Explosive View - Adexa PG811A Instruction Manual

Instruction Manual
WARNING :Electrical Shock Hazard
*Keep water and other liquids from entering the
inside of the equipment.
*Liquid inside the equipment could cause an
electrical shock.
*Do not spray the unit or controls with water or
cleaning products.
*Liquid could contact the electrical components
and cause a short circuit or an electrical shock.
*Do not use unit if power cord is damaged or
has been modified

Explosive View

NO. ITEM NAME
1 Machine's body
2 PVC Sticker
3 Lower hot plate
4 Oil container
5 Lower Heater
6 Upper hot plate
7 Upper Heater
8 Handle
9 Shaft
10 Shaft
11 Fixed board
12 Upper Heater's cover
13 Lower Heater's cover
14 Insulation cotton
15 Terminal block bracket
16 Back board
17 Upper board
MODEL:PG811A Serial Model
QTY/PCS NO. ITEM NAME
1 18 Bottom board
Wire jacket
1 19
1 20 Wire jacket
1 21 Power indicator
1 22 Power switch
1 23 Thermostat dial
1 24 Thermostat knob 1
1 25 Screw M6X10
1 26 Cir-clip
1 27 Cir-clip
1 28 Screw M5X8
1 29 Screw M4X8
1 30 Screw M4X8
1 31 Screw M5X6
1 32 Screw M6X8
1 33 Fixed Pole
1 34 Screw M6X40
WARNING :BURNED HAZARD
*Do not touch hot food, liquid or heating
surfaces while equipment is heating or operating.
*Hot surfaces and food can burn skin. Allow the
hot surfaces to cool before handling.
*Do not drop or spill water into the cooking
surface as it can spray or splatter.
QTY/PCS NO. ITEM NAME
1 35 Spring
1 36 Rubber Feet
1 37 Wire jacket
1 38 Power Cable
1 39 Power Plug
1 40 Insulation Cotton 2
41 Terminal Block
2 42 Screw M4X12
43
2 Gasket M4
1 44 Gasket M4
2 45 Screw M4
6 46 Thermostat
3 47 Screw M5X30
2 48 Screw M4X14
4 49 Screw M4X8
1
2
QTY/PCS
1
4
1
1
1
1
1
1
1
2
1
1
4
2
4
