Saxby Lighting Pimlico Bollard Instruction Leaflet

Commissioning

• Screw the terminal block box back together with the
long tab downwards. This tab will lift the terminal
block off the mounting surface ensuring the block
cannot sit in any puddle which lies underneath the
post. Push the terminal block up into the top of the
base and fix the base to the mounting surface with
the 2 screws.
• Fit the frame onto the top stem using the bayonet
lock and fit the glass pieces into their slots in the

Fitting/replacing bulb

When changing a bulb, always switch off at the mains and
allow the bulb to cool before handling. Dispose of used
bulbs carefully.
Do not exceed the wattage stated or use a different shape
bulb from that indicated on the fitting.
To access the bulb, simply unscrew the shade. Unscrew the
old bulb from the lampholder and replace with a new one.
Then screw the shade back in place.

Care and Cleaning

Do not use solvents or abrasive cleaners as these could damage the finish.
Do not clean the units with a pressure washer.

Recycling advice

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.

Safety information

For your safety, always switch off the supply before changing lightbulbs, or cleaning.
This bulb is protected by a shade. This part must be replaced immediately should the shade become
cracked or damaged. This fitting must not be used without the shade in place.
Replace Cracked Shade
www.saxbylighting.com
frame. Fit the correct bulb according to the label,
use correct shape and do not exceed the wattage
because this will overheat the lantern.
• Lock the decorative finial into the lantern cap using
the bayonet fitting and clip the cap onto the frame.
(Moulded clips on the cap latch over the edge of
the frame).
• The post is ready for use. Turn on the power and
test.
60W E27 GLS
Iss 2 05082015
Saxby Lighting Ltd. LS9 0SE
Instruction leaflet
Pimlico Bollard
EL-40044
