Instrument - SPECTRO SPECTROSCOUT Original Operating Instructions

1.3.2

Instrument

Instrument in transport
(not applicable to
SPECTROSCOUT at-line)
1
a
Fig. 1
No. Component
1 Sample chamber lid
2 Handle
3 X-ray radiation indicator
4 Shutter open/closed (indicator)
5-1 ePC closed
5-2 ePC opened
6 Measurement chamber plate
SPECTROSCOUT — 07.09.2015
Instrument in measurement-
condition
2
b c d
taking position
(sample chamber lid and
ePC closed)
Front side
3 4 5-1
Rear side
a b c d
No.
a
b
c
d
Description of instrument
Instrument in measurement-
taking position
(sample chamber lid and
ePC opened)
4 3 6
a b c
Component
ON button
Power supply connection
Vacuum pump connection
Gas input /vacuum connection
point
5-2
d
