w w w . c e i a . n e t
PD240CH
INSTRUCTION
CEIA reserves the right to make changes, at any moment and without notice, to the models
(including programming), their accessories and options, to the prices and conditions of sale.
FI100K0025v1100UK
MANUALAAAAAAA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD240CH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ceia PD240CH

  • Page 1 . c e i a . n e t PD240CH INSTRUCTION MANUALAAAAAAA CEIA reserves the right to make changes, at any moment and without notice, to the models (including programming), their accessories and options, to the prices and conditions of sale. FI100K0025v1100UK...
  • Page 2: Table Of Contents

    This sign in the manual indicates tips for optimizing the device’s performance. CEIA reserves the right to make changes, at any moment and without notice, to the models (including programming), their accessories and options, to the prices and conditions of sale...
  • Page 3 CEIA is carried out using an alternative return them to a CEIA office. If the forbidden and voids all warranties method. equipment is to be disposed of, and certifications.
  • Page 4: Description

    General Description 1.1.1 Purpose PD240CH is a lightweight portable metal detector which is capable to distinguish magnetic metals with respect to nonmagnetic metals. Potential threats for MRI scans can be hence revealed and distinguished from non-dangerous prosthesis or implants. This equipment is designed to localize metal masses concealed or carried on a person or an object.
  • Page 5: Main Components

    HHDS-CH Verification of Detection test piece , code 72131 Universal AC adapter EU, UK, USA, JP plugs Instruction Manual Carry bag Verification of Discrimination test piece , code 72132 PD Set inside the Carry Bag FI100K0025v1100 UK - - PD240CH...
  • Page 6: Controls And Indicators

    PD240CH SN xxxxxxxxxxx The data provided are as follows: 3V 370mW Battery Size AA or LR6 x2  model  serial number (SN)  power supply voltage and consumption  battery type and quantity FI100K0025v1100 UK - - PD240CH...
  • Page 7: Use

    Example of “ready for use” indication: acoustic alarm enabled and “body” mode setting. Status verification The device settings are indicated by a periodic flashing of the inner lights of the selection push buttons. The same indication is also displayed by pressing push button briefly. FI100K0025v1100 UK - - PD240CH...
  • Page 8: Selection Of Alarm Or Diagnosis Alert Indications

    Insensitive to large nonmagnetic metal items (example large prostheses) Head:  high sensitivity to very small magnetic metals (example: small ferromagnetic fragments).  Insensitive to medium size nonmagnetic metal items (example: non- ferromagnetic dental implants, small prostheses). FI100K0025v1100 UK - - PD240CH...
  • Page 9: Metal Mass Detection

    For this purpose, the person to scan should be lying on a metal free support. The figure below shows an example of a gurney mainly made of plastic: the shaded area is metal free, while the castors can contain metallic parts. FI100K0025v1100 UK - - PD240CH...
  • Page 10: Two-Step Localization Procedure (Pin-Pointing)

    In this case, move away the detector from the metal mass: the alarm will reset automatically. A prolonged alarm can be quickly reset, by pressing the ON/OFF button briefly. Do not reset the detector when placed near to a large size metal mass! FI100K0025v1100 UK - - PD240CH...
  • Page 11: Operational Verification

    An alarm signal must be provided. Head Body Simultaneous use of HHMDs and WTMDs The Hand Held Metal Detector can be used close to a Walk-Through Metal Detector at the distance usually kept for secondary inspections. FI100K0025v1100 UK - - PD240CH...
  • Page 12: Automatic Stand-By

    This function can be disabled, on customer request or using HHMD Configuration Tool. 2.10 Turning off Keep pressed push button for at least 3 seconds. RED lights will turn on in sequence and then the device turns off (all indicators off). >3s FI100K0025v1100 UK - - PD240CH...
  • Page 13: Battery Charging

    The detector can be extracted and used even At full charge (after 5 hours max.) the before the full indicator turns in steady GREEN light. The charge is detector is ready for use. 100% completed If required. FI100K0025v1100 UK - - PD240CH...
  • Page 14: Maintenance

    HHMD Configuration operating channel Tool Increase distance. Alarm signal after start- Walk-through metal detectors or other Use hand-held metal detector with electromagnetic different operating channel (using sources in close the accessory HHMD Configuration proximity Tool FI100K0025v1100 UK - - PD240CH...
  • Page 15: Procedure For Replacing Batteries

    Remove the locking screw from the cap of the battery compartment, using a TORX 10 key. Replace the batteries, respecting their polarity, as illustrated in the figure below. Replace the battery compartment cap and secure it tightening the locking screw. FI100K0025v1100 UK - - PD240CH...
  • Page 16: Appendices

    EMC and to the applicable CE regulations Warranty The warranty on all CEIA products, extended to the period agreed with the Sales Department, is applicable to goods supplied from our factory, and for every constituent part thereof, with the exception of the batteries. Any form of tampering with the device, and in particular opening its container, is strictly forbidden and will invalidate the warranty.
  • Page 17: Spare Parts

    HHDS. batteries NiMH, 2500mAh. Desktop docking station AC power supply adapter TORX10 key Included. with AC power supply for HHDS, with EU, UK, adapter. USA/JP interchangeable plugs. Code: 60769 Code: HHDS-CH Code: 64643 FI100K0025v1100 UK - - PD240CH...
  • Page 18: Options And Accessories

    Appendices Options and Accessories HHMD Configuration Tool Tool for setting up the metal detector via USB PC-HHMD connecting cable and GUI interface. Code: 63537 FI100K0025v1100 UK - - PD240CH...
  • Page 20 www.ceia.net...
