M.2 SSD-2 Removal Procedure
1. Turn off the computer, turn it over, remove the battery
2. The M.2 SSD module will be visible at point
3. The M.2 SSD module (Figure
3
4. Reverse the process to install a new module (do not forget to replace the screws and make sure that the thermal
pad is attached).
4
a.
(page 2 -
on the mainboard. Remove the screw
1
3b) will pop-up, and you can remove it from the computer.
b.
1
2
c.
5).
(Figure
2
3
4
3
Removing the M.2 SSD Module 2 - 9
Disassembly
Figure 3
M.2 SSD-2 Module
3a). Removal
a. Locate the M.2 SSD and
remove the screw.
b. The M.2 SSD module
will pop up.

3.M2 SSD Module
PCIE only
• 1 Screw
