AKRON
FIXED
HEIGHT TRACTION
Models
900-A, 8900-8
®
AKRON
VARI-
HEIGHT TRACTION
Models
901-A, 902-A, 8901-8, 8902-8
®
AKRON
MOBILE
TRACTION SYSTEM
Model
8904-8
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKRON 900-A and is the answer not in the manual?

Questions and answers

Related Manuals for Huntleigh AKRON 900-A

Summary of Contents for Huntleigh AKRON 900-A

  • Page 1 ® AKRON FIXED HEIGHT TRACTION Models 900-A, 8900-8 ® AKRON VARI- HEIGHT TRACTION Models 901-A, 902-A, 8901-8, 8902-8 ® AKRON MOBILE TRACTION SYSTEM Model 8904-8 USER MANUAL...

  • Page 3: Table Of Contents

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 Contents Introduction Warnings, Cautions General Warnings Installation Operation 5-13 Accessories – Operating Instructions 14-22 Cleaning and Decontamination Troubleshooting Maintenance Warranty and Service Revision Status Technical Specification "The mark on this product demonstrates conformity with the EC Directive 93/42/EEC."...

  • Page 4: Introduction

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 1. Introduction Always keep this Operating Manual available for reference. Warnings & Cautions WARNINGS Warnings identify possible hazards in procedures or conditions which, if not correctly followed, could result in death, injury or other serious adverse reactions. CAUTIONS Cautions identify conditions or procedures which, if not correctly followed, could result in equipment failure or damage.

  • Page 5: Installation

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 2. Installation Adjustable Foot WARNING Lock castors before adjusting. Lock castors first. Adjust foot. Lock foot by tightening half nut. WARNING Do not insert the 2-pin mains connector directly into a 3-pin 13A mains outlet. Always use the adapter provided.
  • Page 6 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 2. Installation Fixed Height Traction Table Assembly (900A, 8900-8) WARNING Ensure legs are secured correctly using supplied fittings, prior to use. To assemble: Position legs up to the correct end of the table. Locate bolts through holes.

  • Page 7: Operation

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Elevation Controls WARNING Safely position patient before elevating table. Position all electrical cables away from the moving parts. Position Hand/Foot switch where accidental operation is not possible. Hydraulic Models PUMP PEDAL TO LIFT PEDAL TO RAISE TABLE LOWER TABLE...
  • Page 8 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Foot Bar Switch Press tube done to raise table Lift tube up to lower table Wheel Locking WARNING Lock couch wheels/castors prior to patient transfer or treatment. The retractable castors are not designed for transportation of patients. Disconnect and coil electrical cord away from moving parts prior to repositioning table.
  • Page 9 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Head & Foot Sections CAUTION Support upholstery section while manually altering the angle. Head Section Operating Lever Press lever UP to alter section angle. Support section when altering angle. Release lever to lock section in position. Angles = +85°...
  • Page 10 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Sliding Frame (900A, 901A, 902A) WARNING Ensure when Pelvic and Thoracic Harnesses are in use, the Sliding Top Frame is released before traction commences. Sliding Frame Closed Sliding Frame Open To release the top, release the lever located towards the head end of the table.
  • Page 11 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Fixed Traction Mounting Bracket (Model 2F1970Z) The fixed traction mounting bracket comes as standard as part of the traction table. It is fitted to the foot end of the table to secure the ATP9 Traction Machine. WARNING Ensure that the electrical cord from the ATP9 is coiled away from the rotating Mounting Platform when in use.
  • Page 12 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Fixed Traction Mounting Bracket (Model 2F1970Z) Operating Instructions To raise the support table platform (item H), unscrew the height adjustment clamp (item J) positioned on the side of the bracket (item A). To lock the platform, tighten the height adjustment clamp.
  • Page 13 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Mobile Traction Stand (8904-8) WARNING Check condition of straps. If worn out replace immediately. Only use Huntleigh Akron Straps and Harnesses. ATP9 Traction Machine ATP9 Traction Machine Clamp Height Adjustment Clamp Upholstered Buffer Pad...
  • Page 14 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Mobile Traction Stand (8904-8) To secure the Mobile Traction System to the table :- Position the stand at the end of the table with the buffer pad against the upholstery. To adjust the buffer pad, simply release the clamp knob.
  • Page 15 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 3. Operation Counter Traction Straps (CT9000) Two anchor brackets are provided for securing the thoracic counter traction straps at the opposite end of the table to the mobile traction unit. The brackets are held into position by tightening the grub screws onto the box section of the table. The brackets must be fitted with the hole situated in the bar pointing outwards.
  • Page 16 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories ATP9 Head Halter (ATP9) (HH51) ATP9 Head Halter Cervipillo + Cover (ATP) (HH51) (JC102 + CC103) Thoracic Harness Pelvic Harness Counter Traction Straps (CT81UV) (PB61UV) (CT9000) Flexion Stool Spreader Bar (FS900) (SC31) When purchased as a Traction Package the above accessories are supplied as standard.

  • Page 17: Accessories - Operating Instructions

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions ATP9 Traction Unit WARNING Before the ATP9 Traction Unit is used, please read the ATP9 User Manual, paying particular attention to safety instructions, warnings and cautions. Flexion Stool (Model FS900) WARNING The Flexion Stool is not to be used as a seat.
  • Page 18 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions Traction Swivel Bracket and Mount (Model Option 8906) WARNING Always lock the swivel bracket before treatment commences. Ensure that the electrical cord from the ATP9 is coiled away from any moving parts of the swivel bracket.
  • Page 19 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions Traction Swivel Bracket and Mount (Model Option 8906) Operating Instructions To raise the support table platform, unscrew the height adjustment clamp (item G) positioned on the side of the bracket (item H).
  • Page 20 WARNING Check harnesses for wear before use. Worn and frayed harnesses should not be used and should be replaced. Use only Huntleigh Akron harnesses. Fitting Instructions Raise the foot section to its highest position and remove the black plastic end caps on the top of the foot frame section.
  • Page 21 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions Cervical Sitting Unit (Model 8903) Fitting Instructions (Continued) The overhead flexion pulley adjustment collar (item D) should then be placed over the cervical mast (item B) and secured in the required position by tightening the knob on the side of the collar, making sure the hook is pointing downwards.
  • Page 22 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions Cervical Sitting Unit (Model 8903) Operating Instructions The patient may now be seated against the foot section/backrest. Adjust the backrest to make the patient comfortable. Place the head halter over the patient’s head/neck area, so that the halter supports the head under the chin and across the back of the head.
  • Page 23 WARNING Check harnesses for wear before use. Worn and frayed harnesses should not be used and should be replaced. Use only Huntleigh Akron harnesses. Be sure to lock the Rolling Section at the end of any traction procedure. The unique design of the traction table allows the harnesses to be fitted after the patient has been positioned on the traction table.
  • Page 24 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 4. Accessories – Operating Instructions Traction Procedures (Continued) Position the flexion stool (model FS900) under the calves of the legs of the patient and adjust the height for optimum comfort. It may help the patient to relax if the knees are strapped together. To remove the slack from the harnesses using the ATP9 Traction Machine proceed as follows: With the hold and rest timers set to zero, set the high force control to indicate 35 Kg or less if required.

  • Page 25: Cleaning And Decontamination

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 5. Cleaning and Decontamination WARNING Do not use Alkalis or other organic solvents for routine cleaning. Replace torn or damaged vinyl immediately. Always cover vinyl with fresh paper or sheet between patients. If contamination is known or suspected always decontaminate couch before use.

  • Page 26: Troubleshooting

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 5. Cleaning and Decontamination Decontamination of Traction Straps It is not recommended that the straps are laundered on a regular or routine basis as this will eventually compromise the integrity of the material and associated Tac-Flex. However, under certain conditions, i.e. when the straps become heavily soiled or when they are suspected or known to have been in contact with an infectious organism, they can be laundered or decontaminated using one of the following methods.

  • Page 27: Maintenance

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 7. Maintenance Check couch visually before use. Carry out routine servicing every six months or more frequently if in heavy use. Routine servicing or repair must only be performed by suitably qualified person. WARNING Before commencing any maintenance activity, disconnect the couch from the electrical supply.

  • Page 28: Warranty And Service

    A Member of the Huntleigh Technology PLC Group of Companies © Huntleigh Technology PLC 2001. If for any reason your couch is being returned, please inform Huntleigh Akron prior to sending, and: Clean the product, as described in the cleaning section.

  • Page 29: Revision Status

    A Member of the Huntleigh Technology PLC Group of Companies © Huntleigh Technology PLC 2001. If for any reason your couch is being returned, please inform Huntleigh Akron prior to sending and: 1. Clean the product, as described in the cleaning section.

  • Page 30: Technical Specification

    AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8 10. Technical Specification 900A 901A 902A 8904-8 Head Length (cm) 70±1.5 70±1.5 70±1.5 Mid Length (cm) 14±1.5 + 22±1.5 14±1.5 + 22±1.5 14±1.5 + 22±1.5 Foot Length (cm) 92±1.5 92±1.5 92±1.5 Width (cm) 70±1.5 70±1.5 70±1.5...
  • Page 31 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8...
  • Page 32 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8...
  • Page 33 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8...
  • Page 34 AKRON 900A, 901A, 902A, 8900-8, 8901-8, 8902-8, 8904-8...
  • Page 36 Huntleigh Akron, 1 Farthing Road, Ipswich, Suffolk, IP1 5AP, England Tel: +44 (0) 1473 461042 Fax: +44 (0) 1473 462924 792-055-04...
