  • Page 1 User’s Manual FLXA21 2-Wire Analyzer FOUNDATION Fieldbus Communication IM 12A01A02-71E IM 12A01A02-71E 3rd Edition...

  • Page 2: Introduction

    • No part of the user’s manuals may be transferred or reproduced without prior written consent from YOKOGAWA. • YOKOGAWA reserves the right to make improvements in the user’s manuals and product at any time, without notice or obligation. • If you have any questions, or you find mistakes or omissions in the user’s manuals, please contact our sales representative or your local distributor.
  • Page 3 4: The universal mounting kit contains the pipe and wall mounting hardware (/U) and the panel mounting hardware (/PM). 5: Type “-CB”, “-CD”, “-CH”, “-EG” are intrinsic safety (IS). 6: Type “-DD” is nonincendive (NI). 7: Product registration is done by Yokogawa Taiwan Corporation as an importer in Taiwan. IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...

  • Page 4: Safety Precautions

    The product is provided on an “as is” basis. YOKOGAWA shall have neither liability nor responsibility to any person or entity with respect to any direct or indirect loss or damage arising from using the product or any defect of the product that YOKOGAWA can not predict in advance. IM 12A01A02-71E...
  • Page 5 FLXA21 • The FLXA21 should only be used with equipment that meets the relevant IEC, American, Canadian, and Japanese standards. Yokogawa accepts no responsibility for the misuse of this unit. • Don’t install “general purpose type” instruments in the hazardous area.
  • Page 6 Mark position of intrinsic safety The mark position of intrinsic safety is shown as follows FLXA21-D-P-D-CB-□1-NN-F-N-LA-N-NN (FOUNDATION Fieldbus) FLXA21-D-P-D-CD-□1-NN-F-N-LA-N-NN (FOUNDATION Fieldbus) FLXA21-D-P-D-DD-□1-NN-F-N-LA-N-NN (FOUNDATION Fieldbus) FLXA21-D-P-D-CH-□1-NN-F-N-LA-N-NN (FOUNDATION Fieldbus) FLXA21-D-P-D-EG-□1-NN-F-N-LA-N-NN (FOUNDATION Fieldbus) -F (FOUNDATION Fieldbus) -F (FOUNDATION Fieldbus) Type: -CB Type: -CD Type: -DD Type: -CH Type:-EG *1: This marking conforms to Intrinsic safety of IECEx. *2: This marking conforms to Intrinsic safety of ATEX.
  • Page 7 The instrument should be disposed of in accordance with local and national legislation/ regulations. Warranty and service Yokogawa products and parts are guaranteed free from defects in workmanship and material under normal use and service for a period of (typically) 12 months from the date of shipment from the manufacturer.
  • Page 8 No part of the online manual may be transferred, sold, distributed (including delivery via a commercial PC network or the like), or registered or recorded on video tapes. FLEXA, FLXA and SENCOM are trademarks or registered trademarks of Yokogawa Electric Corporation.

  • Page 9: Ce Marking Products

    CE marking products Authorised Representative in EEA The Authorised Representative for this product in EEA is Yokogawa Europe B.V. (Euroweg 2, 3825 HD Amersfoort, The Netherlands). n Identification Tag This manual and the identification tag attached on a packing box are essential parts of the product. Keep them together in a safe place for future reference.

  • Page 10: Table Of Contents

    Toc-1 FLXA21 2-Wire Analyzer FOUNDATION Fieldbus Communication IM 12A01A02-71E 3rd Edition CONTENTS Introduction ....................i Safety Precautions ..................iii CE marking products ................viii About FOUNDATION Fieldbus ..............1-1 Internal Structure of FLXA21 ................1-1 Logical Structure of Each BLOCK ..............1-2 1.3 Wiring System Configuration ................
  • Page 11 Toc-2 4.6.3 View Object ..................4-9 Explanation of Basic Items..............5-1 AI Function Block ....................5-1 5.1.1 Function Blocks .................. 5-1 5.1.2 MODE_BLK ..................5-1 5.1.3 CHANNEL ..................5-2 5.1.4 XD_SCALE/OUT_SCALE ..............5-2 5.1.5 L_TYPE ....................5-3 5.1.6 PV_FTIME ..................5-3 5.1.7 Alarm Priority ..................5-3 5.1.8 Alarm Threshold .................

  • Page 12: About Foundation Fieldbus

    FOUNDATION Fieldbus is a bi-directional digital communication protocol for field devices, which offers an advancement implementation technologies for process control systems and is widely employed by numerous field devices. FLXA21 FOUNDATION Fieldbus communication type employs the specification standardized by The FOUNDATION Fieldbus, and provides interoperability between Yokogawa devices and those produced by other manufacturers. FOUNDATION Fieldbus comes with software consisting of three AI function blocks, providing the means to implement flexible instrumentation system. For information on other features, engineering, design, construction work, startup and maintenance of FOUNDATION Fieldbus, refer to http://www.yokogawa.com/fbs/fbs-index.htm.

  • Page 13: Logical Structure Of Each Block

    <1. About FOUNDATION Fieldbus> Logical Structure of Each BLOCK System/network management VFD PD Tag Communication parameters Node address Function block execution schedule Function block VFD AI function block AI function block SENSOR AI function Transducer block block Sensor Block tag input Block tag Parameters...
  • Page 14 <1. About FOUNDATION Fieldbus> Korea Electromagnetic Conformity Standard Class A 한국 전자파적합성 기준 A급 기기　(업무용 방송통신기자재) 　이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다. RoHS: EN 50581: 2012 (Style 3.03 or newer) Installation altitude: 2000 m or less Category based on IEC 61010: I (Note 1)
  • Page 15 <1. About FOUNDATION Fieldbus> Item Description 'Type' in MS code United [Nonincendive] States (FM) Applicable Standard: Class 3600: 2011, Class 3611: 2004, Class 3810: 2005, NEMA 250: 2014 Certificate No: 3039632 Marking/Rating: NI CL I, DIV 2, GP ABCD ZN 2 IIC T4: for ambient temperature: -20 to 55°C Control Drawing:...

  • Page 16: Preparation

    Note: 1900 m is trunk + sum of Spurs (Max length type A cable) Yokogawa recommends the use of Type A. Usage of Type B and D is restricted. Yokogawa does not recommend the use of Type C. Table 2.2 Recommended length of Spur Cables...
  • Page 17 <2. Preparation> When using a SENCOM module When using a SENCOM module, you need to use the supplied cable clamp to fix the sensor cables in place. Attach the supplied cable clamp as shown in Figure 2.2. Sensor cable Cable cramp Figure 2.2 When using a SENCOM module DIP switches Figure 2.3 shows the DIP switches for setting the address and write protection. Normally, you do not have the change them from the default settings.

  • Page 18: Shielding And Grounding

    Neutral star-point bonding (English practice) Figure 2.4 Shield and grounding How to download DD for CFF If you do not have the DD or Capability file (CFF) files, you can download them from our web site. http://www.yokogawa.com/an/download/an-dl-fieldbus-001en.htm *: This address is subject to change without prior notice. If the above address cannot be accessed, consult your nearest sales office or the agency from which you purchased the product. IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 19 Blank Page...

  • Page 20: Getting Started

    FOUNDATION Fieldbus uses twisted pair wires. To meet the Electro Magnetic Interference standards a shielded twisted pair is obligated. Refer to Yokogawa when making arrangements to purchase the recommended equipment. Connect the devices as shown in Figure 3.1. Connect the terminators at both ends of the trunk, with a minimum length of the spur laid for connection.

  • Page 21: Host Setting

    <3. Getting started> CAUTION Connecting a FOUNDATION Fieldbus configuration tool to a loop with its existing host may cause communication data scrambles resulting in a functional disorder or a system failure. Host Setting To activate FOUNDATION Fieldbus, the following settings are required for the host. CAUTION Do not turn off the power immediately after setting. When the parameters are saved to the EEPROM, the redundant processing is executed for an improvement of reliability. If the power is turned off within 60 seconds after setting is made, the modified parameters are not saved and the settings may return to the original values.

  • Page 22: Bus Power On

    0x0403 “Field Diagnostics” function (refer to IM 01R01A15-01EN) is available on FLXA21-PH or FLXA21-SC DTM Revision 3.4.0.21 or later. The DTM corresponding to the above is included in Yokogawa Device DTM Library 5.2/Device Files R 3.5.2.8 or later. IM 12A01A02-71E...

  • Page 23: Reading The Parameters

    <3. Getting started> Reading the Parameters To read FLXA21 parameters, select the AI1 block of the FLXA21 from the host screen and read the OUT parameter. The current process value is displayed. Check that MODE_BLOCK of the function block and resource block is set to AUTO, and change the signal input and read the parameter again.

  • Page 24: Configuration

    <4. Configuration> Configuration This chapter contains information on how to adapt the function and performance of the FLXA21 to suit specific applications. Because two or more devices are connected to FOUNDATION Fieldbus, settings including the requirements of all devices need to be determined. Practically, the following steps must be taken. (1) Network design Determines the devices to be connected to FOUNDATION Fieldbus and checks the capacity of the power supply.

  • Page 25: Network Definition

    <4. Configuration> • Cable Used for connecting devices. Refer to “Fieldbus Technical Information” for details of instrumentation cabling. Provide a cable sufficiently long to connect all devices. For field branch cabling, use terminal boards or a connection box as required. First, check the capacity of the power supply. The power supply capacity must be greater than the sum of the maximum current consumed by all devices to be connected to FOUNDATION Fieldbus.

  • Page 26: Definition Of Combining Function Blocks

    <4. Configuration> To ensure stable operation of FOUNDATION Fieldbus, determine the operation parameters and set them to the LM devices. While the parameters in Table 4.2 are to be set, the worst-case values of all the devices to be connected to the same FOUNDATION Fieldbus must be used. Refer to the specification of each device for details. Table 4.2 lists FLXA21 specification values.

  • Page 27: Setting Of Tags And Addresses

    <4. Configuration> LIC100 FLXA21 FIC100 LI100 FLXA21 FI100 FC100 Figure 4.2 Example of Loop Connecting Function Block of Two FLXA21 with Other Instruments Macrocycle (Control Period) LI100 CAS_IN LIC100 BKCAL_OUT BKCAL_IN FIC100 FC100 FI100 BKCAL_IN BKCAL_OUT Communication Unscheduled Schedule Communication Scheduled Communication Figure 4.3 Function Block Schedule and Communication Schedule When the macrocycle is set to more than 4 seconds, set the following intervals to be more than 1% of the macrocycle.

  • Page 28: Communication Setting

    <4. Configuration> UNINITIALIZED (No tag nor address is set) Tag clear Tag setting INITIALIZED (Only tag is set) Address clear Address setting SM_OPERATIONAL (Tag and address are retained, and the function block can be executed.) Figure 4.4 Status Transition by Setting PD Tag and Node Address FLXA21 has a PD Tag and node address that are set upon shipment from the factory unless otherwise specified. To change only the node address, clear the address once and then set a new node address. To set the PD Tag, first clear the node address and clear the PD Tag, then set...
  • Page 29 <4. Configuration> Typical example is a human-machine interface (Client) to read data of a Function Block (Server). The Client sends a Read request to the Server and then the Server sends back the data to the Client. This communication is unscheduled and is handled during the unscheduled interval in the macrocycle.
  • Page 30 <4. Configuration> Table 4.4 VCR Static Entry Sub- Parameter Description index FasArTypeAndRole Indicates the type and role of communication (VCR). The following 3 types are used for FLXA21. 0x32: Server (Responds to requests from host.) 0x44: Source (Transmits alarm or trend.) 0x66: Publisher (Sends AI block output to other blocks.) FasDllLocalAddr...

  • Page 31: Function Block Execution Control

    <4. Configuration> 4.5.2 Function Block Execution Control According to the instructions given in Section 4.3, set the execution cycle of the function blocks and schedule of execution. Block Setting Set the parameter for function block VFD. 4.6.1 Link Object Link object combines the data voluntarily sent by the function block with VCR. The FLXA21 has 40 link objects.
  • Page 32 <4. Configuration> Table 4.8 Parameters for Trend Objects Sub- Parameter Description index Block Index Sets the leading index of the function block that takes a trend. Parameter Sets the index of parameters taking a trend by a value relative to the beginning Relative Index of the function block.
  • Page 33 4-10 <4. Configuration> Table 4.12 View Object for Resource Block View Relative Index Parameter ST_REV TAG_DESC STRATEGY ALERT_KEY MODE_BLK BLOCK_ERR RS_STATE TEST_RW DD_RESOURCE MANUFAC_ID DEV_TYPE DEV_REV DD_REV GRANT_DENY HARD_TYPES RESTART FEATURES FEATURE_SEL CYCLE_TYPE CYCLE_SEL MIN_CYCLE_T MEMORY_SIZE NV_CYCLE_T FREE_SPACE FREE_TIME SHED_RCAS SHED_ROUT FAULT_STATE SET_FSTATE CLR_FSTATE MAX_NOTIFY...
  • Page 34 4-11 <4. Configuration> View Relative Index Parameter SOFTDWN_COUNT SOFTDWN_ACT_AREA SOFTDWN_MOD_REV SOFTDWN_ERROR SOFTDWN_HISTORY SOFTDWN_HIST_INDEX COMPATIBILITY_REV CAPABILITY_LEV CAPABILITY_CONFIG WRITE_LOCK_LEVEL SI_CONTROL_CODES FD_VER FD_FAIL_ACTIVE FD_OFFSPEC_ACTIVE FD_MAINT_ACTIVE FD_CHECK_ACTIVE FD_FAIL_MAP FD_OFFSPEC_MAP FD_MAINT_MAP FD_CHECK_MAP FD_FAIL_MASK FD_OFFSPEC_MASK FD_MAINT_MASK FD_CHECK_MASK FD_FAIL_ALM FD_OFFSPEC_ALM FD_MAINT_ALM FD_CHECK_ALM FD_FAIL_PRI FD_OFFSPEC_PRI FD_MAINT_PRI FD_CHECK_PRI FD_SIMULATE FD_RECOMMEN_ACT FD_EXTENDED_ACTIVE_1 FD_EXTENDED_ACTIVE_2 FD_EXTENDED_ACTIVE_3 FD_EXTENDED_ACTIVE_4...
  • Page 35 4-12 <4. Configuration> View Relative Index Parameter PRIVATE_6 PRIVATE_7 PRIVATE_8 PRIVATE_9 PRIVATE_10 PRIVATE_11 DEVICE_CONDITION_ACTIVE_1 DEVICE_CONDITION_ACTIVE_2 DEVICE_CONDITION_ACTIVE_3 DEVICE_CONDITION_ACTIVE_4 DEVICE_CONDITION_ACTIVE_5 DEVICE_CONDITION_ACTIVE_6 DEVICE_CONDITION_ACTIVE_7 DEVICE_CONDITION_ACTIVE_8 TOTALS(#BYTES) IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 36 4-13 <4. Configuration> Table 4.13 View Object for AI1.AI2.AI3 Function Block View Relative Index Parameter ST_REV TAG_DESC STRATEGY ALERT_KEY MODE_BLK BLOCK_ERR SIMULATE XD_SCALE OUT_SCALE GRANT_DENY IO_OPTS STATUS_OPTS CHANNEL L_TYPE LOW_CUT PV_FTIME FIELD_VAL UPDATE_EVT BLOCK_ALM ALARM_SUM ACK_OPTION ALARM_HYS HI_HI_PRI HI_HI_LIM HI_PRI HI_LIM LO_PRI LO_LIM LO_LO_PRI LO_LO_LIM...
  • Page 37 4-14 <4. Configuration> Table 4.14 View Object for Sensor Transducer Block PH/SENCOM PH View Relative Index PARAMETER NAME ST_REV TAG_DESC STRATEGY ALERT_KEY MODE_BLK BLOCK_ERR UPDATE_EVT BLOCK_ALM TRANSDUCER_DIRECTORY TRANSDUCER_TYPE XD_ERROR COLLECTION_DIRECTORY ALARM_SUM PRIMARY_VALUE_TYPE PRIMARY_VALUE PRIMARY_VALUE_UNIT SENSOR_TYPE_PH PH_ZERO1 PH_ZERO2 PH_ZERO_UNIT PH_SLOPE1 PH_SLOPE2 PH_SLOPE_UNIT PH_3POINT_CALIBRATION ISOPOTENTIAL_PH SENSOR_CALIBRATION_DATE SENSOR_CALIBRATION_DUE_DATE...
  • Page 38 4-15 <4. Configuration> View Relative Index PARAMETER NAME DETC_WELLNESS_PROG_TIME MODULE_PDN MODULE_SOFTREV HOUSING_PDN HOUSING_SOFTREV SENSOR_TYPE_MODEL SENCOM_MAX_TEMP SENCOM_HIGH_PH_TOTAL SENCOM_LOW_PH_TOTAL SENCOM_STERILIZATION SENCOM_STERILIZATION_LAST_DATE SENCOM_HIGH_TEMP1_TOTAL SENCOM_HIGH_TEMP1_LAST_DATE SENCOM_HIGH_TEMP2_TOTAL SENCOM_HIGH_TEMP2_LAST_DATE SENCOM_MODEL_CODE SENCOM_SOFTREV SENCOM_ASSYREV SENCOM_SERIAL_NO SENCOM_FACT_DATE ERR_CONFIG_PH_TOO_HIGH ERR_CONFIG_PH_TOO_LOW ERR_CONFIG_TEMP_TOO_HIGH ERR_CONFIG_TEMP_TOO_LOW ERR_CONFIG_ORP_TOO_HIGH ERR_CONFIG_ORP_TOO_LOW ERR_CONFIG_RH_TOO_HIGH ERR_CONFIG_RH_TOO_LOW ERR_CONFIG_MATRIX_CONFIG_ERROR ERR_CONFIG_CALIB_TIME_EXCEEDED ERR_CONFIG_IMPEDANCE1_TOO_HIGH ERR_CONFIG_IMPEDANCE1_TOO_LOW ERR_CONFIG_IMPEDANCE2_TOO_HIGH ERR_CONFIG_IMPEDANCE2_TOO_LOW ERR_CONFIG_SENCOM_SENSOR_CHANGED IMPEDANCE1_LOW_LMT IMPEDANCE1_HIGH_LMT...
  • Page 39 4-16 <4. Configuration> View Relative Index PARAMETER NAME TRANSMITTER_TIME RESERVE_PARAMETER_1 RESERVE_PARAMETER_2 RESERVE_PARAMETER_3 RESERVE_PARAMETER_4 RESERVE_PARAMETER_5 RESERVE_PARAMETER_6 RESERVE_PARAMETER_7 RESERVE_PARAMETER_8 RESERVE_PARAMETER_9 RESERVE_PARAMETER_10 RESERVE_PARAMETER_11 RESERVE_PARAMETER_12 RESERVE_PARAMETER_13 RESERVE_PARAMETER_14 RESERVE_PARAMETER_15 RESERVE_PARAMETER_16 RESERVE_PARAMETER_17 RESERVE_PARAMETER_18 RESERVE_PARAMETER_19 RESERVE_PARAMETER_20 RESERVE_PARAMETER_21 RESERVE_PARAMETER_22 RESERVE_PARAMETER_23 RESERVE_PARAMETER_24 RESERVE_PARAMETER_25 RESERVE_PARAMETER_26 RESERVE_PARAMETER_27 RESERVE_PARAMETER_28 RESERVE_PARAMETER_29 TEST_1 TEST_2 TEST_3 TEST_4 TEST_5 TEST_6 TEST_7...
  • Page 40 4-17 <4. Configuration> Table 4.15 View Object for Sensor Transducer Block SC View Relative Index PARAMETER NAME ST_REV TAG_DESC STRATEGY ALERT_KEY MODE_BLK BLOCK_ERR UPDATE_EVT BLOCK_ALM TRANSDUCER_DIRECTORY TRANSDUCER_TYPE XD_ERROR COLLECTION_DIRECTORY ALARM_SUM PRIMARY_VALUE_TYPE PRIMARY_VALUE PRIMARY_VALUE_UNIT SENSOR_TYPE_SC CELL_CONST_FACTORY CELL_CONST_ADJUST MEASURING_TYPE MEASURING_UNIT SENSOR_CALIBRATION_DATE SENSOR_CALIBRATION_DUE_DATE SENSOR_TEMP_COMPENSATION SENSOR_TEMP_MANUAL_VALUE REFERENCE_TEMP TEMP_COMPENSATION1 TEMP_COMPENSATION2...
  • Page 41 4-18 <4. Configuration> View Relative Index PARAMETER NAME CONC_TABLE_CONCENTRATION_12 CONC_TABLE_CONCENTRATION_13 CONC_TABLE_CONCENTRATION_14 CONC_TABLE_CONCENTRATION_15 CONC_TABLE_CONCENTRATION_16 CONC_TABLE_CONCENTRATION_17 CONC_TABLE_CONCENTRATION_18 CONC_TABLE_CONCENTRATION_19 CONC_TABLE_CONCENTRATION_20 CONC_TABLE_CONCENTRATION_21 CONC_TABLE_CONDUCTIVITY_1 CONC_TABLE_CONDUCTIVITY_2 CONC_TABLE_CONDUCTIVITY_3 CONC_TABLE_CONDUCTIVITY_4 CONC_TABLE_CONDUCTIVITY_5 CONC_TABLE_CONDUCTIVITY_6 CONC_TABLE_CONDUCTIVITY_7 CONC_TABLE_CONDUCTIVITY_8 CONC_TABLE_CONDUCTIVITY_9 CONC_TABLE_CONDUCTIVITY_10 CONC_TABLE_CONDUCTIVITY_11 CONC_TABLE_CONDUCTIVITY_12 CONC_TABLE_CONDUCTIVITY_13 CONC_TABLE_CONDUCTIVITY_14 CONC_TABLE_CONDUCTIVITY_15 CONC_TABLE_CONDUCTIVITY_16 CONC_TABLE_CONDUCTIVITY_17 CONC_TABLE_CONDUCTIVITY_18 CONC_TABLE_CONDUCTIVITY_19 CONC_TABLE_CONDUCTIVITY_20 CONC_TABLE_CONDUCTIVITY_21 POLARIZATION SENSOR_OHMS DETC_WELLNESS_POLARIZATION DETC_WELLNESS_CELL_CONST DETC_WELLNESS_HEAT_CYCLE DETC_WELLNESS_PROG_TIME...
  • Page 42 4-19 <4. Configuration> View Relative Index PARAMETER NAME DIAG_SETTING_PROG_TIME DIAG_SETTING_PROG_TIME_BAD_LMT DIAG_SETTING_HEAT_CYCLE DIAG_SETTING_HEAT_CYCLE_BAD_LMT HEAT_CYCLE_TEMP HEAT_CYCLE_TIME TRANSMITTER_TIME RESERVE_PARAMETER_1 RESERVE_PARAMETER_2 RESERVE_PARAMETER_3 RESERVE_PARAMETER_4 RESERVE_PARAMETER_5 RESERVE_PARAMETER_6 RESERVE_PARAMETER_7 RESERVE_PARAMETER_8 RESERVE_PARAMETER_9 RESERVE_PARAMETER_10 RESERVE_PARAMETER_11 RESERVE_PARAMETER_12 RESERVE_PARAMETER_13 RESERVE_PARAMETER_14 RESERVE_PARAMETER_15 RESERVE_PARAMETER_16 RESERVE_PARAMETER_17 RESERVE_PARAMETER_18 RESERVE_PARAMETER_19 RESERVE_PARAMETER_20 RESERVE_PARAMETER_21 RESERVE_PARAMETER_22 RESERVE_PARAMETER_23 TEST_1 TEST_2 TEST_3 TEST_4 TEST_5 TEST_6 TEST_7...
  • Page 43 Blank Page...

  • Page 44: Explanation Of Basic Items

    <5. Explanation of Basic Items> Explanation of Basic Items Function block parameters can be read from the host or can be set. For a list of the parameters of blocks held by the FLXA21, refer to Chapter 7. The following is a list of important parameters with a guide how to set them.

  • Page 45: Channel

    <5. Explanation of Basic Items> 5.1.3 CHANNEL Channel is the parameter to select the signal which is calculated in Sensor Transducer Block. The values are assigned to channels. For the FLXA21 four channels are available. For the FLXA21, you can select from the PRIMARY, SECONDARY, TERTIARY, QUATENARY values assigned to the Sensor Transducer Block.

  • Page 46: L_Type

    <5. Explanation of Basic Items> 5.1.5 L_TYPE Specifies the operation function of the AI block. If set to “Direct”, the input delivered to CHANNEL is directly reflected on OUT. If set to “Indirect”, scaling by XD_SCALE and OUT_SCALE is carried out and is reflected on OUT. If set to “Indirect SQRT”, after scaling by XD_SCALE, the square root is extracted and the value scaled by OUT_SCALE is reflected on OUT. Example: Channel range is defined as 0 to 100 °C but °F units is required for HOST display. Set the following parameters: XD_SCALE: EU@0% = 0 °C EU@100% = 100 °C Unit = °C Decimal point = 2 OUT_SCALE: EU@0% = 32 °F EU@100% = 212 °F Unit = °F Decimal point = 2 XD_SCALE OUT_SCALE 100%, 212ºF PV / OUT 100%, 100ºC CHANNEL...

  • Page 47: Status_Opt

    <5. Explanation of Basic Items> 5.1.10 STATUS_OPT STATUS_OPT is a parameter to select options regarding the status of signals. The AI function block offers four options: Propagate Fault Forward, Uncertain if Limited, BAD if Limited, and Uncertain if Man mode. Propagate Fault Forward If the status from the sensor is Bad, Device failure or Bad, Sensor failure, propagate it to OUT without generating an alarm.

  • Page 48: Block_Err

    <5. Explanation of Basic Items> 5.2.2 BLOCK_ERR BLOCK_ERR presents the cause of an error in the block. The Sensor transducer block checks the following causes and sets the relevant bits. BLOCK_ERR Error Cause other Differential pressure adjusted by zero/span adjustment out of measurement range, Static pressure adjusted by zero/span adjustment out of measurement range Out-of-Service MODE_BLK.Target is O/S 5.2.3...
  • Page 49 Blank Page...

  • Page 50: In-Process Operation

    <6. In-process operation> In-process operation This chapter describes the procedure performed when changing the operation of the function block of the FLXA21 in process. Mode Transition When the function block mode is changed to Out_Of_Service, the function block pauses and a block alarm is issued.
  • Page 51 <6. In-process operation> Update Alerts (Generated when a important (restorable) parameter is updated) By Resource Block Update Event By Sensor Transducer Block Update Event By AI1, AI2, AI3 Blocks Update Event Field Diagnostic Alerts (Generated when an abnormal condition in field device is detected) By Resource Block Check Alarm, Failure Alarm, Maintenance Alarm, and off specification Alarm. An alert has following structure: Table 6.1 Alert Object Subindex...
  • Page 52 <6. In-process operation> Alarms displayed by DEVICE_STATUS_1 to DEVICE_STATUS_8 resource block parameters in their default setting are categorized as described in “NAMUR NE-107 Alarm Categories” in the DEVICE_STATUS table in section 8.1. When an alarm occurs, a character string that corresponds to an alarm category is assigned to FD_*_ACTIVE (index 1067 to 1070) [* indicates FAIL, OFF SPEC, MAINT or CHECK].

  • Page 53: Simulation Function

    <6. In-process operation> Simulation Function The simulation function simulates the input of a function block and lets it operate as if the data was received from the Sensor transducer block. It is possible to conduct testing for the downstream function blocks or alarm processes. A SIMULATE_ENABLE switch is mounted on the FF PCB assembly.
  • Page 54 <6. In-process operation> Table 6.5 FEATURE_SEL, write lock switch and WRITE_LOCK parameter relationship FEATURE_SEL (index 1018) Write lock WRITE_LOCK Hard W Lock Soft W Lock switch (index 1034) (bit4) (bit3) 0 (OFF) Unavailable (“1” (Write lock disabled)) 0 (OFF) Disabled 1 (Write lock disabled) (Factory default) 1 (ON) 2 (Write lock enabled) 1 (ON)
  • Page 55 Blank Page...

  • Page 56: List Of Parameters For Each Block Of The Flxa21

    <7. List of parameters for each block of the FLXA21> List of parameters for each block of the FLXA21 Note for sections 7.1 to 7.3 The “Write Mode” column contains the modes in which each parameter is write enabled. O/S: Write enabled in O/S mode.

  • Page 57: Resource Block

    <7. List of parameters for each block of the FLXA21> Resource Block Relative Write Index Parameter Name Factory Default Explanation Index Mode 1000 Block Header TAG:“RS” Block Tag Information on this block such as =O/S Block Tag, DD Revision, Execution Time etc.
  • Page 58 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter Name Factory Default Explanation Index Mode 1014 GRANT_DENY — AUTO Options for controlling access of host computer and local control panels to operating, tuning and alarm parameters of the block. 1015 HARD_TYPES Scalar input The types of hardware available as...
  • Page 59 1041 ITK_VER Version number of interoperability test by FOUNDATION Fieldbus applied to FLXA21. 1042 SOFT_REV Rn.nn FLXA21 software revision number. 1043 SOFT_DESC FLXA21-PH: Yokogawa internal use. n.nn-0402-n.nn FLXA21-SC: n.nn-0403-n.nn IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 60 1054 SOFTDWN_ 0x01 (FF Standard) AUTO Selects the software download FORMAT method. 0x01: FF Standard 0x02: YOKOGAWA Standard 1055 SOFTDWN_ Indicates the number of times the COUNT internal FlashROM was erased. 1056 SOFTDWN_ACT_ — Indicates the ROM number of the AREA currently working FlashROM.
  • Page 61 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter Name Factory Default Explanation Index Mode 1066 FD_VER Indicates value of major version of instrument diagnostics specifications (FF-912). 1067 FD_FAIL_ACTIVE — A parameter that corresponds to ”Failed” in the NAMUR NE-107 category.
  • Page 62 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter Name Factory Default Explanation Index Mode 1083 FD_FAIL_PRI AUTO Indicates the FD_FAIL_ALM priority for an alarm. 1084 FD_OFFSPEC_PRI AUTO Indicates the FD_OFFSPEC_ALM priority for an alarm. 1085 FD_MAINT_PRI AUTO Indicates theFD_MAINT_ALM...
  • Page 63 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter Name Factory Default Explanation Index Mode 1110 PRIVATE_6 — Not used for FLXA21. 1111 PRIVATE_7 — Not used for FLXA21. 1112 PRIVATE_8 — Not used for FLXA21. 1113 PRIVATE_9 —...

  • Page 64: Analog Input Block

    <7. List of parameters for each block of the FLXA21> Analog input Block Relative Index Index Index Parameter Factory Write Explanation Index Name Default Mode 4000 4100 4200 Block Header TAG: “AI1” or Block Information on this block such as “AI2”...
  • Page 65 7-10 <7. List of parameters for each block of the FLXA21> Relative Index Index Index Parameter Factory Write Explanation Index Name Default Mode 4011 4111 4211 OUT_ SCALE EU at 100%: 100 The high and low scale values, EU at 0%: 0 engineering units code, and Unit Index: number of digits to the right of 1342 (%)
  • Page 66 7-11 <7. List of parameters for each block of the FLXA21> Relative Index Index Index Parameter Factory Write Explanation Index Name Default Mode 4021 4121 4221 BLOCK_ALM — The block alarm is used for all configuration, hardware, connection failure or system problems in the block. The cause of the alert is entered in the subcode field. The first alert to become active will set the Active status in...
  • Page 67 7-12 <7. List of parameters for each block of the FLXA21> Sensor Transducer Block (1) Sensor Transducer Block FLXA21-PH Relative Write Index Parameter name Factory Default Description Index Mode 2000 SENSOR_ TAG: “STB” Block Tag Information on this block such as TRANSDUCER_ = O/S Block Tag, DD Revision, Execution...
  • Page 68 7-13 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode PH: 158 (pH) Type of pH sensor. 2017 SENSOR_TYPE_ SENCOM: 160 (pH+ORP) Calibrated sensor offset of pH. 2018 PH_ZERO1 Calibrated secondary sensor offset 2019 PH_ZERO2 of pH. Only available after 3 points calibration 1243 (mV) Unit of PH_ZERO1/2...
  • Page 69 7-14 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode — Sensor wellness indicator by Zero 2050 DETC_ value. WELLNESS_ZERO — Sensor wellness indicator by Slope 2051 DETC_ value. WELLNESS_ SLOPE —...
  • Page 70 7-15 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode — Manufacturing date of SENCOM 2074 SENCOM_FACT_ sensor. Available on SENCOM. DATE 2 (Warning) Category of error status(Fault/ 2075 ERR_CONFIG_ Warning/Off) PH_TOO_HIGH 2 (Warning)
  • Page 71 7-16 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2000 Limit for sensor wellness by elapsed 2099 DIAG_SETTING_ time. PROG_TIME_ BAD_LMT 0 (Disable) Enable or Disable of sensor 2100 DIAG_SETTING_ wellness by heat cycle.
  • Page 72 7-17 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode — 2127 RESERVE_ Not used for FLXA21. PARAMETER_17 — 2128 RESERVE_ Not used for FLXA21. PARAMETER_18 — 2129 RESERVE_ Not used for FLXA21.
  • Page 73 7-18 <7. List of parameters for each block of the FLXA21> (2) Sensor Transducer Block FLXA21-SC Relative Write Index Parameter name Factory Default Description Index Mode 2000 SENSOR_ TAG: “STB” Block Tag Information on this block such as TRANSDUCER_ = O/S Block Tag, DD Revision, Execution BLOCK Time etc.
  • Page 74 7-19 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2018 CELL_CONST_ Cell constant (factory setting). FACTORY 2019 CELL_CONST_ Cell constant (adjusted) ADJUST 2020 MEASURING_ 1 (Conductivity1- Measuring type. TYPE TC1) 2021 MEASURING_UNIT...
  • Page 75 7-20 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2046 CONC_TABLE_ NOT A NUMBER Concentration 3 in the additional CONCENTRATION_3 concentration table. 2047 CONC_TABLE_ NOT A NUMBER Concentration 4 in the additional CONCENTRATION_4 concentration table.
  • Page 76 7-21 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2076 CONC_TABLE_ NOT A NUMBER Conductivity 12 in the additional CONDUCTIVITY_12 concentration table. 2077 CONC_TABLE_ NOT A NUMBER Conductivity 13 in the additional CONDUCTIVITY_13 concentration table.
  • Page 77 7-22 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2103 ERR_CONFIG_ 1 (Off) Category of error status(Fault/ USP_LMT_ Warning/Off) EXCEED 2104 ERR_ 3 (Fault) Category of error status(Fault/ CONFIG_1ST_ Warning/Off) COMP_MATRIX 2105 ERR_...
  • Page 78 7-23 <7. List of parameters for each block of the FLXA21> Write Relative Index Parameter name Factory Default Description Index Mode 2129 RESERVE_ — Not used for FLXA21. PARAMETER_13 2130 RESERVE_ — Not used for FLXA21. PARAMETER_14 2131 RESERVE_ — Not used for FLXA21.
  • Page 79 Blank Page...

  • Page 80: Diagnostic Information

    <8. Diagnostic Information> Diagnostic Information DEVICE STATUS Device setting status and failures of FLXA21 are indicated by using parameter DEVICE_ STATUS_1, DEVICE_STATUS_2, DEVICE_STATUS_3, DEVICE_STATUS_4, DEVICE_ STATUS_5, DEVICE_STATUS_6, DEVICE_STATUS_7, and DEVICE_STATUS_8 (index 1045, 1046, 1047, 1048, 1049, 1050, 1051, and 1052) in Resource Block. IM 12A01A02-71E 3rd Edition : Mar.
  • Page 81 <8. Diagnostic Information> Table 8.1 Contents of DEVICE_STATUS_1 for FLXA21-PH Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 1-31 Write Unlocked Writing to parameters is Unlocked. — [Action]: Change the RB Write Lock(RB. WRITE_LOCK) to Locked or turn on the hardware write lock switch.
  • Page 82 <8. Diagnostic Information> Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 1-08 Link Obj. 9/25 Not Link object 9 or 25 is not open. Open [Action]: Check the Link Object. 1-07 Link Obj. 10/26 Not Link object 10 or 26 is not open. Open [Action]: Check the Link Object.
  • Page 83 <8. Diagnostic Information> Table 8.3 Contents of DEVICE_STATUS_3 (Sensor Fault from Housing) for FLXA21-PH Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 3-32 pH too high pH reading above the higher limit. [Action]: Check connections and cable. Replace sensor. 3-31 pH too low pH reading below the lower limit.
  • Page 84 <8. Diagnostic Information> Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 3-07 SENCOM comm. SENCOM communication is not correct. error [Action]: Check connection of SENCOM sensor. 3-06 Checksum error [Action]: Contact your local sales office. 3-05 Sensor type not SENCOM sensor type is not correct. correct [Action]: Change SENCOM sensor type on the display of FLXA21.
  • Page 85 <8. Diagnostic Information> Table 8.5 Contents of DEVICE_STATUS_5 (Sensor Warning from Housing) for FLXA21-PH Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 5-32 pH too high pH reading above the higher limit. [Action]: Check connections and cable. Replace sensor. 5-31 pH too low pH reading below the lower limit.
  • Page 86 <8. Diagnostic Information> Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 5-11 Temp. comp. matrix Temp. comp. matrix is not properly error defined. [Action]: Execute 'Check values' on the display of FLXA21. Table 8.6 Contents of DEVICE_STATUS_6 for FLXA21-PH Field Display through Description...
  • Page 87 <8. Diagnostic Information> Table 8.8 Contents of DEVICE_STATUS_8 for FLXA21-PH Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 8-25 TB in O/S Mode Sensor Transducer Block is in O/S mode. [Action]: Change the STB Block Mode. Target(STB.MODE_BLK.TARGET) to Auto mode.
  • Page 88 <8. Diagnostic Information> Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 8-11 AI2 Simulate Active AI2 Block is in simulation mode. [Action]: Change the AI2 Simulation En/ Disable (AI2.SIMULATE.SIMULATE_ ENABLE) to Disabled. 8-10 AI2 in MAN Mode AI2 Block is in Man mode. [Action]: Change the AI2 Block Mode.
  • Page 89 8-10 <8. Diagnostic Information> Table 8.9 Contents of DEVICE_STATUS_2 (CPU Fault from Housing) for FLXA21-SC Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX Category 2-17 Calibration Due System was not maintained within the preset period. [Action]: Perform maintenance. Increase Calibr. Interval. 2-15 Outputs in HOLD [Action]: Press HOLD in main display.
  • Page 90 8-11 <8. Diagnostic Information> Table 8.10 Contents of DEVICE_STATUS_3 (Sensor Fault from Housing) for FLXA21-SC Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 3-32 Conductivity too Conductivity exceeds high limit. or high Resistivity exceeds low limit. [Action]: Check connections and cable. Replace sensor.
  • Page 91 8-12 <8. Diagnostic Information> Table 8.11 Contents of DEVICE_STATUS_4 (CPU Warning from Housing) for FLXA21-SC Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 4-19 Log Book (almost) Logbook is more than 95% full. full [Action]: Erase logbooks. Turn logbook "full" warning off. 4-17 Calibration Due System was not maintained within the preset period.
  • Page 92 8-13 <8. Diagnostic Information> Table 8.12 Contents of DEVICE_STATUS_5 (Sensor Warning from Housing) for FLXA21-SC Field Display through Description DeviceViewer NAMUR NE-107 Diagnostic AL-XXX category 5-32 Conductivity too Conductivity exceeds high limit. or high Resistivity exceeds low limit. [Action]: Check connections and cable. Replace sensor.

  • Page 93: Status Of Each Parameter In Failure Mode Flxa21-Ph

    8-14 <8. Diagnostic Information> Status of each parameter in failure mode FLXA21-PH Following tables summarize the value of FLXA21 parameters when LCD display indicates an Alarm or status has some problems. Resource Block Action of each parameters in failure mode related Resource block. Field Diagnostic BLOCK_ERR Display through DD...
  • Page 94 8-15 <8. Diagnostic Information> Sensor Transducer Block (Fault) Action of each parameters in failure mode related Sensor Transducer block. These become effective when ERR_CONFIG_n (TB: 2075 to 2089) is set to Fault. Field Diagnostic Temperature Display BLOCK_ BLOCK_ BLOCK_ Fault Fault Fault through DD ERROR ERROR ERROR 3-32 pH too high BAD- Other —...
  • Page 95 8-16 <8. Diagnostic Information> Field Diagnostic Temperature Display BLOCK_ BLOCK_ BLOCK_ Fault Fault Fault through DD ERROR ERROR ERROR 3-04 Internal BAD- Other BAD- Other BAD- Other error in Sensor Failure Sensor Failure Sensor Failure SENCOM Failure Failure Failure 3-03 SENCOM BAD- Other BAD-...
  • Page 96 8-17 <8. Diagnostic Information> Field Diagnostic Ref. Impedance Empty Display BLOCK_ BLOCK_ BLOCK_ Fault Fault Fault through DD ERROR ERROR ERROR 3-32 pH too high BAD- Other — — — When — — Sensor Failure "Empty" is Failure selected, status 3-31 pH too low BAD- Other...
  • Page 97 8-18 <8. Diagnostic Information> Field Diagnostic Ref. Impedance Empty Display BLOCK_ BLOCK_ BLOCK_ Fault Fault Fault through DD ERROR ERROR ERROR 3-03 SENCOM BAD- Other BAD- Other When Other Sensor Failure Sensor Failure “Empty” is Failure connected Failure Failure selected, status 3-02 EEPROM BAD-...
  • Page 98 8-19 <8. Diagnostic Information> Field Diagnostic Temperature Display BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning ERROR ERROR ERROR 5-32 pH too high Uncertain- — — — — — — — — Sensor Conversion 5-31 pH too low Uncertain- — — —...
  • Page 99 8-20 <8. Diagnostic Information> Field Diagnostic Ref. Impedance Empty Display BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning ERROR ERROR ERROR 5-32 pH too high Uncertain- — — — — — When — — Sensor “Empty” is Conversion selected, status 5-31 pH too low Uncertain- —...

  • Page 100: Status Of Each Parameter In Failure Mode Flxa21-Sc

    8-21 <8. Diagnostic Information> Status of each parameter in failure mode FLXA21-SC Following tables summarize the value of FLXA21 parameters when LCD display indicates an Alarm or status has some problems. Resource Block Action of each parameters in failure mode related Resource block. Field Diagnostic BLOCK_ERR Display through DD...
  • Page 101 8-22 <8. Diagnostic Information> Sensor Transducer Block (Fault) Action of each parameters in failure mode related Sensor Transducer block. These become effective when ERR_CONFIG_n (TB: 2097 to 2106) is set to Fault. Field Concentration- Concentration- Conductivity-TC1 Conductivity-TC2 Temperature Diagnostic Display BLOCK_ BLOCK_ BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning Warning Warning ERROR ERROR ERROR ERROR...
  • Page 102 8-23 <8. Diagnostic Information> Field Concentration- Concentration- Conductivity-TC1 Conductivity-TC2 Temperature Diagnostic Display BLOCK_ BLOCK_ BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning Warning Warning ERROR ERROR ERROR ERROR ERROR 2-02 Chksum BAD- Other BAD- Other BAD- Other BAD- Other BAD- Other Electronics Electronics Electronics...
  • Page 103 8-24 <8. Diagnostic Information> Field Resistivity-TC1 Resistivity-TC2 Empty Diagnostic Display BLOCK_ BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning Warning ERROR ERROR ERROR ERROR 6-02 HART BAD- Other I/O BAD- Other I/O BAD- Other I/O Other I/O When Failure Device Failure Device Failure Device...
  • Page 104 8-25 <8. Diagnostic Information> Field Resistivity-TC1 Resistivity-TC2 Empty Diagnostic Display BLOCK_ BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning Warning ERROR ERROR ERROR ERROR 2-01 EEPROM BAD- Other Electronics BAD- Other Electronics BAD- Other Electronics Other Electronics err.(CPU Device Failure Device Failure Device Failure...
  • Page 105 8-26 <8. Diagnostic Information> Field Resistivity-TC1 Resistivity-TC2 Empty Diagnostic Display BLOCK_ BLOCK_ BLOCK_ BLOCK_ through Warning Warning Warning Warning ERROR ERROR ERROR ERROR 5-32 Conductivity — — — — — — — — Uncertain- Uncertain- Uncertain- When too high Sensor Sensor Sensor “Empty”...

  • Page 106: Appendix 1 Link Master Functions

    App.1-1 <Appendix 1 Link Master Functions> Appendix 1 Link Master Functions Link Active Scheduler A link active scheduler (LAS) is a deterministic, centralized bus scheduler that can control communications on an H1 fieldbus segment. There is only one LAS on an H1 fieldbus segment. FLXA21 supports the following LAS functions. • PN transmission: Identifies a fieldbus device newly connected to the same fieldbus segment. PN is short for Probe Node. • PT transmission: Passes a token governing the right to transmit, to a fieldbus device on the same segment.
  • Page 107 App.1-2 <Appendix 1 Link Master Functions> In the event that the current LAS in this segment (node address 0x14) Node address: 0x14 fails, the LM with the address of 0x15 SlotTime = 5 takes its place to become the LAS. Basic device Basic device Basic device...
  • Page 108 App.1-3 <Appendix 1 Link Master Functions> (3) In the LAS settings of the FLXA21, set the values of V(FUN) and V(NUN) so that they include the node addresses of all nodes within the same segment. (See also Figure 3.) ConfiguredLinkSettingsRecord (Index 385 (SM)) Subindex Element Setting (Default)
  • Page 109 App.1-4 <Appendix 1 Link Master Functions> LM Parameters LM Parameter List The tables below show LM parameters. Meanings of Access column entries: RW = read/write possible; R = read only Sub-parameter Name Default Factory Index Parameter Name Remarks (Sub Index) Setting (SM) cess 375 PLME_BASIC_...
  • Page 110 App.1-5 <Appendix 1 Link Master Functions> Sub-parameter Name Default Factory Index Parameter Name Remarks (Sub Index) Setting (SM) cess 384 CURRENT_ R Settings for LAS 1 SlotTime LINK_SETTING_ 2 PerDlpduPhlOverhead RECORD 3 MaxResponseDelay 4 FirstUnpolledNodeId 5 ThisLink 6 MinInterPduDelay 7 NumConseeUnpolledNodeId 8 PreambleExtension 9 PostTransGapExtension 10 MaxInterChanSignalSkew...
  • Page 111 App.1-6 <Appendix 1 Link Master Functions> (2) DlmeLinkMasterInfoRecord Subindex Element Size [bytes] Description MaxSchedulingOverhead V(MSO) DefMinTokenDelegTime V(DMDT) DefTokenHoldTime V(DTHT) TargetTokenRotTime V(TTRT) LinkMaintTokHoldTime V(LTHT) TimeDistributionPeriod V(TDP) MaximumInactivityToClaimLasDelay V(MICD) LasDatabaseStatusSpduDistributionPeriod V(LDDP) (3) PrimaryLinkMasterFlagVariable Explicitly declares the LAS. Writing “true” (0xFF) to this parameter in a device causes that device to attempt to become the LAS.
  • Page 112 App.1-7 <Appendix 1 Link Master Functions> Subindex Element Size [bytes] Description SlotTime V(ST) PerDlpduPhlOverhead V(PhLO) MaxResponseDelay V(MRD) FirstUnpolledNodeId V(FUN) ThisLink V(TL) MinInterPduDelay V(MID) NumConsecUnpolledNodeId V(NUN) PreambleExtension V(PhPE) PostTransGapExtension V(PhGE) MaxInterChanSignalSkew V(PhIS) TimeSyncClass V(TSC) (8) DlmeBasicInfo Subindex Element Size [bytes] Description SlotTime Indicates the capability value for V(ST) of the device.
  • Page 113 NumOfSub SchedulesPer Indicates the maximum number of sub-schedules an Schedule LAS schedule can contain. (This is fixed to 1 in the Yokogawa communication stacks.) ActiveSchedule Version Indicates the version number of the schedule currently executed. ActiveSchedule OdIndex Indicates the index number of the domain that stores the schedule currently executed.
  • Page 114 App.1-9 <Appendix 1 Link Master Functions> CAUTION When downloading a LAS schedule to the FLXA21, maximum allowable linkages between devices are 25. FAQs Q1. When the LAS stops, the FLXA21 does not back it up by becoming the LAS. Why? A1-1.
  • Page 115 App.1-10 <Appendix 1 Link Master Functions> A4-3. Check that the correct Node Address is used for the FLXA21. Refer to “5.2 Sensor Transducer Block” for details. Confirm that the Node Address of FLXA21 should be out of the parameters of the LAS of V (FUN) ~ V (FUN)+V (NUN) Confirm that the Node Address is not within the default address (0xF8 to 0xFB). IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...

  • Page 116: Appendix 2 Software Download

    For the software download tool, use only a program developed for that purpose. For details, see the software’s User’s Manual. For information about updates of software binary files for field devices and how to obtain them, visit the following web site. http://www.yokogawa.com/fld/fld-top-en.htm CAUTION Do not hook up the software download tool to a fieldbus segment while the plant is in operation, as it may temporarily disturb the communication. Always connect the tool before starting operation.
  • Page 117 App.2-2 <Appendix 2 Software Download> NOTE The download tool can not execute downloading during other system connects to the system/ network management VFD of the device. Software Download Sequence The flowchart below outlines the software download procedure. Although the time taken for the entire procedure varies depending on the size of the field bus device’s software, it generally take about 20 minutes where there is a one-to-one connection between a fieldbus device and download tool, and longer when multiple field devices are connected to the fieldbus. Start download tool Select the software file(s) you Select file(s) want to download.
  • Page 118 App.2-3 <Appendix 2 Software Download> NOTE Be careful about the noise on the fieldbus link. If the fieldbus is noisy, the downloading may take a very long time or fail. Download Files Download files have the following filenames (with the filename extension of “.ffd”). Take care to choose the correct download file for the target field device: “594543” + device family + “_” + device type + “_” + domain name + “_” + software name + “_” + software revision + “.ffd” For example, the name of the download file for FLXA21-PH may have the following name: 5945430402_0402_FLXA21PH_ORIGINAL_R101.ffd Refer to (3) DOMAIN_HEADER in page App.2-8 about each keyword of the file name.
  • Page 119 App.2-4 <Appendix 2 Software Download> Troubleshooting For information on the download tool’s error messages, see also the software’s User’s Manual. Table 2 Problems after Software Update Symptom Cause Remedy An error occurs before starting a The selected download file is not Check SOFTDWN_ERROR in download, disabling the download. for the selected field device.
  • Page 120 App.2-5 <Appendix 2 Software Download> Table 4 Download Error Codes Error Error Detail Detail Code Code No error 32791 On-start state error (other than DWNLD_NOT_READY) 32768 Unsupported header version 32792 Start segment error in module 1 32769 Abnormal header size 32793 Binary file error 32770 Abnormal manufacturer ID 32794 Binary file error...
  • Page 121 App.2-6 <Appendix 2 Software Download> System/Network Management VFD Parameters Relating to Software Download Table 5 System/Network Management VFD Parameters Write Mode: R/W = read/write; R = read only Index Default Write Parameter Name Sub-parameter Name Remarks (SM) Index (Factory Set) Mode DWNLD_PROPERTY Download Class...
  • Page 122 App.2-7 <Appendix 2 Software Download> Comments on System/Network Management VFD Parameters Relating to Software Download IMPORTANT Do not turn off the power to a field device immediately after changing parameter settings. Data writing actions to the EEPROM are dual redundant to ensure reliability. If the power is turned off within 60 seconds after setup, the parameters may revert to the previous settings. (1) DWNLD_PROPERTY Size Element Description Index (Bytes) Download Class Indicates the download class.
  • Page 123 App.2-8 <Appendix 2 Software Download> (2) DOMAIN_DESCRIPTOR Size Element Description Index (Bytes) Command Reads/writes software download commands. 1: PREPARE_FOR_DWNLD (instruction of download preparation) 2: ACTIVATE (activation instruction) 3: CANCEL_DWNLD (instruction of download cancellation) State Indicates the current download status. 1: DWNLD_NOT_READY (download not ready) 2: DWNLD_PREPARING (download under preparation) 3: DWNLD_READY (ready for download) 4: DWNLD_OK (download complete)

  • Page 124: Appendix 3 Control Drawings

    5.36 V 116.5 mA 60.6 mA 106.16 mA 0.3424 W 0.178 W 0.1423 W 100 nF 100 nF 31 μF 1.7 mH 8 mH 0.45 mH Doc. No.: IKE039-A12 P.1-2 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 125 1. The associated apparatus must be a linear source or a FISCO power supply. Sensor 1 may be simple apparatus or intrinsically safe apparatus. WARNING – POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE USER’S MANUAL Doc. No.: IKE039-A12 P.1-3 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...

  • Page 126: App. 3.2 Fm Flxa21: Intrinsic Safety, Nonincendive

    0.45 mH Specific condition of use Electrostatic charges on the non-metallic or coated parts of the two wire analyzer shall be avoided. Rev.1: May 29, 2017 Doc. No.: IFM039-A72 P.1 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 127 Specific condition of use: - Electrostatic charges on the non-metallic or coated parts of the two wire analyzer shall be avoided. Rev.1: May 29, 2017 Doc. No.: IFM039-A72 P.2 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 128 IN THE EVENT OF RARE INCIDENTS, IGNITION SOURCES DUE TO IMPACT AND FRICTION SPARKS ARE EXCLUDED 12. WARNING – SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY AND SUITABITLITY FOR DIVISION 2 / ZONE 2. Rev. Doc. No.: IFM039-A72 P.3 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...

  • Page 129: App. 3.3 Csa Flxa21: Intrinsic Safety, Nonincendive

    8 mH 0.45 mH Specific condition of use Electrostatic charges on the non-metallic or coated parts of the two wire analyzer shall be avoided. Rev. Doc. No.: ICS032-A72 P.1 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 130 8 mH 0.45 mH Specific condition of use Electrostatic charges on the non-metallic or coated parts of the two wire analyzer shall be avoided. Rev. Doc. No.: ICS032-A72 P.2 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 131 ZONE 2 / DIVISION 2. AVERTISSEMENT –LA SUBSTITUTION DE COMPOSANTS PEUT RENDRE CE MATÉRIEL INACCEPTABLE POUR LES EMPLACEMENTS DE ZONE 2 / DIVISION 2. Rev. Doc. No.: ICS032-A72 P.3 Yokogawa Electric Corporation IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 132 App.3-9 <Appendix 3 Control Drawings> App. 3.4 NEPSI and KOSHA FLXA21: Intrinsic safety “ia” (Refer to App. 3.1 ATEX and IECEx Control Drawing) IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 133 Blank Page...

  • Page 134: Revision Record

    Manual Title : FLXA21 2-Wire Analyzer FOUNDATION Fieldbus Communication Manual No. : IM 12A01A02-71E Mar. 2018/3rd Edition Overall review Oct. 2015/2nd Edition Correction (Page iv) Apr. 2015/1st Edition Newly published Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN http://www.yokogawa.com/ IM 12A01A02-71E 3rd Edition : Mar. 23, 2018-00...
  • Page 135 Blank Page...
  • Page 136 - Electrostatic charges on the non-metallic or coated parts of the two wire analyzer shall be avoided. Rev.2: Sep. 15, 2017 Doc. No.: IFM039-A72 P.2 Yokogawa Electric Corporation All Rights Reserved. Copyright © 2019, 2nd Edition: Jan. 06, 2020 (YK) IM 12A01A02-71E 1/1 3rd Edition...

This manual is also suitable for:

Flexa sencom flxa21

Table of Contents
