Table 1: Zynq UltraScale+ MPSoC ZU19 Pin Map (cont'd)
Pin Number
K37
K36
J35
J34
M42
M41
L40
L39
K42
K41
J40
J39
BB16
F30
AK19
A29
A30
B29
B30
C29
N30
B11
B10
A11
A10
AL23
AL24
AM16
AH17
AH1
AH2
AJ3
AJ4
AK1
AK2
AL3
AL4
AM1
AM2
UG1495 (v1.0) December 17, 2021
T1 Telco Accelerator Card User Guide
Signal Name
MAC_MP_T2_N
MAC_MP_T2_P
MAC_MP_T3_N
MAC_MP_T3_P
MAC_RF_TX0_N
MAC_RF_TX0_P
MAC_RF_TX1_N
MAC_RF_TX1_P
MAC_RF_TX2_N
MAC_RF_TX2_P
MAC_RF_TX3_N
MAC_RF_TX3_P
MP_LED
MP_PS_TEST_LED
MP_RST_REQ
CLK_GPIO_0
CLK_GPIO_1
CLK_GPIO_2
CLK_GPIO_3
CLK_GPIO_4
CONFIG_EEPROM_WP
MP_SFP0_SCL
MP_SFP0_SDA
MP_SFP1_SCL
MP_SFP1_SDA
PCIE_SOC_I2C_SCL
PCIE_SOC_I2C_SDA
PCIE_MP_PERST_LS#
PCIE_MP_WAKE_LS#
PCIE_RX0_N
PCIE_RX0_P
PCIE_RX1_N
PCIE_RX1_P
PCIE_RX2_N
PCIE_RX2_P
PCIE_RX3_N
PCIE_RX3_P
PCIE_RX4_N
PCIE_RX4_P
Chapter 2: Pin Mapping
Interface
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
Inter-SoC 100G MAC
LED: MPSoC General Purpose LED1
LED: MPSoC General Purpose LED2
MPSoC-->SC Reset request
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
NOT USED
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
PCIe
