Summary of Contents for John Lewis JLBIIH615
- Page 1 JLBIIH615 User Manual...
-
Page 2: Table Of Contents
Contents Power management function Safety information Hints and tips Children and vulnerable people safety General Safety Cookware The noises during operation Safety instructions Examples of cooking applications Installation Care and cleaning Electrical Connection General information Care and cleaning Cleaning the hob Disposal Troubleshooting Service... -
Page 3: Safety Information
Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 Do not operate the appliance by means of an external timer or • separate remote-control system. WARNING: Unattended cooking on a hob with fat or oil can be • dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the •...
-
Page 5: Safety Instructions
Safety instructions • All electrical connections should be made by a Installation qualified electrician. • The appliance must be earthed. Warning! Only a qualified • Before carrying out any operation make sure person must install this that the appliance is disconnected from the appliance. -
Page 6: Use
• The electrical installation must have an isolation • Do not put flammable products or items that device which lets you disconnect the appliance are wet with flammable products in, near or on from the mains at all poles. The isolation device the appliance. -
Page 7: Service
• Contact your municipal authority for information on how to discard the appliance correctly. • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to the appliance and dispose of it. Service • To repair the appliance contact an Authorised Service Centre. -
Page 8: Product Description
Product description Cooking surface layout 1. Induction cooking zone 2. Control panel Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Hob User Manual... -
Page 9: Heat Setting Displays
Sensor Function Comment field ON / OFF To activate and deactivate the hob. Lock / The Child Safety Device To lock / unlock the control panel. STOP+GO To activate and deactivate the function. Bridge To activate and deactivate the function. Heat setting display To show the heat setting. -
Page 10: Residual Heat Indicator
Residual heat indicator Warning! There is a risk of burns from residual heat. The induction cooking zones make the heat necessary for cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware. Hob User Manual... -
Page 11: Daily Use
Daily use Warning! Refer to Safety Heat setting The hob deactivates chapters. after 4 hours Activating and deactivating 6 - 9 1.5 hour Touch for 1 second to activate or deactivate the hob. The heat setting Automatic Switch Off To set or change the heat setting: Touch the control bar at the correct heat setting The function deactivates the hob or move your finger along the control bar until... -
Page 12: Automatic Heat Up
First set the heat setting for one of the cooking To activate the function for a cooking zones. zone: touch comes on. To activate the function for left / right To deactivate the function: change the heat cooking zones: touch . -
Page 13: Stop+Go
time comes to an end, the sound operates and To deactivate the function: activate the hob 00 flashes. with . Do not set the heat setting. Touch for 4 seconds. comes on. Deactivate the hob To stop the sound: touch with The function has no effect on the To override the function for only one... -
Page 14: Hints And Tips
Hints and tips smaller diameter than the minimum receives Warning! Refer to Safety only a part of the power generated by the chapters. cooking zone. Refer to “Technical information” Cookware chapter. For induction cooking zones a The noises during operation strong electro-magnetic field creates the heat in the cookware If you can hear:... - Page 15 Heat setting Use to: Time Hints (min) Keep cooked food warm. as neces- Put a lid on the cookware. sary 1 - 2 Hollandaise sauce, melt: butter, choc- 5 - 25 Mix from time to time. olate, gelatine. 1 - 2 Solidify: fluffy omelettes, baked eggs.
-
Page 16: Care And Cleaning
Care and cleaning Warning! Refer to Safety chapters. General information • Clean the hob after each use. • Always use cookware with clean bottom. • Scratches or dark stains on the surface have no effect on how the hob operates. •... -
Page 17: Troubleshooting
Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Remedy You cannot activate or operate the The hob is not connected to an Check if the hob is correctly con- hob. electrical supply or it is connected nected to the electrical supply. - Page 18 Problem Possible cause Remedy The highest heat setting is set. The highest heat setting has the same power as the function. The heat setting changes between Power management function oper- Refer to "Daily use" chapter. two levels. ates. The sensor fields become hot. The cookware is too large or you Put large cookware on the rear put it too near to the controls.
-
Page 19: If You Cannot Find A Solution
If you cannot find a solution... If you cannot find a solution to the problem yourself, contact your dealer or an Authorised Service Centre. Give the data from the rating plate. Give also three digit letter code for the glass ceramic (it is in the corner of the glass surface) and an error message that comes on. -
Page 20: Installation
Installation Built-in hobs Warning! Refer to Safety chapters. Only use the built-in hobs after you assemble the hob into correct built-in units and work surfaces that align to the standards. Before the installation Connection cable Before you install the hob, write down the information bellow from the rating plate. - Page 21 min. 2 mm min. 2 mm < 20 mm > 20 mm min. 500 mm min. 500 mm 30 mm 12 mm 57 mm 12 mm 57 mm 28 mm 41 mm 28 mm 41 mm 38 mm 31 mm 38 mm 31 mm min.
-
Page 22: Protection Box
Protection box If you use a protection box (an additional accessory), the front airflow space of 2 mm and the protective floor directly below the hob are not necessary. The protection box accessory may not be available in some countries. Please contact your local supplier. -
Page 23: Technical Data
Technical data Rating plate Model JLBIIH615 PNC 949 594 425 00 Typ 60 GAD EA AU 220 - 240 V 50 - 60 Hz Induction 7.4 kW Made in Germany Ser.Nr....7.4 kW JOHN LEWIS Cooking zones specification Cooking zone... -
Page 24: Energy Efficiency
Energy efficiency Product information according to EU 66/2014 Model identification JLBIIH615 Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cooking Left front 21.0 cm zones (Ø) Left rear 21.0 cm Right front 21.0 cm Right rear 21.0 cm... -
Page 25: Repairs - After Sales Service
John Lewis, Liverpool 0151 709 7070 them here: John Lewis, Milton Keynes 01908 679 171 • Mod........John Lewis, Newcastle upon Tyne 0191 232 5000 • P.N.C........John Lewis, Norwich 01603 660 021 • S.N......... John Lewis, Nottingham 0115 941 8282... - Page 26 John Lewis, Stratford 020 8532 3500 John Lewis, Croydon 020 8662 4730 John Lewis, The Trafford Centre 0161 491 4040 John Lewis, Horsham 01403 214 740 John Lewis, Watford 01923 244 266 John Lewis, Ipswich 01473 275 850 John Lewis, Welwyn 01707 323 456...
- Page 27 ENVIRONMENTAL CONCERNS marked with the symbol with the household Recycle the materials with the symbol . Put waste. Return the product to your local the packaging in applicable containers to recycle recycling facility or contact your municipal office. it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances.
- Page 28 867333152-A-042017 ( Subject to change without notice. )
