ASSEMBLY INSTRUCTIONS
Diamonds
Size: 1200mm
Tools Required: Power screwdriver / Power Drill
Special Note: No pre-drilled Nut inserts . Screws to be drilled into the underside of desktop.
2 persons required for installation
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 1 of 5
