ASSEMBLY INSTRUCTION FOR
Fiona Torchiere
Model# 5179-21 /22
1. Screw pole (B) onto base (A) clockwise until tight.
2. Screw poles (B), (C),(D), (E) and socket (F)
together.
3. Socket ring comes pre-assembled to the socket.
Before placing the shade onto the socket, please
unscrew this socket ring.
4. Place shade (G) onto socket (F) and tighten it with
socket ring (H).

GENERAL PRODUCT INFORMATION:

This product is suitable
for dry locations only.
---------------------------------------------------------------

IMPORTANT SAFETY INSTRUCTIONS:

This portable lamp has a polarized plug as a feature to
reduce the risk of electric shock (one blade is larger than the
other). This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician.Do not use
with an extension cord unless the plug can be fully inserted.
DO NOT ALTER THE PLUG .
-------------------------------------------------------
BULB TYPE: Use only with maximum of 1*100W
incandescent bulb (bulb not included).

PARTS DIAGRAM

(1) * Socket ring (H)
353 West 39
5179-21/22
th
nd
Street, 2
Floor, New York, NY 10018
Tel: (212) 736 4440 Fax: (212) 736 4806
www.adessohome.com
1.0
