PR6-2
GIT-EZDS Aftermarket Distributorship Manual
ADM-SVC:2.01
Repair Procedure
6. Assembling
6.1. Insert the connector side USB port first when assembling the mainboard
6.2. Carefully align 2 screw holes on the VCI board and rear case of housing, and check tackle buttons & key
pads position as shown below.
* Do not put too much pressure on each part to be over torqued
tackle buttons
GIT-EZDS Aftermarket Distributorship Manual
th
Feb 20
, 2019 FIRST EDITION
GIT-EZDS
