- Page 1 PRIMO pilot Pilot for HRC & HTi heat pumps PRIMO pilot Technical installation manual for heat pump Ref. 753010 Made in France Ref. notice : 1898020 N° édition : 22.28 * Concerns the HTI 6 and 8 single-phase models...
-
Page 2: Table Of Contents
4.4.3 - Exterior sensor ......................14 7.2.6.3 - Back-up ......................24 4.4.4 - Domestic water sensor ..................14 7.2.7 - Errors indicated by the pilot ................25 4.4.5 - Underfl oor safety device of the 65°C safety aquastat (OPT) with manual reset (OPT) ..................14 PRIMO PILOT INSTALLATION MANUAL... -
Page 3: 1-Safety
Danger resulting from improper qualifi cations 8 - SPARE PARTS ..........29 • Any work carried out by an unqualifi ed person 8.1 - PRIMO Pilot ..................29 can result in damage to the installation or in 8.2 - Hydraulic block ...................29 physical injury. - Page 4 If the electrical supply cable is damaged, it must be replaced by the manufacturer, their customer service technicians, or by a qualifi ed professional to prevent any risk of injury or danger. • The devices for electrical cut-off must remain accessible. PRIMO PILOT INSTALLATION MANUAL...
-
Page 5: -Please Read Immediately
Admissible storage and transport temperatures are from -20°C to +60°C. The PRIMO Pilot must be stored and transported on its pallet and This technical installation manual forms part of the appliance which in its original packaging and empty of water. -
Page 6: Introduction
7 days of the week using programmable ranges 3.4.2 - Control The PRIMO Pilot is delivered ready to use in its factory set • Ambient temperature thermostat (TA) confi guration (see § «Set-up»). 2 wires - allows to control the temperature in the... -
Page 7: Operating Principles
3.5 - Operating principles 18L buff er tank Heat pump Heating element Decoupling pump (optional) Power terminal By-pass (optional) Circulator pump Heating circuit (radiator or underfl oor heating) Electronic circuit board Domestic hot water circuit Expansion vessel Decoupling kit PRIMO PILOT INSTALLATION MANUAL... -
Page 8: Installation
Automatic air purging valves should be placed at each high point of the installation, and manual air purging The PRIMO Pilot must be placed in an area which is free from frost valves should be installed on each radiator. -
Page 9: Frost Protection
4.2.1.6 - Frost Protection 4.2.1.9.1 - Filling water Frost protection is necessary if the PRIMO Pilot is switched off during The materials used for producing a heating circuit are of diff erent the winter months (ex: secondary residence, etc...). natures. Instances of corrosion may occur through galvanic coupling in both new and existing installations. -
Page 10: Purging The Installation
Heat Pump must, consequently, be lower than 2.5 bars. Example : If the Heat Pump is positioned 5m below the PRIMO Pilot, the pressure reading on the PRIMO Pilot would be 0.5 bars less than the real pressure of the water in the Heat Pump. -
Page 11: Hydraulic Connections
4.2.2 - Hydraulic connections Hydraulic Description connections 1 Outlet towards DHW & Heating 3/4’’ 2 Inlet from HP 3/4’’ 3 Outlet towards HP 3/4’’ 4 Inlet from DHW circuit 3/4’’ 5 Inlet from Heating circuit 3/4’’ 6 Draining valve PRIMO PILOT INSTALLATION MANUAL... -
Page 12: Decoupling Kit
6) Connect the power cable and the PWM cable to the connectors of the circulator pump. 7) Pass the wires through the grommet of the PRIMO Pilot. The power cable and the PWM cable must not be placed in the same grommet. -
Page 13: Electrical Connections
However, it is necessary to connect the following elements to the relevant terminals: • The general electricity supply. • The diff erent sensors or thermostats on the PRIMO Pilot. • The 2-core sheathed cable connecting the PRIMO Pilot and the Heat pump (10m length supplied). -
Page 14: Control Connection Towards The Heat Pump
- Connect the water sensor to the «BAL» terminals of the PRIMO Pilot. 4.4.2 - Ambient temperature control In an installation with both thermostatic valves and a room 4.4.5 - Underfl oor safety device of the 65°C... -
Page 15: Set-Up
- All hydraulic connections are properly tightened. - The correct voltage at the mains switch. When the PRIMO Pilot is turned on for the fi rst time, it will ask you to confi rm the language of use (French, English, German, Italian,... -
Page 16: Step 3: Purging The Installation
And will automatically put itself in standby mode. The PRIMO Pilot can be left in this state until fi rst use. During the cycle, check that the automatic purgers are open and regularly activate the manual purgers. -
Page 17: Settings And Functions
9 character message Current comfort mode Programming Comfort mode Eco mode active Frost protection Holiday mode mode Day of the week: (1= Monday; 2= Tuesday...) Display zone: temperatures, pressure, settings, time... PRIMO PILOT INSTALLATION MANUAL... -
Page 18: Menus
Activation of a special air purge cycle - manual Manual operation of component for diagnostics - COMMISSIO Access to the set-up - modbus Remote control setting up - software Manage software version Press to exit the menus and sub-menus. PRIMO PILOT INSTALLATION MANUAL... -
Page 19: List Of Parameters Which Can Be Set
(if connected) P231 AUTO Set temperature of heating water °C 20 to 70: setting fi xed in °C P232 P233 to 70 Maximum set temperature (TCMA) for the heating circuit °C PRIMO PILOT INSTALLATION MANUAL... - Page 20 Domestic water request diff erential: loss of heat from the domestic hot P281 2 to 15 °K water tank compared to the set temperature to start a new heating cycle. P282 Not concerned Do not change the setting p288 PRIMO PILOT INSTALLATION MANUAL...
-
Page 21: Description Of Functionalities
(P234 = 2). TCMI 6.5.1.4 - Ambient temperature reactivity The reactivity function allows the PRIMO Pilot to increase its set temperature for heating when the temperature read by the ambient temperature sensor is far from the set temperature. TEMI TEMA °C... -
Page 22: Automatic Summer/Winter Changeover
6.5.4 - Functions related to the production of domestic hot water With the automatic summer/winter changeover function activated, the PRIMO Pilot decides when to enact the changeover from one 6.5.4.1 - Domestic priority sharing season to another, independently from the choice made by the user Allows the operation of the heating circuit at the end of the domestic via the on/off button. -
Page 23: Maintenance
In the user menu, the USB sub-menu allows you to set the frequency of monitoring of operating history (every minute, every 30 seconds..). These changes are not retroactive, they will only be visible in the USB history in the period following the changes being applied. PRIMO PILOT INSTALLATION MANUAL... -
Page 24: Water Sensors
7.2.5 - Consulting the counters that circulation is working properly. To activate forced operation press To consult the PRIMO Pilot and heat pump counters, enter the Expert menu by pressing simultaneously on 7.2.6.2 - 3-way valve and select the COunters sub-menu. -
Page 25: Errors Indicated By The Pilot
- Problem with refrigerant fl uid load CP2 ovrht. Multiple overheatings on - The set temperature for heating during warmer months is too high heat pump stopped manual compressor 2 - Problem with refrigerant fl uid load PRIMO PILOT INSTALLATION MANUAL... - Page 26 The messages signalled by «DIAG» are informative and do not interrupt the operating of the PRIMO Pilot. This information comes from the analysis of the operating history of the PRIMO Pilot and is designed to assist you in the maintenance of yout installation.
- Page 27 - The set temperature for heating during colder months is too low - Problem with refrigerant fl uid load - Cause could be a default on defrosting check valve or on thermostatic valve Maintenance on fl uid circuit must be done by a qualifi ed engineer PRIMO PILOT INSTALLATION MANUAL...
- Page 28 - insuffi cient fl ow rate to irrigate the pilot back-up stopped manual outlet Defect of incorrect connection of the temperature sensor at the T-RE Turn TePAC defect heat pump stopped automatic after repair heat pump inlet (TwIN) PRIMO PILOT INSTALLATION MANUAL...
-
Page 29: Spare Parts
8 - SPARE PARTS 8.1 - PRIMO Pilot Rep. Reference Description B4485653 Front Panel B1759317 Enjoliveur B4485651 Upper cover B4485652 Side panel B4479967 Terminal access door B1448815 Pipe B1448812 hydraulic starting block pipe B1448814 D Pipe B1448813 hydraulic block pipe to expansion vessel... -
Page 30: Warranty
9.2.2.4 - Electrical connections The warranty only applies to parts which we (AUER) identify as having been defective at manufacture. If necessary, the part or product should be returned to the manufacturer, but only with prior agreement from Cases (not limited) for exclusion from warranty: our technical department. -
Page 31: Appendix
APPENDIX A1 - Technical specifi cations A1.1 - General characteristics PRIMO Pilot Power supply cable cross-section 3 G 2,5mm² Circuit breaker Electrical supply 230V single phase Buff er volume 18 L Dimensions (W x H x D) 400mm x 790mm x 340mm... -
Page 32: A2 - Hydraulic Schematic Diagrams
> 10m and < 15m 24/26 28/30 32/34 > 15m and < 25m 28/30 32/34 36/38 Maximum pressure 2,5 bar 2,5 bar 2,5 bar 2,5 bar > 25m and < 50m 32/34 36/38 42/44 PRIMO PILOT INSTALLATION MANUAL... -
Page 33: A3 - Wiring Diagram
A3 - Wiring diagram PRIMO PILOT INSTALLATION MANUAL... -
Page 34: A4 - Recap Of Functions
9 character message Current comfort mode Programming Comfort mode Eco mode active Frost protection Holiday mode mode Day of the week: (1= Monday; 2= Tuesday...) Display zone: temperatures, pressure, settings, time... PRIMO PILOT INSTALLATION MANUAL... -
Page 35: A4.2 - Menus
Activation of a special air purge cycle - manual Manual operation of component for diagnostics - COMMISSIO Access to the set-up - MODBUS Remote control setting up - software Manage software version Press to exit the menus and sub-menus. PRIMO PILOT INSTALLATION MANUAL... - Page 36 Rue de la République CS 40029 80210 Feuquières-en-Vimeu Spare parts department Tel. : 03 22 61 21 21 Fax : 03 22 61 33 35 E-mail : pieces@auer.fr Technical assistance department* E-mail : enr@auer.fr *Technical assistance is reserved for professionalss...
