VitalConnect VitalPatch Quick Start Manual page 2

2. Remove from Pouch and Power-On
a. Tear open pouch at the notch and remove VitalPatch.
b. Allow the VitalPatch to "breathe" for at least 2 minutes
before proceeding to the next step.
c. Place VitalPatch on a flat surface. Press and release the
power button. A green light below the logo will flash
when VitalPatch is powered on (the light will go off).
3. Hold Against Chest
a. Hold the VitalPatch against the chest in the position
shown in the figure to the right.
b. Space two fingers below the jugular notch (dip at the
base of the neck).
c. Position diagonally with the three lines angled
downward away from the midline.
4. Remove Backings and Apply
DO NOT touch the adhesive with your fingers!
a. Hold one side of the VitalPatch down.
b. Lift the opposite side, and peel the backing off from the
center. Press against skin.
c. Peel the backing off from the other side of the VitalPatch.
d. Firmly press down both sides to attach to skin.
5. Optional Adhesive Overlay
If your care team recommends an adhesive overlay, please
review the instructional video. Go to the Menu button, tap
Help, and then tap VitalPatch Adhesive Overlay.
Section 3: Wearing the VitalPatch
• DO NOT shower or exercise for 30 minutes after
applying the VitalPatch.
• DO NOT expose the VitalPatch directly to the shower
head, and avoid excessive contact with soap or
scrubbing. Gently pat the VitalPatch dry after showering.
• DO NOT swim with the VitalPatch or use in a sauna,
steam room or hot tub.
• DO NOT wear more than one VitalPatch at a time.
Remove the old VitalPatch before applying a new one.
Section 4: Pairing with VistaPhone
1. Begin the Pairing Process
a. Tap Connect VitalPatch button.
b. Tap Search for VitalPatch ID to search for nearby
VitalPatch biosensors. A list will of IDs will display.
c. Tap the Bluetooth ID of your VitalPatch. If the Bluetooth
ID does not appear in the list, tap the Rescan button to
repeat the search. If the VitalPatch is still not listed, press
the power button on the VitalPatch again and tap the
Rescan button.
Note: If a previous VitalPatch is still connected, disconnect it
before pairing (see Section 6 on Page 3).
2
VitalConnect
Light flashes ON
LEFT
Midline
Peel off
backing
from center
• Each VitalPatch will last up to 7 days (168 hours).
To preserve data recorded by the VitalPatch, make sure
you are connected to the VistaPhone before the
VitalPatch expires.
• If discomfort or irritation occurs, the VitalPatch should be
removed. Contact your care team immediately.
• If the VitalPatch begins to fall off or lift from the skin,
contact your care team immediately.
Connect to VitalPatch
How do you want to connect?
Search for VitalPatch ID
Press and
release power
button
Side
LEFT
Hand
Select ID from list
Scanning for Devices
VC2B008BF_003C3C
VC2B008BF_0014D2
Hold
VitalPatch
down
