3.2 Processor

The Main Processor is a Cortex M0+ running at up to 48MHz. Most of its pins are connected to the external
headers, however some are reserved for internal communication with the wireless module and the on-board
2
internal I C peripherals (IMU and Crypto).
NOTE: As opposed to other Arduino Nano boards, pins A4 and A5 have an internal pull up and default to be used
2
as an I C Bus so usage as analog inputs is not recommended.
Communication with NINA W102 happens through a serial port and a SPI bus through the following pins.
SAMD21 Pin SAMD21 Acronym
13 PA08
39 PA27
41 PA28
23 PA14
21 GPIO19
24 PA15
20 GPIO22
22 PA13
21 PA12
31 PA22
32 PA23

3.3 WiFi/BT Communication Module

Nina W102 is based on ESP32 and is delivered with a pre-certified software stack from Arduino. Source code for the
firmware is available [9].
NOTE: Reprogramming the wireless module's firmware with a custom one will invalidate compliance with radio
standards as certified by Arduino, hence this is not recommended unless the application is used in private
laboratories far from other electronic equipment and people. Usage of custom firmware on radio modules is the
sole responsibility of the user.
Some of the module's pins are connected to the external headers and can be directly driven by ESP32 provided
SAMD21's corresponding pins are aptly tri-stated. Below is a list of such signals:
SAMD21 Pin SAMD21 Acronym
48 PB03
14 PA09
8 PB09
7 PB08
8 / 18
Ref.
Ref.
SJ4
xx
NINA Pin
19
27
7
28
UART RTS
29
UART CTS
1
36
23
22
NINA Pin
8
5
31
35
