- Page 1 Electric Bike Fiido M1-Pro User's Manual SHENZHEN QLHX TECHNOLOGY CO., LTD. No.60, Dawei area 1, Longxin Community, Baolong Street, Longgang District, Shenzhen http://www.fiido.com email: support@fiido.com Made in China Made in China...
- Page 2 FIIDO Electric Bicycle Catalog I.Important Note II.Bike Diagrams III.Unfolding Instructions IV.Folding Instructions V.Specifications...
- Page 3 I．Important Note This manual includes important safety performance and service information. Please make sure to read the following warnings before using our products for the first time. a) If you lend your e-bike to other people, please confirm that he/she has read this manual to decrease the risk of accident. b) Please wear a suitable and safe helmet before riding, please wear clothes with fluorescent and reflective stripes when riding at night.
- Page 4 II. Bike Diagrams 1.Seat tube 5.Chain 9.Battery box 13.Crank 17.Headlight 2.Quick lock 6.Shock absorber 10.Charge port 14.Handle bar 3.Brake disc 7.Controller box 11.Chain wheel 15.Stem 4.Motor 8.Folding system 12.Pedal 16.Folding system...
- Page 5 １ 1.Brake power off system 10.Electric assist gear 4.Power on/off button(Long press on or off) 7.Power off brake 2.Light/horn button 11.Speed-up rotating handle 5.Power adjustment 8.Battery level 3.Horn 12.USB output port 6. Speed regulation 9.speed (Note: The bike will automatically shut down when it is stationary if not used within 10 minutes.) 14.Battery charging port 13.Hold and press with your fingers, folding the pedal.
-
Page 6: Unfolding Instructions
III. Unfolding Instructions 1.Fold the riser to the upper end,lock the riser folding handle,adjust the riser safety hook to the tightening state,and adjust the position of the T handle. 2.Install front wheel; First install the front wheel on the front fork and lock the front wheel with screws. 3.Open the clip on the seat tube clamp and insert the seat tube into the position within the marking line on the seat tube. -
Page 7: Folding Instructions
IV．Folding Instructions Step 1. Open the quick lock on the head end and make the handle perpendicular to the care frame. Step 2. Open the quick lock on the Stem, lower the riser, and lock the quick lock. Step 3. Open the Seat Tube quick lock, decentralized seat and lock the quick lock. Note: Both the riser and the seat tube are marked with a safe (MAX or MIN). -
Page 8: Specifications
V．Specifications Name Specification Electric Bike System Fiido System Electric Motorcycle Support Power Assist System Support Power Assist System 3 Gears Assist Max Load weight 120kg Maximum Speed 50km/h Maximum Range Power assisted models up to 60KM～80KM Battery High quality lion battery 48V 12.8Ah Battery adaptation DC 54.6V2A...
