- Page 1 AR8MX- Series Quick Start Guide Ver 0.1 This Quick Start Guide is for BCM AR8MXMM ARM motherboards based on Freescale i.MX8 Cortex A53 platform.
- Page 2 Contents 1. Overview…………………………………………………….3 2. Mainboard Illustration…………………………………….4 3. Jumper and Connector pin out………………………….5 AR8MXMM Quick Start Guide Page 2...
- Page 3 1. Overview i.MX8M Mini Quad Core SoC Ultra Compact, Ultra Low Power ARM Motherboard NXP i.MX8M Mini 4x Cortex®-A53 cores and 1x Cortex-M4 processor Optional AR8MXMN - i.MX8M Nano Processor (4x Cortex®-A53 cores and 1x Cortex-M7 core) 1GB Onboard DDR4 Memory (expandable up to 2GB Max) Onboard 8GB eMMC Flash, 1 x MicroSD Card Slot GC NanoUltra 3D (1 shader) + GC320 2D, OpenGL ES2.0 1 x LVDS and 1 x MIPI-CSI...
- Page 4 2. Mainboard illustration: Locations of IO ports & Jumper settings definition Board Top View： Board Side View： AR8MXMM Quick Start Guide Page 4...
- Page 5 3. Jumper Settings and Pin Definition JP2: Boot JP3: Boot Device Device Connector type：HDR 2x4 2.0mm Connector type：HDR 2x4 2.0mm Definition Definition Definition Definition D3V3 D3V3 D3V3 D3V3 BT_CFG2 BT_CFG4 BT_CFG10 BT_CFG12 D3V3 D3V3 D3V3 D3V3 BT_CFG3 BT_CFG5 BT_CFG11 BT_CFG13 Default Default BOOT MODES...
- Page 6 JP1: LVDS JP5: BL PWR Connector type：HDR 1X3 2.0mm Connector type：HDR 1X2 2.0mm Definition Definition D3V3 BL_PWR_SEL LCD_PWR Default Default Jumper selector LVDS0 PWR SEL Jumper selector LVDS0 PWR SEL Open 12V(For BL) 1 － 2 3.3V Close 17V(For VGH 7”panel) 2 －...
- Page 7 CN2：8BIT DIO(3.3V) CN3：Touch Panel (I2C) Connector type：HDR 1x8 2.0 Connector type：1x6 1.25 Definition Definition DIO0 DIO1 DIO2 DIO3 DIO4 DIO5 D3V3 DIO6 DIO7 CN4：DC-IN 5V Connector type：6.5/2.5mm CN6: LVDS LVDS CONN. Connector type : CSI-4585-300R 30DP 1.25 efinition Definition Definition LEDBL+ LVDS0_CH0_TX3_P PNL_VHL...
- Page 8 CN7：CSI Connector type：CSI-4585-300R 30DP 1.25 Definition Definition Definition CSI_PWR1 CSI_DP3 CSI_PWR1 CSI_DP2 CSI_DN3 CSI_I2C_SCL CSI_DN2 CSI_DP0 CSI_PWDN CSI_I2C_SDA CSI_CLKP CSI_DN0 CSI_PWR3 CSI_nRST CSI_CLKN CSI_DP1 CSI_MCLK CSI_PWR2 CSI_Dn1 CSI_PWR2 CN9：Front Panel CN8：LAN Connector type：RTA-164AAK1A Connector Type: Header 1x4 2.0 Definition Definition Definition GE_MDI0+ GE_MDI3+...
- Page 9 CN13：Console(M7) CN14：Console(A53) Connector type：Header 1X4 1.25 Connector type：Header 1X4 1.25 Definition Definition D3V3 D3V3 UART4_TXD UART2_TXD UART4_RXD UART2_RXD CN15：COM2 CN16：COM1 Connector type：Header 1X5 1.25 Connector Type: Header 1X5 1.25 Definition Definition UR3_TXD UR1_TXD UR3_RXD UR1_RXD UR3_RTSB UR1_RTSB UR3_CTSB UR1_CTSB CN17：HP JACK CN19：MIC IN Connector type：3.5mm Phone Jack Green Connector type：Header 1X4 1.25...
