extension lead. • Do not use damaged, torn or old plugs. • Do not pull, bend or damage the cord. • Do not use plug adapter. •... -
Page 9: Installation Warnings
Installation warnings Before using your freezer for the first time, please pay attention to the following points: • The operating voltage for your freezer is 220-240 V at 50Hz. • The plug must be accessible after installation. • Your freezer may have an odour when it is operated for the first time. This is normal and the odour will fade when your freezer starts to cool. -
Page 10: Before Using Your Freezer
Before using your freezer • When using your freezer for the first time, or after transportation, keep it in an upright position for at least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the compressor. •... -
Page 11: Usage Information
USAGE INFORMATION 1.1 Display and Control Panel 1. It is super freeze indicator. 2. It is freezer set value screen. 3. Sr alarm indicator. 4. Freezer set button. 1.1.1 Using the Control Panel Freezer Set Button The freezer set button allows changes to be made to the temperature of the freezer compartment. - Page 12 • To freeze fresh food quickly to retain freshness. Activating Super Freezer Mode Push the freezer set button until the super freezer symbol ( ) illuminates. The buzzer will sound twice and the mode will be set. During Super Freeze Mode Super freeze mode can be cancelled in the same way it is selected.
-
Page 13: Warnings About Temperature Adjustments
• If you press the freezer set button until the super freeze symbol ( ) appears on the freezer setting indicator, and do not press any buttons for 1 second, super freeze will flash. • If you continue to press the same button, it will restart from -16 °C. Recommended Temperature Values for Freezer When to adjust Inner Temperature (... -
Page 14: Accessories
Accessories Making Ice Cubes (In some models) • Pull the lever towards you and remove the ice maker tray • Fill with water to the level of line • Hold the left end of the lever and set the ice-tray on the icebox •... - Page 15 possible time. • If a package of frozen food shows signs of humidity and abnormal swelling it is probable that it has been previously stored at an unsuitable temperature and that the contents have deteriorated.. • The storage life of frozen foods depends on the room temperature, thermostat setting, how often the door is opened, the type of food and the length of time required to transport the product from the shop to your home.
- Page 16 Thawing time in Maximum Storing Thawing time in oven room temperature time (months) (minutes) (hours) Bread 4 - 6 2 - 3 4-5 (220-225 °C) Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C) Pastry 1 - 3 2 - 3 5-10 (200-225 °C) 1 - 1,5 3 - 4...
- Page 17 Maximum Vegetables and Fruits Preparation Storing time (months) Wash and cut into small pieces and boil in String beans and beans 10 - 13 water Beans Hull and wash and boil in water Cabbage Cleaned and boil in water 6 - 8 Carrot Clean and cut to slices and boil in water Cut the stem, cut into two pieces, remove...
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Disconnect the unit from the power supply before cleaning. • Do not clean the appliance by pouring water. • Make sure that no water enters the lamp housing and other electrical components. • The freezer should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. -
Page 19: Transportation And Changing Of Installation Position
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION • The original packages and foamed polystyrene (PS) can be retained if required. • During transportation, the appliance should be secured with a wide string or a strong rope. The instructions written on the corrugated box must be followed while transporting. •... - Page 20 • There is enough place at the rear and side walls. Your freezer is operating noisily Normal noises Cracking (ice cracking) noise occurs: • During automatic defrosting • When the appliance is cooled or warmed (due to expansion of appliance material). Short cracking noise occurs: When the thermostat switches the compressor on/off.
- Page 21 1 TIPS FOR SAVING ENERGY 1. Install the appliance in a cool, well-ventilated room, but not in direct sunlight and not near a heat source (such as a radiator or oven) otherwise an insulating plate should be used. 2. Allow warm food and drinks to cool before placing them inside the appliance. 3.
-
Page 22: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS This appliance is not intended to be used as a built-in appliance. In some models there is a shelf with icematic in the top basket. This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. - Page 23 Dimensions Overall dimensions 1860 the height, width and depth of the appliance without the handle. Overall space required in use 710,6 Space required in use 1243,5 2010 the height, width and depth of the appliance including the handle, plus the space necessary for free 752,5 circulation of the cooling air, plus the height, width and depth of the...
-
Page 24: Technical Data
TECHNICAL DATA The technical information is situated in the rating plate on the internal side of the appliance and on the energy label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
