Removing the Battery

1. Turn off the computer, turn it over.
2. Remove screws - (Figure
1 14
3. Carefully lift the bottom case
a.
1 2
11
10
12
9
8
1a).
up in the direction of the arrow at point
15
b.
4
3
14
5
13
6
7
)
and remove it (Figure 1b
16 17
16
15
17
15
Disassembly
Figure 1
Battery Removal
a. Remove the screws.
.
b. Remove the bottom case.

15. Bottom Case
• 14 Screws
Removing the Battery 2 - 5
