Summary of Contents for John Lewis JLBICH602
- Page 1 JLBICH602 Ceramic hob Instruction manual 822 925 327-A-270705-03...
- Page 2 Dear Customer, Please read these user instructions carefully and keep them to refer to later. Please pass the user instructions on to any fu- ture owner of the appliance. The following symbols are used in the text: Safety instructions Warning! Notes that concern your personal safety.
-
Page 3: Table Of Contents
Contents Operating Instructions ..Safety instructions....Description of the Appliance ..Cooking surface layout ....Control panel layout . -
Page 4: Operating Instructions
Operating Instructions Safety instructions General safety Please comply with these instructions. If you do not, any damage caused to the • The appliance may only be installed and appliance will not be covered by the connected by trained, registered service warranty. - Page 5 Safety when cleaning • For cleaning, the appliance must be switched off and cooled down. • For safety reasons, the cleaning of the ap- pliance with steam jet or high-pressure cleaning equipment is not permitted. How to avoid damage to the appliance •...
-
Page 6: Description Of The Appliance
Description of the Appliance Cooking surface layout Single cooking zone Single cooking zone 1200W 1800W Control panel Single cooking zone Single cooking zone 2300W 1200W Control panel layout Cooking zones and heat setting selection Display On/Off... -
Page 7: Touch Control Sensor Fields
Touch Control sensor by touching sensor fields and confirmed by displays. fields Touch the sensor fields from above, without covering other sensor fields. The appliance is operated using the Touch Control sensor fields. Functions are controlled Sensor field Function On / Off Switches appliance on and off Increase settings Select cooking zone... -
Page 8: Operating The Appliance
Operating the appliance Switching the appliance on and off Control panel Display ¾ Switch on Touch for 2 seconds. / Decimal point flashes Switch off Touch for 1 second / none Selecting the cooking zone Control panel Display ¾ Select Touch Decimal point illuminates The decimal point is displayed by the... -
Page 9: Using The Child Safety Device
Using the child safety device The child safety device prevents unintentional use of the appliance. Setting the child safety device Step Control panel Display ¾ Switch on appliance (Do not set a (if hot) heat setting) ¾ Touch of the front right cooking zone at the same time Decimal points flash of the front right cooking zone l... -
Page 10: Overriding The Child Safety Lock
Overriding the child safety lock The child safety device can be released in this way for a single cooking session; it remains ac- tivated afterwards. Step Control panel Display Switch on the appliance (if hot) ¾ Touch of the front right cooking Decimal points flash zone and at the same time... -
Page 11: Safety Cut-Out
Safety cut-out Cooking surface • If after switching on the appliance a heat setting is not set for a cooking zone within approx. 10 seconds, the appliance automat- ically switches itself off. • If one or more sensor fields are touched for longer than approx. -
Page 12: Tips On Cooking And Frying
Tips on cooking and frying Information about acryla- Switch cooking zones off before the end of the cooking time, to take advan- mides tage of residual heat. According to the latest scientific re- search, intensive browning of food, es- pecially in products containing starch, may present a health risk due to acryla- mide. -
Page 13: Examples Of Cooking Applications
Examples of cooking appli- cations The information given in the following table is for guidance only. Heat Cooking suitable for Cook time Tips/Hints setting process Residual heat setting, Off posi- tion Keeping Keeping cooked foods warm as required Cover food warm Hollandaise sauce, Melting melting butter, chocolate, gela-... -
Page 14: Cleaning And Care
Cleaning and care Take care! Risk of burns from residual heat. Important Sharp objects and abrasive cleaning materials will damage the appli- ance. Clean with water and washing up liquid. Important Residues from cleaning agents will damage the appliance. Re- move residues with water and washing up liquid. - Page 15 Removing deposits 1. Place the scraper on the glass ceramic sur- face at an angle. 2. Remove residues by sliding the blade over the surface. 3. Wipe the appliance with a damp cloth and a little washing up liquid. 4. Rub the appliance dry using a clean cloth. Remove imme- when the appliance has...
-
Page 16: Something Not Working
Something not working ... Problem Possible cause Remedy The cooking zones are not func- No cooking zone selected Select cooking zone within 10 tioning. seconds of switching on (Deci- mal point lights up) The cooking zones cannot be se- More than 10 seconds has passed Switch on the appliance again. -
Page 17: Installation Instructions
Installation Instructions • In the event of single-phase or two-phase Safety instructions connection, the appropriate mains cable of The laws, ordinances, directives and standards type H05BB-F Tmax 90° (or higher) must in force in the country of use are to be fol- be used. -
Page 18: Electrical Connection Diagram
Electrical Connection Dia- Sticking on the seal gram • Clean the worktop in the area of the cut- out section. For UK only: 230V...240V~ • Stick the one-sided self-adhesive sealing tape supplied all the way round the lower edge of the cooking surface along the out- er edge of the glass ceramic panel. -
Page 19: Assembly
Assembly... -
Page 23: Rating Plates
Rating Plates JLBICH602 949 591 900 PEE2019 230 V 50 Hz 6,5 kW John Lewis JLBICH602 949 592 457 PEE2019 230 V 50 Hz 6,5 kW John Lewis... -
Page 24: Disposal
Disposal Packaging material The packaging materials are environ- mentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materi- als in the appropriate container at your local waste disposal facilities. Old appliance The symbol on the product or on... -
Page 27: Service And Spare Parts
Service and Spare Parts In th event of your appliance requiring service, or if you wish to purchase spare parts, please contact our extended warranty administrators by telephoning: 0870 01 07887 They will give you details for your local Service Force Centre. - Page 28 John Lewis partnership 171 Victoria Street London SW1E 5NN www. johnlewis.com Subject to change without notice 822 925 327-A-270705-03...
