Cordless Die Grinder Kit
GS25-KL1, GS25-KL2, GR25-KL1, GR25-KL2
User Manual
User Manual
EN
ES
Manual del Usuario
FR
Manuel d'Utilisation
Manual do Usuário
PT
This manual contains safety and
product information for
IQV Cordless Die Grinder
IQV Cordless Battery Charger
IQV Cordless Batteries
This manual contains parts lists for
IQV Cordless Die Grinder
IQV Cordless Battery Charger
Este manual contiene información
de seguridad y de producto de
Amoladora Inalámbrica de IQV
Cargador de Baterías Inalámbricas de IQV
Baterías Inalámbricas de IQV
Este manual contiene la lista de
piezas de
Amoladora Inalámbrica de IQV
Cargador de Baterías Inalámbricas de IQV
Save These Instructions
Ce manuel contient les informations
de sécurité et de renseignements
sur le produit pour
Meule Sans Fil à Rectifier les Matrices IQV
Chargeur de Piles Sans Fil IQV
Piles Sans Fil IQV
Ce manuel contient des listes de
pièces pour
Meule Sans Fil à Rectifier les Matrices IQV
Chargeur de Piles Sans Fil IQV
Este manual contém informações de
segurança e sobre produtos para
Disco Abrasivo Sem Fio IQV
Carregador de Baterias Sem Fio IQV
Baterias Sem Fio IQV
Este manual contém listas de peças
para
Disco Abrasivo Sem Fio IQV
Carregador de Baterias Sem Fio IQV
45619418
Edition 2
August 2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the GS25-KL1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ingersoll-Rand GS25-KL1

  • Page 1 45619418 Edition 2 August 2010 Cordless Die Grinder Kit GS25-KL1, GS25-KL2, GR25-KL1, GR25-KL2 User Manual User Manual Manual del Usuario Manuel d’Utilisation Manual do Usuário This manual contains safety and Ce manuel contient les informations product information for de sécurité et de renseignements •...
  • Page 3 This section contains product safety information for • IQV Die Grinder • IQV Battery Charger • IQV Battery Esta sección contiene información de seguridad de productos de • Amoladora de IQV • Cargador de la Batería IQV • Batería IQV Cette section contient des informations sur la sécurité...
  • Page 4 Product Safety Information: Cordless Die Grinder Product Description A Cordless Die Grinder is a battery powered, hand-held, rotary power tool that is fitted with an inserted tool whose shank is clamped in a collet chuck. The inserted tool is typically a carbide burr, rotary file, small disk or stone permanently mounted on a shank or mandrel. WARNING General Safety Rules •...
  • Page 5 Power Tool Use and Care Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at • the rate for which it is designed. • Do not use the power tool if the switch does not turn it on or off.
  • Page 6 • When a suspension device is used, ensure that it is securely fastened. Failure to secure may result in loss of control, unexpected motion, or dropping of the tool. This power tool is intended to function as a grinder, sander, or polisher. Read all safety warnings, instructions, illustrations and •...
  • Page 7 • To prevent excessive overhang, the mandrel shall be inserted to the full depth of the gripping jaws of the collet and the resulting overhung length shall be no greater than the inserted depth. Improper installation may result in serious injury. Ensure that the grinding wheel or other abrasive accessory is correctly mounted and tightened before use.
  • Page 8 Product Safety Information: Cordless Battery Charger Product Description A Battery Charger is an electrical device that converts alternating current electric power to direct current electric power used to charge electric storage batteries. WARNING General Safety Rules Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious •...
  • Page 9 Product Safety Information: Cordless Battery Product Description A Battery is an electric energy storage device used as the power source for Ingersoll Rand Cordless Products. WARNING General Product Safety Information Read all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious injury. The term “power •...
  • Page 10 NOTICE Refer to Product Information Manual for Model Specific Safety Information. Safety Symbol Identification - Die Grinder Read Manuals Before Wear Hearing Wear Eye Risk of Wear Respiratory Operating Product Protection Protection Electric Shock Protection (Dwg. 16589525) Safety Symbol Identification - Cordless Battery Read Manuals Before Risk of Electric Shock...
  • Page 11 Información de Seguridad sobre el Producto: Amoladora de Matrices Inalámbrico Descripción del Producto Una amoladora de matrices inalámbrica es una herramienta motorizada rotatoria portátil que funciona con baterías y que lleva acoplada una herramienta cuyo vástago se fija a una pinza circular. La herramienta acoplada es, generalmente, una piedra molar de carburo, una lima rotatoria, un pequeño disco o una piedra, permanentemente montada en un vástago o mandril.
  • Page 12 El arsénico y el cromo que produce la madera sometida a tratamientos químicos. El riesgo que representa una exposición de este tipo varía según la frecuencia con que se realice este tipo de trabajo. Para reducir la exposición a estas sustancias químicas: trabaje en una zona bien ventilada y utilice un equipo de protección homologado, por ejemplo, una mascarilla especialmente diseñada para filtrar partículas microscópicas.
  • Page 13 • Si utiliza guantes, asegúrese de que no le impidan liberar el mecanismo del mando. Ya que eso podría provocar lesiones corporales. No despegue ninguna etiqueta. Sustituya todas las etiquetas dañadas. Las etiquetas le aportan información para la utilización segura •...
  • Page 14 • No ponga en funcionamiento la herramienta motorizada cerca de materiales inflamables. Las chispas podrían encender estos materiales. No utilice accesorios que requieran líquidos refrigerantes. La utilización de agua u otros líquidos refrigerantes podría provocar • electrocuciones o descargas eléctricas. •...
  • Page 15 Información de Seguridad Sobre el Producto: Cargador de Batería Inalámbrico Descripción del Producto Un cargador de baterías es un dispositivo eléctrico que convierte la corriente alterna en continua. Ésta se utiliza para cargar las baterías eléctricas de almacenamiento. ADVERTENCIA Normas Generales de Seguridad •...
  • Page 16 Información de Seguridad sobre el Producto: Batería Inalámbrico Descripción del Producto Una batería es un dispositivo de almacenamiento de energía eléctrica que se utiliza como fuente de alimentación para los productos inalámbricos de Ingersoll Rand. ADVERTENCIA Información General de Seguridad Sobre el Producto •...
  • Page 17 AVISO Si desea información de seguridad específica para su modelo, consulte el manual de información del producto. Identificación de los Símbolos de Seguridad - Amoladora de Matrices Inalámbrico Lea los manuales antes Utilice protección Utilice protección Riesgo de Utilice protección de utilizar el producto acústica ocula...
  • Page 18 Informations de Sécurité du Produit: Meuleuses Légères Sans Fil Description du Produit Une meuleuse sans fil est un outil rotatif à main, mû par un moteur à piles, équipé d'un outil dont la queue de fixation est serrée dans une pince de serrage.
  • Page 19 le plomb issu de peintures à base de plomb ; la silice cristallisée utilisée pour les briques, le ciment et autres produits de maçonnerie ; l'arsenic et le chrome issus du bois traité chimiquement. Les risques liés à ces expositions dépendent de la fréquence à laquelle vous effectuez ce type de travail. Pour limiter l'exposition à ces produits chimiques : travaillez dans un lieu bien ventilé...
  • Page 20 • Veuillez nettoyer régulièrement les évents d'aération de l'outil. Le ventilateur du moteur attirera la poussière vers l'intérieur du boîtier et l'accumulation excessive d'un métal en poudre peut provoquer des dangers électriques. Entretien • Faites entretenir votre outil par des réparateurs qualifiés et n’utilisez que des pièces de rechange identiques. Cela garantit le maintien de la sécurité...
