- Page 1 High temperature, ultra modulating Heat pump Installation and User manual Ref. 955000 Ref. 955010 Made in France Manual ref.: 1897763 Edition n 21.110...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 SAFETY ............. 3 compressors 1 and 2 - ..........................15 6.7 - Modifi cation..................15 2 PLEASE READ IMMEDIATLY ......5 6.8 - Decommissioning ................15 6.8.1- Interim Decommissioning of Product ..............15 2.1 - Conservation of documents ............5 6.8.2- Final decommissioning of the product ............15 2.2 - Symbols used ..................5 6.9 - Recycling and Disposal ..............15 2.3 - Abbreviations and acronyms ............5... -
Page 3: Safety
Danger of death if the pressure relief valves 1 SAFETY are missing or defective A defective pressure relief valve may prove Danger resulting from improper qualifi cations dangerous and could lead to burns or other injuries by, for example, the pipes bursting. •... - Page 4 This appliance is in compliance with the international standards concerning electrical REFRIGERANT CIRCUIT safety CEI 60335-1, CEI 60335-2-102. The CE branding on the appliance attests to its -Any work on the refrigerant circuit must compliance with the following directives: be carried out by a qualifi ed professional - Low voltage (LV): 2014/35/UE with a category 1 certificate of aptitude.
-
Page 5: Please Read Immediatly
2 PLEASE READ 3 DELIVERY AND IMMEDIATLY STORAGE This technical installation manual forms part of the appliance which 3.1 - Delivery terms and conditions it refers to. In order for the warranty to be valid, the instructions must be read prior to using the appliance. In general, the material is transported at the recipient’s own risk. -
Page 6: Introduction
4.2 - Accessories (included) 4 INTRODUCTION The components described below are delivered with the Heat Pump: 2-core sheathed cable linking the à Heat Pump and the Pilot (lg 10m) Hydraulic Fitting à (included a 1’’ fi lter valve, a safety valve assembly 1’’ , a hydraulic connection [ reduction F3/4 M1’’... -
Page 7: Installation
5 INSTALLATION 5.1 - Standard confi guration 2 electrical supplies 230V single phase Pilot heat pump hydraulic connection • The Heat pump must be installed outside exclusively. • Avoid any obstruction of the airfl ow of the ventilator. Ensure that there is nothing blocking the exchanger’s air circulation. Ensure that the Heat pump is placed so that it is sheltered from dominant winds. -
Page 8: Installation Site
5.2 - Installation site The Heat pump is designed to be installed outdoors exclusively, while respecting a minimum of free space around the appliance in an area free from excessive levels of dust. It should never be placed in an enclosed space. The Heat pump is designed to operate in rainy weather conditions, although it can be installed under a well ventilated shelter (with a large enough opening to allow suffi... -
Page 9: Setting Up
5.3 - Setting up The Heat pump must be installed on a hard and stable base, which is suffi ciently raised from ground level to avoid risks of damage in case of fl ooding or snow. • € • • - Retrieve the 4 heat pump attachment tabs from the transport pallet €... -
Page 10: Hydraulic Installation
5.4 - Hydraulic installation 5.4.1 - Hydraulic connections on the installation In order to ensure that fl uids can circulate properly, it is advisable to check that the sizing of piping in the circuit is appropriate between the Heat Pump and the Pilot. All piping should be thermally insulated, especially the connecting pipes from the Pilot to the Heat Pump. -
Page 11: Hydraulic Connection Between Heat Pump And Pilot
5.4.2 - Hydraulic connection between Heat 5.5 - Connecting to the power supply pump and pilot A suffi cient fl ow rate should be ensured so that the range of 5.5.1 - General recommendations temperature between the outlet and inlet of the Heat Pump does not exceed 5°C when the Heat Pump is operating at full power (take a temperature measure when the HTi Heat Pump is in Ensure that the power supply is suffi... -
Page 12: Accessing The Connection Terminals
Connecting terminals 5.5.4 - Connection to the power supply The terminal strips are spring-loaded «Cage Clamps». The HTi Heat pump is CE-marked. It is compliant with French standard NF C15-100 as well as European standards EN 61000-3-3 For Handling, use the following : and EN 61000-3-11, among others. -
Page 13: Communication Bus Cable Between The Heat Pump And The Pilot
Power supply 230V - 50Hz Fuse or thermical-magnetic circuit breaker Phase Ground Neutral See § «Recommendations for conection the system to the power supply» 5.5.5 - Communication bus cable between the heat pump and the pilot Colour of wire Brown White Black 1 : Hydraulic pilot... -
Page 14: Maintenance And Troubleshooting
Any work on the refrigerant circuit must be undertaken by a 6 MAINTENANCE AND qualifi ed professional with a category 1 certifi cate of aptitude. 1. It is forbidden to release gas from the refrigerant circuit into the TROUBLESHOOTING atmosphere, and it is obligatory to recover the refrigerant before undertaking any work on the circuit. -
Page 15: Sensor Data Curve Charts
6.7 - Modifi cation 6.6 - Sensor data curve charts Any modifi cation of the device is prohibited. Any replacement of components must be done by a professional with original parts 6.6.1 - Water inlet and outlet - de-icing sensor from the manufacturer. -
Page 16: List Of Spare Parts
7 LIST OF SPARE PARTS Reference number Rep. Designation 155000 155010 4994445 4994445 Compressor remplacement kit 4994307 4994308 Condenser kit 1473042 1473043 Evaporator 4994304 4994305 4-way valve kit 4994306 4994306 Pressure reducing kit 1473040 1473040 Liquid reservoir tank 1473041 1473041 Dehumidifying fi... -
Page 17: Warranty
The warranty only applies to parts which we (AUER) identify as having - Absence of frost protection for the appliances in the installation. been defective at manufacture. If necessary, the part or product should... -
Page 18: Appendix
APPENDIX A1 - Technical specifi cations A1.1 - General characteristics A1.2 - Performances 155000 155010 Water regime 155000 30/35 40/45 47/55 55/65 Maximum temperature 70 °C 70 °C MAX heat ouput 6,00 6,00 6,00 6,00 R290 refrigerant fl uid 0.420 kg 0.600 kg Nominal heat ouput * 12 °C... -
Page 19: A2 - Eu Declaration
A2 - EU declaration A4 - Treatment of the water in the heating circuit This device complies with international electrical safety standards IEC 60335-1, IEC 60335-2-40. The CE marking present on the device attests to its conformity with the following Community Directives, of which it meets the essential requirements: It is MANDATORY to read the additional document concerning the quality of... -
Page 20: A5 - Dimensions
- Protect the installation against corrosion with a corrosion Corrosion inhibitor : inhibitor, example: SENTINEL X100. Or against corrosion - protects against the formation of limescale and freezing with an inhibitor with an anti-freeze - prevents «pinhole» type corrosion additive. Example : SENTINEL X500 or SENTINEL R600. - prevents, in new installations, the formation of sludge •... -
Page 21: A5.2 - Hti 70 8 Kw Heat Pump
A5.2 - HTi 8 kW Heat pump 1 - Heat pump outlet 2 - Heat pump inlet 3 - Communication bus 4 - Electrical supply 6 & 8 KW HEAT PUMPS MANUAL... -
Page 22: A6 - Product Technical Information Sheet
A6 - Product technical information sheet A6.1 - HTi 6 kW Heat pump Compliant with EU regulation n°811/2013) AUER Marque / Brand name Pompe a chaleur Air- Eau / Air- Water heat pump Type / Type HTI 6 Modèle / Model 35°C... -
Page 23: A6.2 - Hti 70 8 Kw Heat Pump
A6.2 - HTi 8 kW Heat pump Compliant with EU regulation n°811/2013) AUER Marque / Brand name Pompe a chaleur Air- Eau / Air- Water heat pump Type / Type HTI 8 Modèle / Model 35°C 55°C Classe d'efficacité énergétique chauffage / Heating seasonnal energy efficiency class... -
Page 24: A7 - Internal Wiring Diagram
A7 - Internal wiring diagram 6 & 8 KW HEAT PUMPS MANUAL... - Page 25 TwOUT - Water outlet temperature sensor TwIN - Water inlet temperature sensor Tévap - Condenser outlet temperature sensor Tair - Air intake temperature sensor TCP1 - Compressor 1 temperature sensor - High pressure sensor - Low pressure sensor~ HP1 - Compressor 1 high pressure switch - Fuse 5x20 4A - Fuse 10x38 20A - Defrosting solenoid valve...
-
Page 26: Notes / Maintenance
NOTES / MAINTENANCE Refrigerant collected Date Technician Work carried out Refrigerant loaded 6 & 8 KW HEAT PUMPS MANUAL... - Page 27 NOTES / MAINTENANCE Refrigerant collected Date Technician Work carried out Refrigerant loaded 6 & 8 KW HEAT PUMPS MANUAL...
- Page 28 Rue de la République CS 40029 80210 Feuquières-en-Vimeu Spare Parts Department Tel. : 03 22 61 21 21 Fax : 03 22 61 33 35 E-mail : pieces@auer.fr Technical Assistance Department* E-mail : enr@auer.fr *Technical assistance is reserved for professionals...
