Related Manuals for gbo ULTRATHERM 908i
Summary of Contents for gbo ULTRATHERM 908i
- Page 1 Short-wave-Therapy-Unit ULTRATHERM 908i User Manual gbo Medizintechnik AG 2004 Version 1.6...
- Page 2 Art und Weise oder mit welchen Mitteln, elektronisch oder mechanisch, dies geschieht. © 2004 gbo Medizintechnik AG The gbo Medizintechnik AG has taken care in preparation of this operating instruction, but makes no expressed or implied warranty of any kind and assume no responsibility for errors or omissions.
- Page 3 Technical support is available from the manufacturer or from agencies, authorized by the manufacturer. The product is intended for a lifetime of 10 years. ULTRATHERM 908i is an electronic device. Disposing has to be done according to regulations for electronic devices.
- Page 4 IEC 61000-4-8 location in a typical commercial or hospital environment. Note: U is the a.c. mains voltage prior to application of the test level. τ gbo Medizintechnik AG 2004 Version 1.6...
- Page 5 150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz d=1,2√ √ √ √ P d=1,2√ √ √ √ P d=2,3√ √ √ √ P 0,01 0,12 0,12 0,23 0,38 0,38 0,73 gbo Medizintechnik AG 2004 Version 1.6...
- Page 6 : TÜV Product Service in Munich/Germany with the registration no. 0123 Additional information : none Date : January-1, 2006 Name of persons responsible : Dr. Eberhard Keck Title/Function : CEO Signature gbo Medizintechnik AG 2004 Version 1.6...
-
Page 7: Table Of Contents
Heat effect of the applicators 4.4.1 Capacitive method of application 4.4.2 Inductive method of application Power rating of the applicators WARNINGS AND SAFETY PRECAUTIONS TROUBLESHOOTING SUMMARY OF OPERATIONS TECHNICAL DATA ACCESSORIES 10 KEY TO SYMBOLS gbo Medizintechnik AG 2004 Version 1.6... -
Page 8: Intended Use
ULTRATHERM 908i 1 Intended Use The ULTRATHERM 908i is a high performance short wave therapy unit for high frequency heat therapy that operates at the well proved frequency of 27.12 MHz (wave length 11 m). It enables the classical therapy in capacitor-field and electromagnetic coil fields in both the continuous and the modern pulsed modes of operation and, therefore, it is suited for all heat therapy treatments in clinic as well as practice. -
Page 9: Functional Description
Power switch with light indicator RESET key Key „Continuous mode of operation“ Key „Pulsed mode of operation“ 70 Hz/2 ms Key „Pulsed mode of operation“ 350 Hz / 0.4 ms Key „Coil applicator“ MINODE ∅ 8 cm gbo Medizintechnik AG 2004 Version 1.6... -
Page 10: Structure Of The Unit
(43) and coil (30) applicators and the connection part of the detachable mains supply cable (44) including fuses. The ripcord (45) for the patient emergency-OFF switch passes through a bushing mounted in the arm fastening area so that it can be pulled from all directions. gbo Medizintechnik AG 2004 Version 1.6... -
Page 11: Support Arms
Insert the adjuster pin of the Schliephake electrode into the hole (25) and plug socket end of the electrode cable into the pin socket (26) underneath. 2.4 Applicators and applicator cables Coil as well as capacitor-field applicators can be used with the ULTRATHERM 908i (see also paragraph 7, Accessories). 2.4.1 Capacitor-field applicators (distance applicators according to „Schliephake") -
Page 12: Capacitor-Field Applicators, Elastic
Before cleaning or disinfecting the therapy unit must be switched off and the mains plug disconnected. For cleaning and disinfecting the therapy unit and accessories (except for the felt spacers, of course) we recommend commercially available surface disinfectants to be used according to their instructions for use. gbo Medizintechnik AG 2004 Version 1.6... -
Page 13: Tests, Safety And Regulations
2.6 Tests, safety and regulations The ULTRATHERM 908i conforms to MDD class IIb. Due to the strict application of legal standards and rules and maintaining the definitions of the design documentation it complies with the general requirements of labour safety. - Page 14 This includes regular inspections of all cables and lines for possible insulation defects. The ULTRATHERM 908i complies to the Medical Devices Directive (MDD) 93/42/EEC and therefore carries the CE sign with the number of the notified body for medical devices.
-
Page 15: Installation
By pressing button (6), (7), (8) or (9), (10), (11) in the "APPLICATOR" button pad the dosage (output power) is limited according to the selected applicator so that an unintended overheating of the tissues is avoided. gbo Medizintechnik AG 2004 Version 1.6... -
Page 16: Connection Of The Applicators
5-minute intervals. When both buttons are simultaneously pressed the time is reset to „O". The maximum time that can be set is 30 minutes. Changing the time during the treatment is also possible. gbo Medizintechnik AG 2004 Version 1.6... -
Page 17: Setting The Dosage
Thus, any accidental increase of the dosage due to patient movements is safely avoided, too. gbo Medizintechnik AG 2004 Version 1.6... -
Page 18: Switching Off (Emergency Disconnection By The Patient)
If anyone of these error messages is displayed the therapy unit must be switched off and the after- sales service informed. The FE 0 message means the parameter settings are incomplete. This condition is to be eliminated as described in subparagraph 2.7. No acoustic signal follows this error message. gbo Medizintechnik AG 2004 Version 1.6... -
Page 19: Treatment
Other contra-indications are growing-grooves, tumours, tuberculosis, disturbed arterial blood circulation of stages III and IV, varicose veins, general tendency to bleeding. The doses must be carefully selected for organs with low vascularization and low blood circulation (e. g. eyes, testicles)! gbo Medizintechnik AG 2004 Version 1.6... -
Page 20: Heat Effect Of The Applicators
These currents increase with the electric conductivity of the corresponding tissue region (tissues with good blood circulation, e. g. muscle tissue and inner organs). To reach these deeper tissues the coil applicators of the ULTRATHERM 908i are provided with an electrostatic shielding that prevents the technically unavoidable electric field of the coil applicator from effecting the upper-skin fat tissue and its heating. -
Page 21: Power Rating Of The Applicators
LEDs. The same is possible while using the MINODE or the MONODE. This constitutes nevertheless a regular operating condition for the ULTRATHERM 908i . Relevant for the emitted HF power and thus for the success of the therapy is the value giver in the dosage display. -
Page 22: Warnings And Safety Precautions
If it is used in dangerous areas of anesthesia departments, the possibility of an explosion cannot be excluded. • In case of all visible failures contact immediately gbo Medizintechnik AG or one of the service agencies authorized by gbo Medizintechnik AG. -
Page 23: Troubleshooting
(cf. subparagraph 2.9). gbo Medizintechnik AG 2004 Version 1.6... -
Page 24: Summary Of Operations
This signal is repeated every minute until the dosage knob (17) is reset by turning to the left (counterclockwise). • When an error is displayed (except for FE 0) press RESET button (2) and readjust, if required. • The entire therapy unit is switched off by actuating switch (1) again. gbo Medizintechnik AG 2004 Version 1.6... -
Page 25: Technical Data
30 ... 75 % transport and storage: temperature range +5 °C ... +50 °C realtive humidity of air < 90 %, non condensing All rights reserved for technical changes. gbo Medizintechnik AG 2004 Version 1.6... -
Page 26: Accessories
Cable holder (for cable without lead protection) 23-38-499 Q 5028 Clamp, small ( for cable without lead protection) 23-51-245 Q 4562 Clamp, big (for cable with lead protection) 19-53-363 Q 4514 Indicator discharge tube 22-53-722 Q 3215 gbo Medizintechnik AG 2004 Version 1.6... -
Page 27: Key To Symbols
Type B, unit suitable for external and internal application to the patient, except to the heart. Non ionizing radiation This product complies with WEEE Directive 2002/96/EG (waste electrical electronic equipment). Separate collection for electrical and electronic equipment. gbo Medizintechnik AG 2004 Version 1.6... - Page 28 Unlock electrodes (38) Axial adjustment (39) Ball joint (40) Connection (41) Fixing hole (42) Claw (43) Sockets for capacitor-field applicators (44) Mains voltage connection (45) Emergency-OFF switch (ripcord) (46) Screw holes for arm attachment gbo Medizintechnik AG 2004 Version 1.6...
- Page 29 ULTRATHERM 908i 28 34 31 33 32 35 Rückseite gbo Medizintechnik AG 2004 Version 1.6...
- Page 30 WE, SE, DI I - III 3 - 15 Angina pectoris (dose carefully) WE, SE, DI 3 - 5 Impaired peripheral circulation WE, SE II -III 10 - 15 Thrombophlebitis WE, SE 5 - 10 gbo Medizintechnik AG 2004 Version 1.6...
- Page 31 Herpetic keratitis (dose carefully) I - II 5 - 10 Ulcus corneae (dose carefully) I - II 5 - 10 = rubber-pad electrodes = air space electrodes of Schliephake type = MINODE or MONODE = DIPLODE gbo Medizintechnik AG 2004 Version 1.6...
- Page 32 ULTRATHERM 908i Correction sheet gboAG - Dokumentation - Kleiststrasse 6 D-64668 Rimbach Germany Please revise the following errors and stimulation to the document: page line wrong text right text Sender: Artikel-Nr.: 011-7-0324 gbo Medizintechnik AG 2004 Version 1.6...
