Prepac RK-2525 Assembly Instructions Manual

Night table

Advertisement

Quick Links

Assembly Instructions
CALL US FIRST
1-877-PREPAC1
1-877-773-7221
Mon - Fri
7am - 4pm PST
10am - 7pm EST
For help with assembly
If you have received a damaged or defective part or
are missing hardware.
We will process replacement parts
less. Parts are shipped via
Before you call please:
1) Record the following information from the shipping
label on the outside of the box. You will need it for
warranty purposes:
• Ship To Name
• Sales Order Number
2) Note the
product model number.
3) Review the contents of your shipment to determine
what you are missing.
Online Option:
Fill out the Replacement Parts Order form in the Product
Support section of our website: www.prepacmfg.com
Required Tools
Screwdrivers
in 2 business days or
UPS Ground or mail.
Phillips Head
Flat Head
Hammer
Night Table
Model #
RK-2525 / BDR-2000
This product is shipped in
Optional Tools
Using a power screwdriver
will speed up assembly.
Caution
Do not over tighten any screw.
The last few turns of each screw
should be done very slowly or by hand.
1 carton
1 of 1
Prepac Manufacturing Ltd.
6705 Dennett Place
Delta, BC V4G 1N4
LB-0655
2012-05-16

Advertisement

loading
Need help?

Need help?

Do you have a question about the RK-2525 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Prepac RK-2525

  • Page 1 Night Table Model # RK-2525 / BDR-2000 Assembly Instructions This product is shipped in 1 carton 1 of 1 CALL US FIRST 1-877-PREPAC1 1-877-773-7221 Mon - Fri 7am - 4pm PST 10am - 7pm EST • For help with assembly •...
  • Page 2: Hardware Identification

    Hardware Identification Cabinet Hardware 15mm Zinc Cam Green Twister Dowel 12mm Zinc Cam (16) (32) (16) RM-0103 RM-0501 RM-0502 ¾” Nail (16)* RM-0022 T Spacer Drawer Slide Screw (24) RM-0628 RM-0074 *More than required LEFT Cabinet Slide (2) RIGHT Cabinet Slide (2) Drawer Hardware Set of Drawer &...
  • Page 3: Cabinet Parts

    Cabinet Parts Profiled Top (1) Left Side (1) Right Side (1) Unfinished Rear TP-4131 Black SL-4112 Black SR-4112 Black Stabilizer (2) TP-4931 Cherry SL-4912 Cherry ST-4512 SR-4912 Cherry TP-4631 Espresso SL-4612 SR-4612 Espresso Espresso TP-4031 White SL-4012 White SR-4012 White Front Stabilizer (2) Left Right Leg (2)
  • Page 4 STEP 1 Estimated Time: 3 minutes Insert large cams into holes on left and right sides. Front Make sure arrow on cam faces hole for connecting bolt Left Right Side Side STEP 2 Estimated Time: 3 minutes Insert 16 small cams into all 4 stabilizers* Front Stabilizer Unfinished Rear Stabilizer To see a video showing how to use cams and...
  • Page 5 STEP 3 Estimated Time: 10 minutes Attach T-spacers to left and right sides using drawer slide screws Then, attach metal Cabinet Slides to T-spacers using drawer slide screws Front Front Drawer Slide Screw Left Right Side Side T-spacer & Slide Detail Drawer Slide Screw To see a video showing how to attach drawer ONLINE...
  • Page 6 STEP 4 Estimated Time: 10 minutes Screw green twister dowels into the holes on each leg STEP 5 Estimated Time: 5 minutes Attach legs to each side and lock cams using a flat head screwdriver FRONT Left Side Right Side FRONT Unlocked Locked...
  • Page 7 STEP 6 Estimated Time: 5 minutes Attach front and rear stabilizers to the Left Side and tighten cams. Make sure to attach the finished stabilizers at the FRONT Finished Front Stabilizer Unfinished Rear Stabilizer FRONT Left Side Locked Unlocked Turn 210° Page 7 of 16...
  • Page 8 STEP 7 Estimated Time: 5 minutes Attach the Right Side and tighten cams. Right Side FRONT Locked Unlocked Turn 210° Page 8 of 16...
  • Page 9 STEP 8 Estimated Time: 4 minutes Insert green twister dowels into underside of top Attach top and tighten cams FRONT Unlocked Unlocked Locked Locked Turn 210° Turn 210° Page 9 of 16...
  • Page 10 STEP 9 Estimated Time: 4 minutes Nail backer to top and sides as shown. Attach to the top and sides only Page 10 of 16...
  • Page 11 Drawer Parts Identification Drawer Front (2) Left Drawer Side (2) Drawer Bottom (2) Drawer Back (2) Right Drawer Side (2) DF-10013-B Black DS-0412W-L DB-0414 DK-0414W DS-0412W-R DF-10016-C Cherry Wood unfinished Wood Wood DF-10013-E Espresso DF-10016-W White Page 11 of 16...
  • Page 12 STEP 10 Estimated Time: 5 minutes PER DRAWER Insert small cams into drawer sides Left Drawer Side Right Drawer Side Make sure arrow faces toward hole for twister dowel Screw black twister dowels into drawer fronts Page 12 of 16...
  • Page 13 Attach drawer sides to drawer back with 1½” Hi Lo screws 1½” Hi Lo Screws Attach drawer front and tighten cams using a flat head screwdriver Right Drawer Side Left Drawer Side Locked Locked Unlocked Unlocked Turn 210° Turn 210° Page 13 of 16...
  • Page 14 Turn drawer upside down and slide drawer bottom into grooves Secure the drawer bottom to the drawer back with nails Use 4 nails per drawer Page 14 of 16...
  • Page 15 Attach drawer slides to left and right drawer sides using drawer slide screws Right Drawer Side Drawer Slide Screws Left Drawer Side Attach knobs with machine screws Machine Screw Page 15 of 16...
  • Page 16 STEP 11 Estimated Time: 2 minutes Insert drawers Cabinet Drawer Note: When drawers are installed correctly, you will not be able to remove them without first lifting up the drawer front. Furniture Care Q&A How do I clean your products? We recommend that you simply wipe your products with a clean, damp cloth and then dry immediately with another clean cloth to maximize the life span and look of your unit Can I paint or varnish your products?
