with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
Use suitable detectors to find hidden utility lines or
h
call the local utility company for assistance (contact
with electric lines can lead to fire or electrical shock;
damaging a gas line can result in an explosion; pene-
trating a water pipe will cause property damage or an
electrical shock).
Secure the workpiece (a workpiece clamped with
h
clamping devices or in a vice is held more securely
than by hand).
Always wait until the machine has come to a com-
h
plete stop before placing it down. The tool insert can
jam and lead to loss of control over the power tool.
CONNECTION TO THE POWER SUPPLY
Make sure the power supply information on the ma-
chine's rating plate are compatible with the power
supply you intend to connect it to.
This appliance is Class II* and is designed for connec-
tion to a power supply matching that detailed on the
rating label and compatible with the plug fitted. If an
extension lead is required, use an approved and com-
patible lead rated for this appliance. Follow all the
instruction supplied with the extension lead.
*Double insulated
: This product requires no earth
connection as supplementary insulation is applied
to the basic insulation to protect against electric
shock in the event of failure of the basic insulation.
GUIDELINES FOR USING EXTENSION CORDS
Make sure your extension cord is in good condition.
h
When using an extension cord, be sure to use one
heavy enough to carry the current your product will
draw. An undersized cord will cause a drop in line volt-
age resulting in loss of power and overheating.
Always replace a damaged extension cord or have it
h
repaired by a qualified person before using it.
Protect your extension cords from sharp objects, ex-
h
cessive heat and damp/wet areas.
Use a separate electrical circuit for your tools. This
h
circuit should be protected with the appropriate
time-delayed fuse. Before connecting the motor to
the power line, make sure the switch is in the OFF po-
sition and the electric voltage is rated the same as the
voltage stamped on the motor nameplate. Running
at a lower voltage will damage the motor.
PRODUCT SPECIFICATIONS
INTENDED USE
The machine is intended for impact drilling in brick,
concrete and stone as well as for drilling in wood,
metal and plastic. Machines with electronic control
and right/left rotation are also suitable for screw-
driving and thread-cutting.
TECHNICAL DATA
Article number
Model
Rated voltage
Rated Power Input
No-load speed
Impact Rate
Chuck Capacity
Weight
Max. drilling diameter:
Steel
Concrete
Wood
Sound emission values determined according to
EN 60745-1
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Vibration total values a
and uncertainty K determined according to EN
60745-1
Vibration level max:
a
h
K
IDENTIFICATION
1. On/Off switch
2. Button for switch locking
3. Thumbwheel for speed selection
4. Rotational direction switch
5. Gear Selector
6. "Drilling/Impact Drilling" selector switch
7. Auxiliary handle
8. Keyless chuck (Fully Automatic Spindle Locking)
9. Depth stop
AUXILIARY HANDLE (07)
ADJUSTING THE DRILLING DEPTH
41339
ID 1050 PRO
CHANGING THE TOOL
V
220-240
Hz
50/60
W
1.050
h
h
Operate your machine only with the auxiliary han-
dle. The auxiliary handle can be set in 10 positions
to achieve a safe and low-fatigue working stance.
Turn the bottom part of the auxiliary handle and
push the auxiliary handle forward until you can
pivot it to the desired position. Then pull the aux-
iliary handle back again and tighten it by turning
the bottom part of the auxiliary handle.
The required drilling depth can be set with the
depth stop (09). Loosen the auxiliary handle and
insert the depth stop rod. Pull out the depth stop
until the distance between the tip of the drill bit
and the tip of the depth stop corresponds with the
desired drilling depth. Retighten the auxiliary han-
dle again.
Wear protective gloves when changing the
tool. The drill chuck can become very hot
during longer work periods.
The drill spindle is locked when the On/Off switch
(01) is not pressed. This makes quick, convenient and
English |
0-1.200
min
-1
0-3.200
0-19.200
min
-1
0-51.200
mm
1,5 - 13
kg
3,2
mm
13/8
mm
20/13
mm
40/25
dB(A)
93,5
dB(A)
104,5
dB
3
(triax vector sum)
m/s
9,6
2
m/s
1,5
2
