Safety

This HVAC control device requires 12V direct current (DC) and cannot operate from alternating
current (AC) sources. Do NOT connect the HVAC control device to AC power. Connecting the module

Compatability

The HVAC control unit is compatible with the following appliances:
1. Single-stage LP gas furnaces with self-contained fan control.
2.
Conventional air conditioning units with one or two-speed fans.
3.
Combination air conditioning/heat pump units with one or two-speed fans.

Specifications

Operating Supply Voltage
Operating Temperature Range
Quiescent Current
Sink Current (Generator)
Focused Relay Drive Current
Specifications
The HVAC control unit includes a "capabilities" switch which must be set to correspond with the attached
equipment. The switch settings are as follows:
Switch Function
Dual Speed Fan
Heat Pump (HP)
AC Unit Present
Furnace Present
HVAC Operation - OneControl® Touch Panel
NOTE: When using the OneControl® HVAC system, all of the controls you would normally find on your
thermostat will be in the HVAC app on your OneControl® Touch Panel.

Power On/Off

1.
The device can be powered on or off using the button on the front of the device (Fig.1A).
NOTE: It will take a few moments to start up and load the system.
2.
To enter or exit sleep mode, press and release the power button (Fig. 1A).
Rev: 02.05.21
to AC will cause irreparable damage, and void the warranty.
When "OFF"
Fan is High-speed only
Unit (if present) is AC only
No AC unit in this zone
No furnace in this zone
Min Typical
9 13.8
14 (-10)
30
1.2
When "ON"
Fan has a Low Speed wire
Rooftop AC Unit includes HP
This zone has AC
This zone has gas furnace
Page 3
Max Units
18 Volts DC
113 (+45) °F (°C)
45 mA DC
2.0 A DC
1.5 A DC
Note
Orange wire
HP setting ignored
Furnace has own fan
CCD-0001448
