- Page 1 USER’S MANUAL JP5520 10-20KVA ...
-
Page 2: Table Of Contents
……………………………………………………………………………3 Introduction Foreword………………… ………………………………………………………………3 …………………………………………………………………3 Dimension Structure ………………………………………………………3 10-20KVA UPS appearance ……………………………………………………………………………3 Put by UPS Handle or move……………………………………………………………………………3 Put by………………………………………………………………………………………3 …………………………………………………………5 Installation and connection Caution ……………………………………………………………………………………5 Single UPS installation……………………………………………………………………7 Connection wire option……………………………………………………………………7 …………………………………………………………………………8 UPS operation Prepare before for turn-on…………………………………………………………………8 Two kinds of LCD panel for choosing ……………………………………………………8 First start-up operating ……………………………………………………………………9 …………………………………………………………………11 Condition handling... -
Page 3: Introduction
（1）Foreword JP5520 series UPS are development produce compact and intelligently uninterrupted power system by JALPOWER. Which ensure you to operating computer in a stable and pure power circumstance, and to manage network system intelligently. UPS have becoming necessary equipment to computer and information system. - Page 4 Fig3 Option on place of the UPS b. Maintain a minimum clearance of 100 mm all around the UPS for proper air flow and cooling Fig4. Fig4 c. Free form sun shine, raindrop or moisture Fig5, Fig6. Fig 5 Fig6...
-
Page 5: Installation And Connection
d. Far form fire source and high temperature, prevent over temperature Fig7. e. Don’t put by objects on top of UPS Fig 8. Fig7 Fig8 f. Free form moisture, flammable liquids, gasses or corrosive substances Fig9. Fig9 g. Operation environment temperature 0~40℃。 4. - Page 6 Fig10 c. Free form electric operating, caution construction safety, will be input mains switch “off”. d. If properly input voltage for use all powerful meter measurement. e. Power wire, terminal use of high quality products, restrain use of faulty products. f.
-
Page 7: Single Ups Installation
（2）Single UPS installation Installation method: refer to Fig1. Use screw driver to tear down four screws. Opening front panel, namely seeing downside distribution box of power switch. Refer to Fig12、13. Fig12 SWITCH:BYPASS mode and AUTO mode transfer. Fig13 SW1:city input switch SW2:bypass switch SW3:battery input switch ... -
Page 8: Ups Operation
5. UPS Operation （1）Prepare before for turn-on For normal running be able to the UPS. Please validation below thing before for turn-on, refer to Fig2. a. Validation be located “OFF” for all power switch. b. Again validation primary for installation places. c. -
Page 9: First Start-Up Operating
（3）First start-up operating After validation properly of more than thing, please according under method turn-on. a. Put switch on auto mode. Turn on the “NO fuse breaker” with front panel(SW1,SW2,SW3), front panel indicator and bypass indicator at times are lightness. Refer to Fig14.(panel 1) Fig14 b. - Page 10 d. Disconnected input power of the UPS, mains indicator are go out, LCD display (AC) OFF, (BAT) OK, inverter output, beeps every 4 seconds will the UPS, show UPS is operating from battery power. After beeps 90 seconds, beep stop, when battery runs low, beep every 1 second, battery capacity indicator at times flashing.
-
Page 11: Condition Handling
6. Condition handling （1）Meaning as follows for representative notation. [Notes]: indicator flashing, flashing cycle and beep that will do synchronous. （2） When running condition display of the ups and unusual condition handling method: Please contrast panel indicators on ups, LCD display value and buzzer beep, namely can hear of running whether unusual of the ups, please condition handling on panel indications. - Page 12 c. Displays condition as follow on panel Fig20 The ups running condition Mains power with 120vac OK, normal running of the ups Handling way: No handling Displays condition as follows on panel Fig21 The ups running condition Mains power OK, ups running OK, battery low capacity ...
- Page 13 The ups running condition Mains power supply, overload is 125%, the overload indicator that is lightness, beep continuous Handling way Cut down less load, cause load display be power (%)<100% If condition never change after grow less load, please according to flow chart 30 handling g.
-
Page 14: New Lcd Panel Display And Alarming
The ups running condition Mains failure, battery output, battery power will out of store, beep every 1 second battery capacity indicator be flashing every 1 second Handling way Automatic shut down be about to ups, please will at hand works in no time finished, must in time store data in computer. - Page 15 Power switch Will power switch “SW1,SW2” “1s” to up “ON” whether “ON” Input voltage Check input power wire whether be true of stipulation Input allots wire Again allot wire whether correct? Input and bypass indicators whether “ON” notify this company service personality handling Continue operating Fig .28 condition handling flow chart...
- Page 16 Whether correct turn-on? Front panel switch whether push down? Notify this company service personality handling Fig29 Condition handling flow chart...
- Page 17 Whether Refer to first turn-on already correct main points once again turn-on? turn-on LCD load use rate Remove non indication whether part loads surpass 100% beep continuons Fault indicators whether “ON”? Output indicator whether still die out? Notify this company service personality handling Equipment normal operation Fig 30 Condition handling flow chart...
- Page 18 Panel button switch push down stop running of the UPS Remove non part loads Refer to general turn-on Input indicator whether “ON” Output indicator whether “ON” Bypass indicator whether “ON” fault indicator Connection on load, according to general whether “ON” Turn-on stop again turn-on Fig 31 Condition handling flow chart Notify this company service...
-
Page 19: Work Theory
Work theory 1. UPS system square frame, as fig32 Fig 32 2. UPS running method under bypass. 1) UPS normal running method under bypass mode, as fig33 Put switch on bypass, main power gets rid of high-step noise via filter and supply to use equipment via SCR1. - Page 20 When city power off, battery change into pure sine wave power and supply to equipment via SCR2. 3) UPS running method when power is out of specified range (15%),as fig35 fig35 3. UPS running method under auto mode. 1). Put switch on auto mode, when UPS normal running, filter get rid of high-step noise, one way to charge battery , another to supply for user’s eqiupment with pure sine wave Via SCR2.
-
Page 21: Maintenance Of The Ups And Battery
UPS transfer to bypass supply with following fire status: 1) overload 2) inverter protection 3) In the course of UPS starting slowly when press SW4 key to start within 20 seconds. 4) After pressed SW4 key to close. 5) Over temperature in UPS. Fig 38 Maintenance of the ups and battery (1) Everyday maintenance of the UPS... -
Page 22: Communication Interface
9. Communication interface (1) Make use of communication interface to connection the computers; monitor it power. (2) DB9 communication interface on rear panel connection to computer ,can hear of condition for ups ,task systems are DOS 、 WINDOWS3.1、 WINDOWS95、 WINDOWS-NT、 NOVELL etc. User should purchase software of computer, can be cause ups connection to computer, when hear of mains failure with system, send out information alarm, when measure up to predetermine time, can be according to normal shutdown procedure will shutdown system after storage data, after that automatically shutting down ups... -
Page 23: Specifications
10. Specifications...
