IHP WINSLOW PS40 Installation Instructions

INSTALLATION INSTRUCTIONS FOR INSTALLING DOOR TRIM KITS
FOR USE WITh WINSLOW™ MODELS PS40 AND PI40 PELLET APPLIANCES
KIT CONTENTS (See Figure 1):
2 ea. Trim Pieces
6 ea. #10 nuts
6 ea. #10 washers
1 ea. Instruction Sheet
TOOLS NEEDED:
3/8" Nut Driver or Socket Wrench
Winslow Door Trim Kits
Cat. No. Model
79038 P40DT-B
79034 P40DT-G
79037 P40DT-N
79035 P40DT-BRN
79036 P40DT-BLN
(A)
Trim Pieces
#10 Nuts
Figure 1 - Kit Contents
IMPORTANT
If you have a gold or nickel trim, be sure to clean
them with a soft cloth and household glass cleaner
prior to burning the insert. Fingerprints left on the
plated surfaces while burning will usually remain
on the finish permanently.
775274M
Rev. B, 10/2013
Upper Door Trim
Lower Door Trim
Description
Black Door Trim Kit
Gold Door Trim Kit
Nickel Door Trim Kit
Brushed Nickel Door Trim Kit
Black Nickel Door Trim Kit
#10 washers
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installa-
tion.
ALL WARNINGS AND PRECAUTIONS IN ThE INSTALLATION AND
OPERATION MANUAL PROVIDED WITh ThE APPLIANCE APPLY TO
ThESE INSTRUCTIONS.
TURN OFF ThE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
INSTALLATION INSTRUCTIONS
Step 1. Remove the trim pieces and hardware from its packaging and
ensure that all pieces are present before beginning installation.
Take care not to scratch finished surfaces (see Figure 1).
Pellet Stove Door
Pellet Stove Door
Figure 2
HEARTH PRODUCTS
KITS AND ACCESSORIES
WINSLOW™ DOOR TRIM KITS
MODELS PS40 AND PI40
Upper Door Trim
Trim Pieces
Lower Door Trim
1
