- Page 1 PANINI CONTACT GRILL Instruction Manual Marketed globally by: ADEXA DIRECT LIMITED Ground Floor, Unit 1, 214 Purley Way, Croydon CR0 4XG United Kingdom T:(+44)01483 931040 service@adexa.co.uk www.adexa.co.uk...
- Page 2 4. Convenient independent temperature controls are easy to set and may result in overall power savings (double unit). 5. Nonstick hotplate for easy clean 6. Over-heat temperature controller for safety using Specification Model Voltage Power Hotplate shape Dimension/mm PG811A 220-240V/50HZ 1.8kW Full Ribbed 305*365*210 PG811B 220-240V/50HZ 1.8kW Full Smooth 305*365*210...
- Page 3 Instruction Manual Mainly part ⑥ 1. Heat Indicator 2. On &Off Power Switch 3. Thermostat 50-300C 4. Bottom Grill Plate ⑤ 5. Top Grill Plate 6. Thermo-insulated Handles 7. Drip Tray 8. Rubber Feet Remark :Double Grill would be has two sets of same device as above (except rubber ⑦...
-
Page 4: Explosive View
*Liquid could contact the electrical components and cause a short circuit or an electrical shock. *Do not use unit if power cord is damaged or has been modified Explosive View MODEL:PG811A Serial Model NO. ITEM NAME QTY/PCS NO. ITEM NAME QTY/PCS NO. ITEM NAME QTY/PCS 1 Machine’s body... -
Page 5: Circuit Diagram
Instruction Manual Circuit Diagram MODEL:PG811 with On &Off Power Switch ST1:Thermostat SA:Power Switch HL:Heater Indicator EH1:Heater EH2:Heater ST2:Temperature Limiter Trouble Shooting Problem Possible Cause Action Grill plates do not heat even though Defective controller Replace controller power indicators are lit. Defective heater(s) Replace heater(s) Temperature can not be controlled.
