- Page 1 E12A LAVALIERE ELECTRET CONDENSER MICROPHONE Contact Marketing and sales Goang-Fann Co., Ltd. +886-2-26931323 sales@superlux.com.tw support@superlux.com.tw Manufacturing & logistics Superlux Enterprise Development ( Shanghai ) Co., Ltd. English...
- Page 2 E12A LAVALIERE ELECTRET CONDENSER MICROPHONE DESCRIPTION The E12A omni lavaliere mini clip-on condenser microphone is ideal for inconspicuous recording. Its tailored frequency response gives accurate, intel- ligible speech recognition, making it well suited for the interview programs of TV and radio stations for recording where ambient noise is not an issue.
-
Page 3: Specifications
SPECIFICATIONS *Note:Specifications are subject to change. E12ATQG E12AXLR E12ADXLR PS418D Preamp PS418S Preamp With Wireless system (Either phantom power or (Phantom power only) battery) Back electret, Back electret, Back electret, Type Ø4mm (Ø0.16”) Ø4mm (Ø0.16”) Ø4mm (Ø0.16”) Polar Pattern Omni Omni Omni Frequency... - Page 4 (0.41"×0.28"×0.6") (0.41”×0.28”×0.6”) (0.41”×0.28”×0.6”) Dimensions PS418S: Ø21×106mm PS418D: 84×63×22.5mm (0.83"×4.18") (3.3"×2.48"×0.89") E12A (With lavaliere) : E12A (With lavaliere) : E12A (With lavaliere) : Net Weight 19g (0.7 oz) 19g (0.7 oz) 19g (0.7 oz) PS418S: 118g (4.2 oz) PS418D: 245g (8.6 oz)
- Page 5 7.3 mm (0.29 in.) 4.0 mm (0.16 in.) 4.0 mm 7.3 mm (0.16 in.) (0.29 in.) 2.5 mm (0.10 in.) 6.0 mm (0.24 in.) Ø2.0 mm (0.08 in.) 10.5 mm (0.42 in.) Ø8.4 mm (0.33 in.) Ø10.5 mm Unit:mm (0.42 in.)
- Page 6 Ø21 mm (0.83 in.) 0.8 mm (0.03 in.) 63 mm (2.5 in.) 106 mm (4.18 in.) 84 mm (3.3 in.) Ø19 mm (0.75 in.) Unit:mm PS418S Preamp PS418D Preamp (E12AXLR) (E12ADXLR)
-
Page 7: Knowing Your Microphone
E12A FREQUENCY RESPONSE (OMNI) E12A KNOWING YOUR MICROPHONE Type of transducer Type of directivity Condenser Omni With an extremely light weight dia- With equal sensitivity in all directions, phragm, it is very sensitive to sound. an omni microphone doesn’t need Very small versions are available for to point toward the sound source. - Page 8 Superlux will repair or replace the parts. This warranty is only for the product which selling by distributor or agent which authorized by Superlux. However, the situation below is excluded in the warranty :...
